DMX Protocol

Channel 1 – Red
0-255
Channel 2 – Green
0-255
Channel 3 – Blue
0-255
Channel 4 – Dimmer intensity
0-255
Channel 5 – Sound sensitivity
0-25
26-255
Note: When using the Sound active function, please be sure to first select CH1, CH2, CH3 and CH4
Channel 6 – Auto Fade
0-14
15-255
Note: When using the Auto Fade function, please be sure to first select CH1, CH2, CH3 and CH4

Maintenance

The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
1. All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
2. There may not be any deformations on housings, fixations and installation spots.
3. Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
4. The electric power supply cables must not show any damages or material fatigue.
The Showtec LED Sphere requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture's light-output will be significantly reduced.
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
The cooling-fans, colour-wheel, the gobowheel, the gobos and the internal lenses should be cleaned
monthly with a soft brush.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Gradual adjustment Red from 0 – 100%
Gradual adjustment Green from 0 – 100%
Gradual adjustment Blue from 0 – 100%
From black to brightest
No functions
Sound-active
No fade
Fade between the active channels from fast to slow
Disconnect the mains power supply, and
