Menu Overview

Press the MODE button to scroll through 4 options of the menu:

Control Modes

There are 5 Modes:

1. Built-in Programs 1-8

When the LED Sphere is not connected by a DMX-cable, it functions as a stand-alone device.
When you press UP/DOWN in menu CHE1, you can choose one of 8 built-in programs (CHE1-CHE8).
Pay attention CHE9 is sound-controlled (Also see page 10)
Built-in Programs
CHE1: Red to Fade out
CHE2: Green to Fade out
CHE3: Blue to Fade out
CHE4: Red → Green → Red → Green, etc.
CHE5: Red → Blue → Red → Blue, etc.
CHE6: Green → Blue → Green → Blue, etc.
CHE7: RGB (=full white) to Fade out
CHE8: Red → Green → Blue → Red+Green → Red+Blue → Green+Blue → Red → Green → Blue, etc.
You are also able to adjust the Speed and Fade in time.
Press F/S to switch between Speed (S) or Fade In (F).
Speed from
Fade in
Adjust these values by pressing the Up/Down buttons.
1) Built-in Programs CHE1-8
2) Sound-controlled (CHE9)
3) Manual control
4) Master/Slave
5) DMX512
from fast to slow
from fast to slow
