2. Sound-controlled
When the LED Sphere is not connected by a DMX-cable, it functions as a stand-alone device.
When the display shows
CHE9: Red → Green → Blue → Red+Green → Red+Blue → Green+Blue → Red → Green, etc.
The LED Sphere will automatically change its color to the beat of the music.
However you are not able to adjust the audio sensitivity.
3. Manual Control
When the display shows
Press F/S to enter Manual Mode.
When you press the Up button, you are able to
The first digit of the display will move counter-clockwise.
When you press the Down button, you are only able to create a full color (Red, Green or Blue).
The first digit of the display will move clockwise.
4. Master/Slave Mode
1.
Use a 3-p XLR cable to connect the LED Sphere.
The pins:
2. Link the units as shown in (Fig. 3), Connect a DMX signal cable from the first unit's DMX "out"
socket to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
3. Configure the Menu settings as follows
Master
You can use the same functions on the master device as described on page 9+10 (Built-in
Programs 1-8,
This means on the master device you configure several settings depending on your desired
operation Mode and all slave devices will react the same as the master device.
, the LED Sphere is sound-controlled.
, you are able to mix any color you want.
1.
Earth
2.
Signal -
3.
Signal +
Music control and Manual Mode)
Multiple LED Spheres
manually mix any color you want.
Slave
(Master/Slave control)
10
Fig. 3
