Remote control
■ Remote control (CI-V) information(Continued)

D Preparing

The Icom Communications Interface V (CI-V) is used for remote control.
To control the transceiver, first set its address, data communication speed, and transceive function.
These settings are set in the Set mode (Refer to the IC-9700 instruction manual).

D About the data format

The CI-V system can be written using the following data formats. Data formats differ according to command
numbers. A data area or sub command is added for some commands.
Controller to IC-9700
q w
FE FE A2
FE FE E0
q w
IC-9700 to controller
e r t y
E0 Cn Sc Data area
A2 Cn Sc Data area
e r t y
OK message to controller
u
FD FE FE E0
FD FE FE E0
u
NG message to controller
3
A2 FB FD
A2 FA FD
