Remote control
D Command formats (Continued)
• Memory keyer content
Command: 1A 02
X X X ...... X X
X
w ~ &1 : Text data
q: Channel data
01=M1
02=M2
03=M3
04=M4
• IF filter width settings
Command: 1A 03
Mode Data
SSB/CW/RTTY
0 to 9
SSB/CW 10 to 40
RTTY 10 to 31
AM 0 to 49
• AGC time constant settings
Command: 1A 04
AGC time constant (sec.)
Data
SSB/CW/RTTY
0
OFF
1 0.1
2 0.2
3 0.3
4 0.5
5 0.8
6 1.2
7 1.6
8 2.0
9 2.5
10 3.0
11 4.0
12 5.0
13 6.0
• RX HPF/LPF setting for each operating mode
Command: 1A 05 0001, 0004, 0007,
0010, 0013, 0014
X X X X
HPF (Lower edge)
00=Through
01 ~ 20=100 ~ 2000 Hz
*The value of the HPF should be smaller than the LPF.
05=M5
06=M6
07=M7
08=M8
Steps
50 ~ 500 Hz (50 Hz)
600 Hz ~ 3.6 kHz (100 Hz)
600 ~ 2.7 kHz (100 Hz)
200 Hz ~ 10.0 kHz (200 Hz)
AM
OFF
0.3
0.5
0.8
1.2
1.6
2.0
2.5
3.0
4.0
5.0
6.0
7.0
8.0
LPF(Upper edge)
05 ~ 24=500~2400 Hz
25=Through
• SSB/SSB-DATA transmission passband width
settings
Command: 1A 05 0017 ~ 1A 05 0020
X X
Lower edge
Higher edge
• Split offset frequency setting
Command: 1A 05 0044
q w
X 0 X
• UTC Offset setting
Command: 1A 05 0184
X X X
Offset time
0000 ~ 1400
• Scope VBW (Video Band Width) settings
Command: 1A 05 0191, 27 1D
X X X
00=MAIN 00=Narrow
01=SUB 01=Wide
• Color settings
Command: 1A 05 0194, 0195, 0196, 0212, 0214,
0230, 0235, 0236
q w e
0 X X X 0 X X X
R (Red) G (Green)
0000 ~ 0255 0000 ~ 0255
16
Lower edge Higher edge
0= 100 Hz 0= 2500 Hz
1= 200 Hz 1= 2700 Hz
2= 300 Hz 2= 2800 Hz
3= 500 Hz 3= 2900 Hz
e r
X 0 X X
Direction:
00=+ direction
01=– direction
X X X
Shift direction
00=+ (plus)
01=− (minus)
X
r t y
0 X X X
B (Blue)
0000 ~ 0255
X
