Icom IC-9700 Reference Manual page 10

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
1A* 05 0198 00 to 02 SCOPE > Waterfall Speed
(00=Slow, 01=Mid, 02=Fast)
0199 00 to 02 SCOPE > Waterfall Size (Expand Screen)
(00=Small, 01=Mid, 02=Large)
0200 00 to 07 SCOPE > Waterfall Peak Color Level
(00=Grid 1 to 07=Grid 8)
0201 00 or 01 SCOPE > Waterfall Marker Auto-hide
(00=OFF, 01=ON)
0202 See p. 17 SCOPE > Fixed Edges > 144M > No.1:
0203 See p. 17 SCOPE > Fixed Edges > 144M > No.2:
0204 See p. 17 SCOPE > Fixed Edges > 144M > No.3:
0205 See p. 17 SCOPE > Fixed Edges > 430M > No.1:
0206 See p. 17 SCOPE > Fixed Edges > 430M > No.2:
0207 See p. 17 SCOPE > Fixed Edges > 430M > No.3:
0208 See p. 17 SCOPE > Fixed Edges > 1200M > No.1:
0209 See p. 17 SCOPE > Fixed Edges > 1200M > No.2:
0210 See p. 17 SCOPE > Fixed Edges > 1200M > No.3:
0211 00 or 01 AUDIO SCOPE SET >
FFT Scope Waveform Type
(00=Line, 01=Fill)
0212 See p. 16 AUDIO SCOPE SET >
FFT Scope Waveform Color
0213 00 or 01 AUDIO SCOPE SET >
FFT Scope Waterfall Display
(00=OFF, 01=ON)
0214 See p. 16 AUDIO SCOPE SET >
Oscilloscope Waveform Color
0215 0000 ~ 0255 VOICE TX > TX LEVEL
(0000=0%, 0255=100%)
0216 00 or 01 VOICE TX SET > Auto Monitor
(00=OFF, 01=ON)
0217 01 to 15 VOICE TX SET > Repeat Time
(01=1 sec. to 15=15 sec.)
0218 00 to 04 KEYER 001 > Number Style
( 00=Normal, 01=190→ANO, 02=190→ANT,
0219 01 to 08 KEYER 001 > Count Up Trigger
(01=M1 to 08=M8)
0220 0001 to 9999 KEYER 001 > Present Number
(0001=1 to 9999=9999)
0221 0000 ~ 0255 CW-KEY SET > Side Tone Level
(0000=0% to 0255=100%)
0222 00 or 01 CW-KEY SET > Side Tone Level Limit
(00=OFF, 01=ON)
0223 01 to 60 CW-KEY SET > Keyer Repeat time
(01=1 sec. to 60=60 sec.)
0224 28 to 45 CW-KEY SET > Dot/Dash Ratio
(28=1:1:2.8 to 45=1:1:4.5; 0.1 steps)
0225 00 to 03 CW-KEY SET > Rise Time
(00=2 msec., 01=4 msec., 02=6 msec.,
0226 00 or 01 CW-KEY SET > Paddle Polarity
(00=Normal, 01=Reverse)
0227 00 to 02 CW-KEY SET > Key Type
(00=Straight, 01=Bug, 02=Paddle)
0228 00 or 01 CW-KEY SET > MIC Up/Down Keyer
(00=OFF, 01=ON)
0229 00 to 03 RTTY DECODE SET > FFT Scope Averaging
(00=OFF, 01=2, 02=3, 03=4)
0230 See p. 16 RTTY DECODE SET >
FFT Scope Waveform Color
0231 00 or 01 RTTY DECODE SET > Decode USOS
(00=OFF, 01=ON)
0232 00 or 01 RTTY DECODE SET > Decode New Line Code
(00=CR, LF, CR+LF, 01=CR+LF)
0233 00 or 01 RTTY DECODE SET > TX USOS
(00=OFF, 01=ON)
0234 00 or 01 RTTY DECODE SET >
Displayed Characters during Tx (Satellite)
( 00=Displayed Characters during RX,
0235 See p. 16 RTTY DECODE SET > Font Color (Receive)
0236 See p. 16 RTTY DECODE SET > Font Color (Transmit)
0237 00 or 01 RTTY DECODE LOG > Decode Log
(00=OFF, 01=ON)
0238 00 or 01 RTTY DECODE LOG > Log Set > File Type
(00=Text, 01=HTML)
Description
03=90→NO, 04=90→NT)
03=8 msec.)
01=Displayed Characters during TX)
Cmd. Sub cmd. Data
1A* 05 0239 00 or 01
0240 00 or 01
0241 00 or 01
0242 00 or 01
0243 00 or 01
0244 00 or 01
0245 00 or 01
0246 00 or 01
0247 00 to 03
0248 00 to 03
0249 00 or 01
0250 00 or 01
0251 00 to 10
0252 00 to 06
0253 00 to 04
0254 00 or 01
0255 00 to 02
0256 00 or 01
0257 See p. 17
0258 00 to 02
0259 See p. 17
0260 00 to 03
0261 00 to 04
0262 See p. 17
0263 See p. 17
0264 See p. 17
0265 See p. 17
0266 00 to 42
0267 00 to 03
9
Description
RTTY DECODE SET > Log Set >
Time Stamp
(00=OFF, 01=ON)
RTTY DECODE SET > Log Set >
Time Stamp (Time)
(00=Local, 01=UTC)
RTTY DECODE SET > Log Set >
Time Stamp (Frequency)
(00=OFF, 01=ON)
QSO RECORDER > Recorder Set >
TX REC Audio
(00=Direct, 01=Monitor)
QSO RECORDER > Recorder Set >
RX REC Condition
(00=Always, 01=Squelch Auto)
QSO RECORDER > Recorder Set >
File Split
(00=OFF, 01=ON)
QSO RECORDER > Recorder Set >
REC Operation
( 00=MAIN/SUB Separate,
01=MAIN/SUB Link)
QSO RECORDER > Recorder Set >
PTT Auto REC
(00=OFF, 01=ON)
QSO RECORDER > Recorder Set >
PRE-REC for PTT Auto REC
(00=OFF, 01=5 sec., 02=10 sec., 03=15 sec.)
QSO RECORDER > Player Set > Skip Time
(00=3 sec., 01=5 sec., 02=10 sec., 03=30 sec.)
SCAN SET > SCAN Speed
(00=Slow, 01=Fast)
SCAN SET > SCAN Resume
(00=OFF, 01=ON)
SCAN SET > Pause Timer
( 00=2 sec. to 09=20 sec.; 2 sec. steps,
10=HOLD)
SCAN SET > Resume Timer
(00=0 sec. to 05=5 sec., 06=HOLD)
SCAN SET > Temporary Skip Timer
( 00=5 min., 01=10 min., 02=15 min.,
03=While Scanning, 04=While Powered ON)
SCAN SET > MAIN DIAL Operation (SCAN)
(00=OFF, 01=Up/Down)
GPS > GPS Set > GPS Select
(00=OFF, 01=External GPS, 02=Manual)
GPS > GPS Set > GPS Receiver Baud Rate
( 00=4800bps, 01=9600bps)
GPS > GPS Set > Manual Position
GPS > GPS TX Mode
(00=OFF, 01=D-PRS, 02=NMEA)
GPS > GPS TX Mode > D-PRS >
Unproto Address (Up to 56 characters)
GPS > GPS TX Mode > D-PRS > TX Format
( 00=Position, 01=Object,
02=Item, 03=Weather)
GPS > GPS TX Mode > D-PRS > TX Format >
Position > Symbol
(00=No.1, 01=No.2, 02=No.3, 03=No.4)
GPS > GPS TX Mode > D-PRS >
TX Format > Position >
the GPS-A Symbol No.1 setting (2 characters)
GPS > GPS TX Mode > D-PRS >
TX Format > Position >
the GPS-A Symbol No.2 setting (2 characters)
GPS > GPS TX Mode > D-PRS >
TX Format > Position >
the GPS-A Symbol No.3 setting (2 characters)
GPS > GPS TX Mode > D-PRS >
TX Format > Position >
the GPS-A Symbol No.4 setting (2 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Position > SSID
( 00=---, 01=(-0), 02=-1 to 16=-15,
17=-A to 42=-Z)
GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment
( 00=1 to 03=4)
