Icom IC-9700 Reference Manual page 16

Remote control
D Command formats (Continued)
• Codes for character entries
Command: 1A 00,
1A 05 0144, 0151, 0182, 0259,
0279, 0281, 0293, 0316
1A 05 0262 ~ 1A 05 0265,
1A 05 0268 ~ 1A 05 0271
- Character codes— Letters and Numbers
Character ASCII code
A ~ Z 41 ~ 5A
0 ~ 9 30 ~ 39
- Character codes— Symbols
Character ASCII code
! 21
$ 24
& 26
? 3F
' 27
^ 5E
− 2D
/ 2F
, 2C
; 3B
< 3C
(
28
[
5B
{
7B
|
7C
͂ 7E
Command Set item/selectable characters
1A 00 Memory name
All characters are usable.
1A 05 0144 SET > Network > Network Name
(up to 15 characters)
0151 SET > Network > Network Radio Name
(up to 16 characters)
0182 SET > Time Set > Date/Time >
NTP Server Address
Character ASCII code
a ~ z 61 ~ 7A
Character ASCII code
# 23
% 25
\ 5C
" 22
` 60
+ 2B
* 2A
. 2E
: 3A
= 3D
> 3E
)
29
]
5D
}
7D
_
5F
@ 40
• Band stacking register
Command: 1A 01
X
NOTE:
When sending the contents, the codes, such as operating
frequency and operating mode*, should be added after
the frequency band code and the register code, as shown
below.
* See t to % 1 on 'Memory content setting.' (p. 14)
q Frequency band codes
Code Freq. band Frequency range (unit: MHz)
01 VHF
02 UHF
03 1.2GHz
w Register codes
Code Registered number
01 1 (Display on left side)
02 2 (Display in center)
03 3 (Display on Right side)
To read the contents, the register code should be
added after the frequency band code, as shown
below.
Example: When reading the frequency displayed in
the center of the display in the VHF band, use code
"0202."
• Memory keyer character entries
Command: 1A 02
- Character codes
ASCII
Character
code
0 ~ 9 30 ~ 39
A ~ Z 41 ~ 5A
space 20
/ 2F
? 3F
, 2C
. 2E
@ 40
^ 5E
* 2A
15
q w
X X X
144.000000 ~ 148.000000
430.000000 ~ 450.000000
1240.000000 ~ 1300.000000
Description
Numbers
Letters
Word space
Symbol
Symbol
Symbol
Symbol
Symbol
‒ ―
Example: to send ,
BT
enter ^4254
Inserts contest number
(can be used for 1 channel only)
