Icom IC-9700 Reference Manual page 8

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
1A* 05 0090 00 or 01 SET > QSO/RX Log > RX History Log
(00=OFF, 01=ON)
0091 00 to 02 SET > QSO/RX Log > CSV Format >
Separator/Decimal
( 00=Separator is " , " and Decimal is " . ,"
0092 00 to 02 SET > QSO/RX Log > CSV Format > Date
( 00="yyyy/mm/dd," 01="mm/dd/yyyy,"
0093 00 or 01 SET > Connectors > External P.AMP > 144M
(00=OFF, 01=ON)
0094 00 or 01 SET > Connectors > External P.AMP > 430M
(00=OFF, 01=ON)
0095 00 or 01 SET > Connectors > External P.AMP > 1200M
(00=OFF, 01=ON)
0096 00 or 01 SET > Connectors >
External Speaker Separate
(00=Separate, 01=Mix)
0097 00 to 30 SET > Connectors > Phones > Level
(00=–15 dB to 30=+15 dB)
0098 00 to 02 SET > Connectors > Phones > L/R Mix
(00=Separate, 01=Mix, 02=Auto)
0099 00 or 01 SET > Connectors > ACC AF/IF Output >
AF/SQL Output Select
(00=MAIN, 01=SUB)
0100 00 or 01 SET > Connectors > ACC AF/IF Output >
Output Select
(00=AF, 01=IF)
0101 0000 ~ 0255 SET > Connectors > ACC AF/IF Output >
AF Output Level
(0000=0% to 0255=100%)
0102 00 or 01 SET > Connectors > ACC AF/IF Output >
AF SQL
(00=OFF (Open), 01=ON)
0103 00 or 01 SET > Connectors > ACC AF/IF Output >
AF Beep/Speech... Output
(00=OFF, 01=ON)
0104 0000 ~ 0255 SET > Connectors > ACC AF/IF Output >
ACC IF Output Level
(0000=0% to 0255=100%)
0105 00 or 01 SET > Connectors > USB AF/IF Output >
Output Select
(00=AF, 01=IF)
0106 0000 ~ 0255 SET > Connectors > USB AF/IF Output >
AF Output Level
(0000=0%, 0255=100%)
0107 00 or 01 SET > Connectors > USB AF/IF Output >
AF SQL
(00=OFF (Open), 01=ON)
0108 00 or 01 SET > Connectors > USB AF/IF Output >
AF Beep/Speech... Output
(00=OFF, 01=ON)
0109 0000 ~ 0255 SET > Connectors > USB AF/IF Output >
IF Output Level
(0000=0%, 0255=100%)
0110 00 or 01 SET > Connectors > LAN AF/IF Output >
Output Select
(00=AF, 01=IF)
0111 00 or 01 SET > Connectors > LAN AF/IF Output >
AF SQL
(00=OFF (Open), 01=ON)
0112 0000 ~ 0255 SET > Connectors > MOD Input > ACC MOD
Level
(0000=0% to 0255=100%)
0113 0000 ~ 0255 SET > Connectors > MOD Input > USB MOD
Level
(0000=0% to 0255=100%)
0114 0000 ~ 0255 SET > Connectors > MOD Input > LAN MOD
Level
(0000=0% to 0255=100%)
0115 00 ~ 05 SET > Connectors > MOD Input >
DATA OFF MOD
( 00=MIC, 01=ACC, 02=MIC,ACC, 03=USB,
0116 00 ~ 05 SET > Connectors > MOD Input >
DATA MOD
( 00=MIC, 01=ACC, 02=MIC,ACC, 03=USB,
Description
01=Separator is " ; " and Decimal is " . ,"
02=Separator is " ; " and Decimal is " , ")
02="dd/mm/yyyy")
04=MIC,USB, 05=LAN)
04=MIC,USB, 05=LAN)
Cmd. Sub cmd. Data
1A* 05 0117 00 or 01
0118 00 or 01
0119 00 or 01
0120 00 to 04
0121 00 to 04
0122 00 to 04
0123 00 or 01
0124 00 or 01
0125 00 or 01
0126 00 or 01
0127 00 or 01
0128 0000 ~ 0223 SET > Connectors > CI-V > CI-V USB/
0129 00 or 01
*
1
0130 00 or 01
0131 00 or 01
0132 00 to 02
0133 00 to 04
0134 00 or 01
0135 00 or 01
0136 00 to 03
0137 00 or 01
0138 0000000000
000001 ~
0255025502
550254
7
Description
SET > Connectors >
ACC SEND Output > 144M
(00=OFF, 01=ON)
SET > Connectors >
ACC SEND Output > 430M
(00=OFF, 01=ON)
SET > Connectors >
ACC SEND Output > 1200M
(00=OFF, 01=ON)
SET > Connectors > USB SEND/Keying >
USB SEND
( 00=OFF, 01=USB(A) DTR, 02=USB(A) RTS,
03=USB(B) DTR, 04=USB(B) RTS)
( You cannot select the same setting for USB
keying (CW) or USB keying (RTTY).)
SET > Connectors > USB SEND/Keying >
USB Keying (CW)
( 00=OFF, 01=USB(A) DTR, 02=USB(A) RTS,
03=USB(B) DTR, 04=USB(B) RTS)
( You cannot select the same setting for USB
SEND.)
SET > Connectors > USB SEND/Keying >
USB Keying (RTTY)
( 00=OFF, 01=USB(A) DTR, 02=USB(A) RTS,
03=USB(B) DTR, 04=USB(B) RTS)
( You cannot select the same setting for USB
SEND.)
SET > Connectors > USB SEND/Keying >
Inhibit Timer at USB connection
(00=OFF, 01=ON)
SET > Connectors > External Keypad >
VOICE
(00=OFF, 01=ON)
SET > Connectors > External Keypad >
KEYER
(00=OFF, 01=ON)
SET > Connectors > External Keypad >
RTTY
(00=OFF, 01=ON)
SET > Connectors > CI-V > CI-V Transceive
(00=OFF, 01=ON)
LAN→REMOTE Transceive Address
(0000=00h to 0223=DFh in Hexadecimal)
SET > Connectors > CI-V > CI-V USB Port
( 00=Link to [REMOTE], 01=Unlink to [REMOTE])
SET > Connectors > CI-V >
CI-V USB Echo Back
(00=OFF, 01=ON)
SET > Connectors > CI-V >
CI-V DATA Echo Back
(00=OFF, 01=ON)
SET > Connectors > CI-V >
USB (B)/DATA Function > USB (B) Function
(00=OFF, 01=RTTY Decode, 02=DV Data)
SET > Connectors > CI-V >
USB (B)/DATA Function > DATA Function
( 00=OFF, 01=RTTY Decode, 02=DV Data,
03= GPS/Weather, 04= CI-V)
SET > Connectors > CI-V >
USB (B)/DATA Function > GPS Out
(00=OFF, 01=DATA→USB (B))
SET > Connectors > CI-V >
USB (B)/DATA Function >
DV Data/GPS Out Baud Rate
( 00=4800bps, 01=9600bps)
SET > Connectors > CI-V >
USB (B)/DATA Function >
RTTY Decode Baud Rate
( 00=4800bps, 01=9600bps,
02=19200bps, 03=38400bps)
SET > Network > DHCP (Valid after Restart)
(00=OFF, 01=ON)
SET > Network > IP Address (Valid after
Restart)
( 0000000000000001=0.0.0.1 to 0255025502
550254=255.255.255.254)
( Valid when the DHCP (Valid after Restart) is
set to OFF.)
