Icom IC-9700 Reference Manual page 11

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
1A* 05 0268 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment 1 (Up to 43 characters)
0269 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment 2 (Up to 43 characters)
0270 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment 3 (Up to 43 characters)
0271 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Comment 4 (Up to 43 characters)
0272 00 to 02 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Time Stamp
(00=OFF, 01=DHM, 02=HMS)
0273 00 or 01 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Altitude
(00=OFF, 01=ON)
0274 00 to 02 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Data Extension
( 00=OFF, 01=Course/Speed,
0275 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Power
( 00=0W, 01=1W, 02=4W, 03=9W,
0276 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Height
( 00=3 m (10 ft), 01=6 m (20 ft),
0277 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Gain
(00=0 dB to 09=9 dB)
0278 00 to 08 GPS > GPS TX Mode > D-PRS > TX Format >
Position > Directivity
( 00=Omni, 01=45ºNE, 02=90ºE, 03=135ºSE,
0279 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Object Name (Up to 9 characters)
0280 00 or 01 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Data Type
(00=Live Object, 01=Kill Object)
0281 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Symbol (2 characters)
0282 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Comment (Up to 43 characters)
0283 See p. 17 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Position
0284 00 to 02 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Data Extension
( 00=OFF, 01=Course/Speed,
0285 000 to 360 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Course (0º to 360º; 1 degree steps)
0286 00 to 1850 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Speed (0 km/h to 1850 km/h)
0287 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Power
( 00=0W, 01=1W, 02=4W, 03=9W,
0288 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Height
( 00=3 m (10 ft), 01=6 m (20 ft),
0289 00 to 09 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Gain
(00=0 dB to 09=9 dB)
0290 00 to 08 GPS > GPS TX Mode > D-PRS > TX Format >
Object > Directivity
( 00=Omni, 01=45ºNE, 02=90ºE, 03=135ºSE,
Description
02=Power/Height/Gain/Directivity)
04=16W, 05=25W, 06=36W, 07=49W,
08=64W, 09=81W)
02=12 m (40 ft), 03=24 m (80 ft),
04=49 m (160 ft), 05=98 m (320 ft),
06=195 m (640 ft), 07=390 m (1280 ft),
08=780 m (2560 ft), 09=1561 m (5120 ft))
04=180ºS, 05=225ºSW, 06=270ºW,
07=315ºNW, 08=360ºN)
02=Power/Height/Gain/Directivity)
04=16W, 05=25W, 06=36W, 07=49W,
08=64W, 09=81W)
02=12 m (40 ft), 03=24 m (80 ft),
04=49 m (160 ft), 05=98 m (320 ft),
06=195 m (640 ft), 07=390 m (1280 ft),
08=780 m (2560 ft), 09=1561 m (5120 ft))
04=180ºS, 05=225ºSW, 06=270ºW,
07=315ºNW, 08=360ºN)
Cmd. Sub cmd. Data
1A* 05 0291 00 to 42
0292 00 or 01
0293 See p. 17
0294 00 or 01
0295 See p. 17
0296 See p. 17
0297 See p. 17
0298 00 to 02
0299 000 to 360
0300 00 to 1850
0301 00 to 09
0302 00 to 09
0303 00 to 09
0304 00 to 08
0305 00 to 42
0306 See p. 17
0307 00 to 42
0308 See p. 17
0309 00 to 02
0310 00 or 01
*
6
0311 00 or 01
*
6
0312 00 or 01
*
6
0313 00 or 01
*
6
0314 00 or 01
*
6
0315 00 or 01
*
6
10
Description
GPS > GPS TX Mode > D-PRS > TX Format >
Object > SSID
( 00=---, 01=(-0), 02=-1 to 16=-15,
17=-A to 42=-Z)
GPS > GPS TX Mode > D-PRS > TX Format >
Object > Time Stamp
(00=DHM, 01=HMS)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Item Name (Up to 9 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Data Type
(00=Live Item, 01=Killed Item)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Symbol (2 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Comment (Up to 43 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Position
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Data Extension
( 00=OFF, 01=Course/Speed,
02=Power/Height/Gain/Directivity)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Course (0º to 360º; 1 degree steps)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Speed (0 km/h to 1850 km/h)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Power
( 00=0W, 01=1W, 02=4W, 03=9W,
04=16W, 05=25W, 06=36W, 07=49W,
08=64W, 09=81W)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Height
( 00=3 m (10 ft), 01=6 m (20 ft),
02=12 m (40 ft), 03=24 m (80 ft),
04=49 m (160 ft), 05=98 m (320 ft),
06=195 m (640 ft), 07=390 m (1280 ft),
08=780 m (2560 ft), 09=1561 m (5120 ft))
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Gain
(00=0 dB to 09=9 dB)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > Directivity
( 00=Omni, 01=45ºNE, 02=90ºE, 03=135ºSE,
04=180ºS, 05=225ºSW, 06=270ºW,
07=315ºNW, 08=360ºN)
GPS > GPS TX Mode > D-PRS > TX Format >
Item > SSID
( 00=---, 01=(-0), 02=-1 to 16=-15,
17=-A to 42=-Z)
GPS > GPS TX Mode > D-PRS > TX Format >
Weather > Symbol (2 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Weather > SSID
( 00=---, 01=(-0), 02=-1 to 16=-15,
17=-A to 42=-Z)
GPS > GPS TX Mode > D-PRS > TX Format >
Weather > Comment (Up to 43 characters)
GPS > GPS TX Mode > D-PRS > TX Format >
Weather > Time Stamp
(00=OFF, 01=DHM, 02=HMS)
GPS > GPS TX Mode > NMEA >
GPS Sentence (RMC)
(00=OFF, 01=ON)
GPS > GPS TX Mode > NMEA >
GPS Sentence (CGA)
(00=OFF, 01=ON)
GPS > GPS TX Mode > NMEA >
GPS Sentence (GLL)
(00=OFF, 01=ON)
GPS > GPS TX Mode > NMEA >
GPS Sentence (GSA)
(00=OFF, 01=ON)
GPS > GPS TX Mode > NMEA >
GPS Sentence (VTG)
(00=OFF, 01=ON)
GPS > GPS TX Mode > NMEA >
GPS Sentence (GSV)
(00=OFF, 01=ON)
