Icom IC-9700 Reference Manual page 9

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
1A* 05 0139 0000000000 SET > Network > DHCP (Valid after Restart)
* 000001 ~
Read the IP address set by the DHCP server
1
0255025502 ( 0000000000000001=0.0.0.1 to 0255025502
550254
( When the DHCP setting (Valid after Restart)
0140 01 ~ 30 SET > Network >
Subnet Mask (Valid after Restart)
(01=128.0.0.0 (1 bit) to 30=255.255.255.252
(30 bit))
( Valid when the DHCP (Valid after Restart)
0141 0000000000 SET > Network >
000001 ~ Default Gateway (Valid after Restart)
0255025502 ( 0000000000000001=0.0.0.1 to 0255025502
550254, FF
( Valid when the DHCP (Valid after Restart)
0142 0000000000 SET > Network >
000001 ~ Primary DNS Server (Valid after Restart)
0255025502 ( 0000000000000001=0.0.0.1 to 0255025502
550254, FF
( Valid when the DHCP (Valid after Restart)
0143 0000000000 SET > Network >
000001 ~ 2nd DNS Server (Valid after Restart)
0255025502 ( 0000000000000001=0.0.0.1 to 0255025502
550254, FF
( Valid when the DHCP (Valid after Restart)
0144 See p. 15 SET > Network > Network Name
(Up to 15 characters)
0145 00 or 01 SET > Network >
Network Control (Valid after Restart)
(00=OFF, 01=ON)
0146 00 or 01 SET > Network >
Power OFF Setting (for Remote Control)
(00=Shutdown only, 01=Standby/Shutdown)
0147 000001 ~ SET > Network >
065535 Control Port (UDP) (Valid after Restart)
(000001=1 to 065535=65535)
0148 000001 ~ SET > Network >
065535 Serial Port (UDP) (Valid after Restart)
(000001=1 to 065535=65535)
0149 000001 ~ SET > Network >
065535 Audio Port (UDP) (Valid after Restart)
(000001=1 to 065535=65535)
0150 00 or 01 SET > Network >
Internet Access Line (Valid after Restart)
( 00=FTTH (Fiber To The Home), 01=ADSL/
0151 See p. 15 SET > Network > Network Radio Name
(Up to 16 characters)
0152 0000 ~ 0255 SET > Display > LCD Backlight
(0000=0% to 0255=100%)
0153 00 or 01 SET > Display > Display Type
(00=A, 01=B)
0154 00 or 01 SET > Display > Display Font
(00=Basic, 01=Round)
0155 00 or 01 SET > Display > Meter Peak Hold (Bar)
(00=OFF, 01=ON)
0156 00 or 01 SET > Display > Memory Name
(00=OFF, 01=ON)
0157 00 or 01 SET > Display >
MN-Q Popup (MN OFF→ON)
(00=OFF, 01=ON)
0158 00 or 01 SET > Display > BW Popup (PBT)
(00=OFF, 01=ON)
0159 00 or 01 SET > Display > BW Popup (FIL)
(00=OFF, 01=ON)
0160 00 to 03 SET > Display > RX Call Sign Display
(00=OFF, 01=Normal, 02=RX Hold, 03=Hold)
0161 00 or 01 SET > Display > RX Position Indicator
(00=OFF, 01=ON)
0162 00 to 02 SET > Display > RX Position Display
( 00=OFF, 01=ON (Main/Sub),
Description
550254=255.255.255.254)
is set to OFF, the manually set IP address
(static IP address) is returned.)
setting is set to OFF.)
550254=255.255.255.254, FF=Blank)
setting is set to OFF.)
550254=255.255.255.254, FF=Blank)
setting is set to OFF.)
550254=255.255.255.254, FF=Blank)
setting is set to OFF.)
CATV)
02=ON (Main Only))
Cmd. Sub cmd. Data
1A* 05 0163 00 to 04
0164 00 or 01
0165 00 to 02
0166 00 or 01
0167 00 to 03
0168 00 or 01
0169 00 or 01
0170 00 or 01
0171 00 or 01
0172 00 to 02
0173 00 or 01
0174 00 to 03
0175 00 or 01
0176 00 to 03
0177 00 or 01
0178 00 or 01
0179 20000101 ~
20991231
0180 0000 ~ 2359 SET > Time Set > Date/Time > Time
0181 00 or 01
0182 See p. 15
0183 00 or 01
0184 See p. 16
0185 00 to 02
0186 00 to 02
0187 00 or 01
0188 00 to 02
0189 00 ~ 02
0190 00 or 01
0191 See p. 16
0192 00 to 03
0193 00 or 01
0194 See p. 16
0195 See p. 16
0196 See p. 16
0197 00 or 01
8
Description
SET > Display > RX Position Display Timer
( 00=5 sec, 01=10 sec, 02=15 sec,
03=30 sec, 04=Hold)
SET > Display > Reply Position Display
(00=OFF, 01=ON)
SET > Display > TX Call Sign Display
( 00=OFF, 01=Your Call Sign,
02=My Call Sign)
SET > Display > Scroll Speed
(00=Slow, 01=Fast)
SET > Display > Screen Saver
( 00=OFF, 01=15 min.,
02=30 min., 03=60 min.)
SET > Display > Opening Message
(00=OFF, 01=ON)
SET > Display > Power ON Check
(00=OFF, 01=ON)
SET > Display > Display Unit >
Latitude/Longitude
(00=ddd°mm.mm', 01=ddd°mm'ss")
SET > Display > Display Unit >
Altitude/Distance
(00=m, 01=ft/mi)
SET > Display > Display Unit > Speed
(00=km/h, 01=mph, 02=knots)
SET > Display > Display Unit > Temperature
(00=ºC, 01=ºF)
SET > Display > Display Unit > Barometric
(00=hPa, 01=mb, 02=mmHg, 03=inHg)
SET > Display > Display Unit > Rainfall
(00=mm, 01=inch)
SET > Display > Display Unit > Wind Speed
(00=m/s, 01=km/h, 02=mph, 03=knots)
SET > Display > Display Language
(00=English, 01=Japanese)
SET > Display > System Language
(00=English, 01=Japanese)
SET > Time Set > Date/Time > Date
(20000101=2000/01/01 to 20991231=2099/12/31)
(0000=00:00 to 2359=23:59)
SET > Time Set > Date/Time > NTP Function
(00=OFF, 01=ON)
SET > Time Set > Date/Time >
NTP Server Address
SET > Time Set > Date/Time >
GPS Time Correct
(00=OFF, 01=Auto)
SET > Time Set > UTC Offset
SET > SD Card > Import/Export >
CSV Format > Separator/Decimal
( 00=Separator is " , " and Decimal is " . ,"
01=Separator is " ; " and Decimal is " . ,"
02=Separator is " ; " and Decimal is " , ")
SET > SD Card > Import/Export >
CSV Format > Date
( 00=""yyyy/mm/dd," 01="mm/dd/yyyy,"
02="dd/mm/yyyy")
SCOPE > Scope during Tx (CENTER TYPE)
(00=OFF, 01=ON)
SCOPE > Max Hold
(00=OFF, 01=10s Hold, 02=ON)
SCOPE > CENTER Type Display
( 00=Filter center, 01=Carrier point center,
02=Carrier point center (Abs. Freq.))
SCOPE > Marker Position (Fix Type)
(00=Filter center, 01 Carrier point)
SCOPE > VBW
SCOPE > Averaging
(00=OFF, 01=2, 02=3, 03=4)
SCOPE > Waveform Type
(00=Fill, 01=Fill+Line)
SCOPE > Waveform Color (Current)
SCOPE > Waveform Color (Line)
SCOPE > Waveform Color (Max Hold)
SCOPE > Waterfall Display
(00=OFF, 01=ON)
