Remote control
D Command formats (Continued)
• RIT frequency settings
Command: 21 00
X X X X
• DV TX data
Command: 22 00
1 ~ 30
X X ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
(Variable length)
q ~ #0 : Tx, data (Up to 30 Byte)
(" FA" to "FF" are entered after converted to
"FF 0A" to "FF 0F" automatically. Up to 60 Byte
data can be entered in this case.)
• DV RX data (transceive)
Command: 22 0101
1 ~ 30
X X
∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
(Variable length)
q ~ #0 : Rx, data (Up to 30 Byte)
(" FA" to "FF" are entered after converted to
"FF 0A" to "FF 0F" automatically. Up to 60 Byte
data can be entered in this case.)
• MY position data
Command: 23 00
~ ~
1 5 6
X X ∙∙∙∙∙∙∙ X X X X ∙∙∙∙∙∙∙
~
16 17 18
X X X X X X
∙∙∙∙∙∙∙
q ~ t: Latitude (ddºmm.mmm format)
y ~ !1 : Longitude (dddºmm.mmm format)
!2 ~ !5 : Altitude (0.1 meter steps)
!6 , !7 : Course (1 degree steps)
!8 ~ @0 : Speed (0.1 km/h steps)
@1 ~ @7 : Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second)
X X
00: + (plus)
01: – (minus)
X X
X X
~
11 12 15
X X X X ∙∙∙∙∙∙∙ X X
~
20 21 27
X X X X X X
∙∙∙∙∙∙∙
• Selected or unselected VFO frequency settings
Command: 25
X X X X X X X X X X 0 0
*00=Selected VFO
See "Operating frequency."
01=Unselected VFO
* 00/01 can be set in the VFO mode. (In the satellite
mode, "FA" (NG) is returned.)
In the memory channel mode, call channel mode,
or DR function, the transceiver returns "FA" (NG)
because these cannot be set to 01.
•When VFO A is selected
00=frequency of VFO A changes
01=frequency of VFO B changes
•When VFO B is selected
00=frequency of VFO B changes
01=frequency of VFO A changes
• Selected or unselected VFO's operating mode
and filter settings
Command: 26
Both data and filter settings can be skipped. In that
case, "DATA OFF" and the default filter setting of
the operating mode is automatically selected.
2
X X X X
1 Operating mode setting
*00=Selected VFO
01=Unselected VFO
* 00/01 can be set in the VFO mode. (In the satellite
mode, "FA" (NG) is returned.)
In the memory channel mode, call channel mode,
or DR function, the transceiver returns "FA" (NG)
because these cannot be set to 01.
•When VFO A is selected
00=operating mode of VFO A changes
01=operating mode of VFO A changes of VFO B changes
•When VFO B is selected
00=operating mode of VFO A changes of VFO B changes
01=operating mode of VFO A changes of VFO A changes
q Operating mode
setting
00 :LSB 05 :FM
01 :USB 07 :CW-R
02 :AM 08 :RTTY-R
03 :CW 17: DV
04 :RTTY 22: DD* 1
1
* 22 Command (DD) can be selected when setting the
1200 MHz band to other than the satellite mode.
2
* When 00 is set, also set 00 to e.
23
Operating frequency
(p. 13)
Data mode setting
X X X X
3 Filter setting
w Data mode
setting
00: Data mode OFF* 2
01: Data mode ON
—
—
—
e Filter
setting
01 :FIL1
02 :FIL2
03 :FIL3
—
—
