Remote control
D Command formats (Continued)
• DV RX call sign data
Command: 20 0001, 20 0002
3 ~ 10
1, 2
X X X X X X X X
∙∙∙∙∙∙
23 ~ 30
X X X X X X
∙∙∙∙∙∙
q Header flag data (First byte)
Data
(0: Fixed)
bit7
(0: Fixed)
bit6
(0: Fixed)
bit5
0/1 0=Voice, 1=Data
bit4
0/1 0=Direct, 1=Through repeater
bit3
0/1 0=No Break-in, 1=Break-in
bit2
0/1 0=Data, 1=Control
bit1
0/1 0=Normal, 1=EMR
bit0
w Header flag data (Second byte)
Data
bit2 bit1 bit0
1 1 1 Repeater control
1 1 0 Send auto acknowledge
1 0 1 (Not used)
1 0 0 Request to re-transmit
0 1 1 Send acknowledge
0 1 0 Receive no reply
0 0 1 Repeater disabled
0 0 0 NULL
e ~ !0 : Call sign of the caller station
(8 characters, fixed)
!1 ~ !4 : Note of the caller station
(4 characters, fixed)
!5 ~ @2 : Call sign of the called station
(8 characters, fixed)
@3 ~ #0 : Call sign of the access/area repeater (R1)
(8 characters, fixed)
#1 ~ #8 : Call sign of the link/gateway repeater (R2)
(8 characters, fixed)
LFF: When no call sign is received since the transceiver
power was turned ON.
11 ~ 14 15 ~ 22
X X X X X X X X
∙∙∙∙∙∙
31 ~ 38
X X
∙∙∙∙∙∙
Description
—
—
—
Description
• DV RX message
Command: 20 0101, 20 0102
~
1 20
X X X X X X
∙∙∙∙∙∙
q ~ @0 : Message (20 characters)
@1 ~ @8 : Call sign of the caller station (8 characters)
@9 ~ #2 : Note of the caller station (4 characters)
See "Codes for character entries." (p. 15)
LFF: When no call sign is received since the transceiver
power was turned ON.
Example: When a Gateway call is received
RXRPT2
GW
RXRPT1
CALLED
YOUR STATION
CALLER: Caller's call sign
CALLED: Called station call sign
RXRPT1: Call sign of the repeater that was
accessed by the caller station
L If it was a call through a gateway and the
internet, this item displays the gateway call
sign of the repeater you received the call from.
RXRPT2: Call sign of the repeater you received the
call from
• DV RX Status setting
Command: 20 0201, 20 0202
Data Function
bit7 0 (Fixed)
Receiving a
bit6 0/1
voice call
Last call
bit5 0/1
finisher
Receiving a
bit4 0/1
signal
Receiving a
bit3 0/1
BK call
Receiving a
bit2 0/1
EMR call
Receiving a
bit1 0/1 signal other
than DV
Packet loss
bit0 0/1
status
20
~ ~
21 28 29 32
X X X X X X
∙∙∙∙∙∙
INTERNET INTERNET
Description
—
While receiving a digital
voice signal, select "1."
(Regardless of DSQL and
CSQL setting)
When the last call was
finished by you, select "1."
When the audio tone can
be heard, select "1."
While receiving a BK call,
select "1."
While receiving a EMR call,
select "1."
When "DV" and "FM" are
blinking, select "1."
While displaying packet
loss, "1" is returned.
CALLER
