Icom IC-9700 Reference Manual page 13

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
27 00 See p. 24 Read the Scope waveform data
( Only when "Scope ON/OFF status"
10* 00 or 01 Send/read the Scope ON/OFF status
(00=OFF, 01=ON)
,
11* * 00 or 01 Send/read the Scope wave data output
8
(00=OFF, 01=ON)
12* 00 or 01 Send/read the Main or Sub scope setting
(00=Main, 01=Sub)
14* See p. 24 Send/read the Scope Center mode or Fixed
mode setting
15* See p. 24 Send/read the Span setting in the Center
mode Scope
16* See p. 24 Send/read the Edge number setting in the
Fixed mode Scope
17* See p. 24 Send/read the Scope hold function ON/OFF
status
19* See p. 24 Send/read the Scope Reference level setting
1A* See p. 25 Send/read the Sweep speed setting
1B* 00 or 01 SCOPE > Scope during Tx (CENTER TYPE)
(00=OFF, 01=ON)
1C* 00 to 02 SCOPE > CENTER Type Display
(00=Filter center, 01=Carrier point center,
1D* See p. 16 Send/read the Scope VBW setting
1E* See p. 25 Send/read the Scope Fixed edge frequencies
28 00 00 to 08 Voice TX Memory
(00=Stop, 01=T1 to 08=T8)
Description
(Command: 27 10) and "Scope data output"
(Command: 27 11) are set to "ON," outputs
the waveform data to the controller.)
02=Carrier point center (Abs. Freq.))
*(Asterisk) Send/read data
* Read only data
1
* Send only data
2
* In the CW mode, if the [TRANSMIT] or an external TX
3
switch is ON, or the Break-in function is ON, a message
will be transmitted as CW code when you send it from your
PC.
* When sending the power ON command (18 01), you need
4
to repeatedly send "FE" before the standard format. The
following is the approximate number of needed repetitions.
• 115200 bps: 119 "FE"s
• 57600 bps: 59 "FE"s
• 38400 bps: 40 "FE"s
• 19200 bps: 20 "FE"s
• 9600 bps: 9 "FE"s
• 4800 bps: 5 "FE"s
Example: When using 4800 bps
Preamble
F E F E F E
×5
* To insert a counter, first clear the other channel's counter.
5
* Set at least 1 GPS sentence to ON.
6
Up to 4 GPS sentences can be set to ON at the same time.
* Output setting is automatically set to OFF after turning
7
OFF the transceiver.
* When you use the [USB] port, select "Unlink from
8
[REMOTE]" in the "CI-V USB port" item, and select
"115200" in the "CI-V Baud Rate" item.
» SET > Connectors > CI-V
MENU
You can use the [LAN] port, regardless of those settings.
You cannot use the [REMOTE] terminal, regardless of
those settings.
12
Controller's Command
9700's Sub
address
address command
A 2 E 0 1 8 0 1
Post
amble
F D
