INTRODUCTION

Thank you for purchasing the Intellinet Network Solutions Gigabit Ethernet PoE+ Web-Managed AV Switch.
Before you install and use this product, read this manual carefully for a full understanding of its functions.
Because this manual applies to multiple models, the screenshots and tables may vary slightly from the actual
images that your particular model offers.

PRODUCT OVERVIEW

This switch provides seamless network connections. It integrates 1000 Mbps Gigabit Ethernet, 100 Mbps
Fast Ethernet and 10 Mbps Ethernet network capabilities into a highly flexible package. The switch's rear-
facing ports make for a cleaner installation in the rack, so it's perfect for use in A/V environments. Each of the
10/100/1000 Mbps Auto-Negotiation RJ45 ports support Auto MDI/MDIX function.
The switch offers a high-performance upgrade from your old network to a 1000 Mbps Gigabit network. It
is essential in solving network bottlenecks that frequently develop as more advanced computer users and
newer applications demand greater network resources. For efficient management, the switch offers a remote
Web interface. You can program the switch for advanced management functions such as Port Management,
Link Aggregation, VLAN, Spanning Tree, Multicast, QoS, Security, Access Control, MAC Address Table,
Diagnostics, RMON and Maintenance. Its PoE ports can automatically detect and supply power to IEEE802.3at-
compliant Powered Devices (PD) such as Wireless Access Points, network cameras or Voice over IP phones.

FEATURES

• Rear-facing IEEE 802.3at/af-compliant RJ45 PoE/PoE+ Gigabit Ethernet ports
• Provides power and data connection for 8, 16 or 24 PoE network devices, depending on model
• 10/100/1000 auto-sensing ports automatically detect optimal network speeds
• Two small form-factor pluggable 1 GbE SFP module slots
• Two RJ45 combo uplink ports (model 561457)
• Console port for configuring
• Power output up to 30 watts per port*
• PoE power budget of 255 watts for models 561433 & 561440 and 425 watts for model 561457
• Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (e.g., wireless access points, VoIP phones,
IP cameras, etc.)
• Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
• Management by Web/SNMP/Telnet/Console
• All RJ45 ports with Auto-MDIX and NWay auto-negotiation support
• Complies with the IEEE 802.3az (Energy Efficient Ethernet [EEE]) specification
• Offers 20 Gbps switch fabric in model 561433 and 36 Gbps switch fabric in models 561440 & 561457
• SNMP Management and Remote Monitoring (RMON)
• Remote reboot/restart
• IPv4/v6 dual protocol
• Supports VLAN (tag-based and port-based)
• Provides IEEE 802.1x port-based security
• Supports link aggregation (trunking)
