STATUS FIELD

A State field will display on the far-right of some Focus Pages, which gives the status of the line displayed. All
displayed status fields are Read-Only. Once information has been entered, click Apply, and the line will reflect
the status.
Switch
SWITCH CONFIGURATION
This section describes how to use the web‐based management interface (Web UI) for this switch.

SYSTEM CONFIGURATION

BASIC INFORMATION

The following image shows basic system information, which lets you to configure the System Name, Location
and Contact. Click apply to save any changes.
Switch

SERIAL (CONSOLE PORT) INFORMATION

The following image shows the settings of the console port, which include Baud Rate, Character Size, Parity
Code, Stop Bits, and Flow Control. Make sure settings are the same in the software on your PC.
Switch
