Page 1 QMS 1725E ® Print System Reference 1800387-001B...
Page 2 Copyrighted © 1995 by QMS, Inc. All Rights Reserved. This software may not be reproduced, modified, displayed, transferred, or copied in any form or in any manner or on any media, in whole or in part, without the express written permission of QMS, Inc. Copyright Notice This manual is Copyrighted ©...
Page 3: Table Of Contents
Contents Contents Introduction Introduction .................. 1-2 About This Manual ............... 1-2 Typographic Conventions 1-4 Print Media Introduction .................. 2-2 Media Sizes and Imageable Areas ..........2-2 Setting Page Margins 2-3 Media Types and Weights ............2-3 Envelopes 2-4 Labels 2-4 Paper 2-4...
Page 4 Using Printer Commands 4-3 Using the Control Panel 4-3 Using a Remote Console 4-4 Configuration Menu ..............4-4 Accessing the Configuration Menu 4-5 Selecting Configuration Menu Options 4-6 Changing Character Information 4-7 Saving Configuration Changes 4-10 QMS 1725E Print System Reference...
Page 5 Canceling Configuration Changes 4-10 Setting the Message Window Language 4-11 Restoring the Factory Default Configuration 4-12 Operator Control Menu ..............4-12 Copies 4-12 Collation 4-13 Orientation 4-13 Inputbin 4-13 Outputbin 4-14 Chain Inputbins 4-14 Manual Feed Size 4-14 Def. Duplex 4-15 Tumble Duplex 4-15 Administration Menu ..............4-15 Communications ................4-16...
Page 6 Formatting a Hard Disk 4-61 Collation 4-61 Spool Overflow 4-61 Installation .................. 4-62 Operator Password 4-62 Use Operator Password 4-62 Admin Password 4-62 Use Admin Password 4-63 Using Passwords 4-63 Configuring Optional Features ..........4-63 QMS 1725E Print System Reference...
Page 7 Communication Modes ..............5-3 About Gamma Correction ............5-3 Terms 5-4 Gamma Correction Concept 5-5 Memory ..................5-7 QMS Memory Management 5-7 Memory Terms 5-8 Evaluation of Your Printing Environment 5-10 Memory Clients 5-12 Hard Disk Management 5-18 End Job Mode ................5-19...
Page 8 Installing an Optional Interface Card and Daughterboard 6-29 Using a Network Interface ............6-34 Using a LocalTalk Interface ............6-34 Hardware 6-35 Software 6-36 Testing Macintosh Communication 6-40 Internal Hard Disk ..............6-43 External Hard Disk Drive 6-46 QMS 1725E Print System Reference...
Page 9 QMS Customer Support Sources of Support ..............A-2 Your QMS Vendor A-2 Your Application Vendor A-2 Q-FAX A-2 The QMS Corporate Bulletin Board System A-3 CompuServe A-3 Internet A-3 QMS Customer Technical Assurance (CTA) A-4 QMS National Service A-5 QMS World-wide Offices ............A-6 Technical Specifications Print Engine Specifications ............
Page 10 Electrostatic Discharge and Your Warranty B-13 Document Option Commands Introduction ..................C-2 Supported DOCs ................C-2 Header/Trailer Page Commands C-2 HP-GL Emulation Commands C-2 HP PCL 5 Emulation Commands C-3 Lineprinter Emulation Commands C-3 PostScript Emulation Commands C-4 Printer Commands C-4 viii QMS 1725E Print System Reference...
Page 11 Updated DOCs ................C-4 PCL 5 Emulation Terminology C-4 Updated PCL 5 DOCs C-7 CCITT Commands ..............C-20 Accessing CCITT Emulation C-20 Command Syntax C-20 ImageSize C-21 ImagePosition C-21 Rotation C-22 LineEnd C-22 BlockEnd C-23 EBAMode C-23 BitReverse C-23 InvertImage C-24 Compression C-24 DPI C-24 ImageData C-25...
Page 12 Glossary Index QMS 1725E Print System Reference...
Page 13: Introduction
Introduction In This Chapter . . . About this manual Typographic conventions...
Page 14: About This Manual
Introduction Introduction This manual provides detailed instructions and technical information for your QMS 1725E Print System. Use this guide in conjunction with your other printer documentation. This chapter gives you a brief overview of this manual. About This Manual The information in this manual is divided into the following sections: Chapter 1—Introduction...
Page 15 Appendix A—QMS Customer Support Provides world-wide product sales and support telephone num- bers and describes how to communicate with QMS through the QMS Bulletin Board, CompuServe, the Internet, and Q-FAX. Appendix B—Technical Specifications Provides technical specifications for the printer and lists available supplies and replacement parts.
Page 16: Typographic Conventions
Warnings indicate the possibility of personal injury if a specific WA RNING! procedure is not performed exactly as described in the manual. Bitte halten Sie sich exakt an die im Handbuch beschriebene A CHTUNG! Vorgehensweise, da sonst Verletzungsgefahr bestehen könnte. QMS 1725E Print System Reference...
Page 17: Print Media
Print Media In This Chapter . . . Media sizes, margins, and imageable areas Media types and weights Media storage...
Page 18: Introduction
Introduction Introduction This chapter lists the media sizes and imageable areas supported by the QMS 1725E Print System, and then provides information on selecting and storing media. Media Sizes and Imageable Areas Your printer supports media of different sizes. Each media size has a certain imageable area, the maximum area on which the printer can print.
Page 19: Media Types And Weights
Media Types and Weights Working Within the Imageable Area The imageable areas for print media on your QMS 1725E Print Sys- tem are not centered vertically on their respective pages and may vary " (1.6 mm). You can align the image in several different ways: Adjust the margins or page size through your application.
Page 20: Envelopes
Laser Print. Thicker paper, such as Xerox 4024 (28 lb [105 g/m ]), is also acceptable when using manual feed. » Note: We recommend that you do not print on perforated or 3-hole punched paper. QMS 1725E Print System Reference...
Page 21: Transparencies
Media Storage Weight The printer supports the following weights of paper: Paper cassettes—17-24 lb (64-90 g/m Manual feed—17-34 lb (64-128 g/m Transparencies Type Use only transparencies recommended for laser printers, such as Canon brand type D and 3M type PP2500. Weight The printer supports 17-34 lb (64-128 g/m ) transparencies using...
Page 23: Professional Printing
Professional Printing In This Chapter . . . About typefaces and fonts More typography terms Typeface classification Resident fonts Postscript typeface sampler Page design References...
Page 24: Introduction
Character Set A character set is a collection of symbols designed for various printing applications. Many character sets are composed of the letters (upper- case and lowercase A-Z), digits (0-9), and any symbol (such as blank QMS 1725E Print System Reference...
Page 25: More Typography Terms
More Typography Terms space, dollar sign, and ampersand). Other character sets are com- posed entirely of symbols. More Typography Terms Monospacing The terms “monospaced” and “fixed-pitch” refer to a typeface whose characters all have uniform and equal spacing. These typefaces are useful for spreadsheets and other documents with columnar data.
Page 26 10-Pitch Courier 12-Pitch Courier Stroke Weight Stoke weight (light/medium/bold) is the width (thickness), of the lines (strokes) that make up a character. The following example shows the medium and bold weights of Palatino: Palatino Palatino QMS 1725E Print System Reference...
Page 27 More Typography Terms Italic and Oblique Forms Italic was originally developed in the early sixteenth century as a type- face based on cursive handwriting. Today’s italics are still individually crafted typefaces designed to blend with a specific roman (upright) typeface. Oblique (or slanted) type forms, however, are not designed and crafted individually but are mechanically slanted versions of the roman form from which they derive.
Page 28: Typeface Classification
In the following example, the slight curving at the bottom of the letters “t” and “a” is not a serif. It is part of the line forming the letter rather than a decorative line added on: Helvetica QMS 1725E Print System Reference...
Page 29: Resident Fonts
Resident Fonts Resident PostScript Fonts The following 39 PostScript fonts are resident in your printer. See your QMS vendor if you are interested in expanding your printer's typeface families. Serif Fonts ITC Bookman Light ITC Bookman Light Italic...
Page 30 ITC Zapf Chancery Medium Italic Pi or Symbol Fonts Σψµβολ (Symbol) Dingbats (ITC Zapf Dingbats) All of these typeface families are authentic: they are licensed, they carry the true name, and they have multilingual character sets. QMS 1725E Print System Reference...
Page 31: Resident Hp Pcl Fonts
Resident Fonts Resident HP PCL Fonts Your printer has the following resident HP PCL fonts. All fonts can be automatically rotated to landscape orientation. Some are fixed in pitch and point size while others are scalable. Unless otherwise noted, samples are show in 10 point size. Serif Fonts Courier 12 pitch 10 point Courier 12 pitch 10 point Italic...
Page 32: Optional Fonts
Optional Intellifont SIMM—Increases the number of PCL 5 fonts from 20 to 37. See chapter 6, “Printer Options,” for more informa- tion. Optional Kanji internal IDE hard disk—Provides 6 Kanji fonts. See chapter 6, “Printer Options,” for more information. 3-10 QMS 1725E Print System Reference...
Page 33: Postscript Typeface Sampler
PostScript Typeface Sampler PostScript Typeface Sampler Following are some tips on using your printer’s resident PostScript typefaces appropriately and effectively. All samples are printed 10 points in size. Helvetica—Helvetica is a popular typeface, a modification of a kind of sans serif typeface called Grotesque. It is used widely in publishing and is admired for its clean lines, although it can be repetitive to the eye, ESPECIALLY WHEN IN ALL CAPS.
Page 34 σ δ φ γ η ϕ κ λ ζ ξ χ ϖ β ν µ ITC Zapf Dingbats—ITC Zapf Dingbats, also designed by Hermann Zapf, is a typeface of whimsical characters with a wide variety of uses. 3-12 QMS 1725E Print System Reference...
Page 35: Page Design
Page Design Page Design One rule to remember when designing documents is to keep it sim- ple. Avoid cluttering your documents with unnecessary font changes, which can detract from the document. Consider your reader first. Select the typeface that is best for your particular document, and consider the meaning of your words.
Page 36 West Orange, NJ: Pipeline Associates. ISSN 0891-5873. Smith, Ross. Learning PostScript: A Visual Approach . Berkeley: Peachpit Press, 1990. ISBN 0-938151-12-6. White, Jan V. Graphic Design for the Electronic Age . New York: Watson-Guptill, 1988. ISBN 0-8230-2122-X. 3-14 QMS 1725E Print System Reference...
Page 37: Printer Configuration
Printer Configuration In This Chapter . . . Methods of configuration Configuration menu Operator control menu Administration menu Installation menu...
Page 38: Introduction
The rest of the chapter provides basic printer configuration informa- tion about some of the configuration menu options. The QMS Crown- Net Interface System Administrator’s Guide (shipped with your printer) contains the CrownNet submenu configuration information for the Ethernet interface.
Page 39: Using Ps Executive Series Utilities
See the QMS Crown Technical Reference man- ual (shipped on disk with your printer) as well as the QMS Crown Document Option Commands manual, and the HP PCL5 Emulation Technical Reference (both available for purchase from your QMS vendor), for information on these commands.
Page 40: Using A Remote Console
The Operator Control menu may be password protected with an optional security card if the system administrator does not want users changing defaults. QMS 1725E Print System Reference...
Page 41: Accessing The Configuration Menu
Note: For information on printer-host communication using the Ethernet interface or any options under the CrownNet submenu (Administration/Communications/Network 2/CrownNet), see chapter 2, “Printer Configuration,” in the QMS CrownNet Interface System Adm inistrator’s Guide Installation Menu Use this menu to establish passwords for the Operator Control and Administration menus.
Page 42: Selecting Configuration Menu Options
Access the Administration menu ADMINISTRATION COMMUNICATIONS Select Access the Communications menu. COMMUNICATIONS TIMEOUTS Next Advance to the Communications/Parallel COMMUNICATIONS menu. PARALLEL Select Access the Parallel menu. PARALLEL MODE Next Advance to the Parallel/Emulation menu. PARALLEL EMULATION QMS 1725E Print System Reference...
Page 43: Changing Character Information
Configuration Menu Select Access the Emulation menu. EMULATION Previous Advance to the Emulation/PostScript EMULATION menu. POSTSCRIPT Select Select PostScript as the default POSTSCRIPT emulation. IS SELECTED After 3 seconds you are returned to the PARALLEL Parallel/Emulation menu. EMULATION Online/ Exit from the menu (Online/Offline) or SAVE CHANGES? Offline or return to the previous menu (Menu).
Page 44 The message window reads... Online/ Turn off the Online/Offline indicator and IDLE Offline readies the printer for configuration. Menu Access the configuration menu. CONFIGURATION OPERATOR CONTROL Next Advance to the Administration menu. CONFIGURATION ADMINISTRATION QMS 1725E Print System Reference...
Page 45 Configuration Menu Select Access the Administration menu ADMINISTRATION COMMUNICATIONS Next Advance to the Communications/ COMMUNICATIONS Emulation menu. EMULATIONS Select Access the Emulations menu. EMULATIONS ESP DEFAULT EMUL Next Advance to the Emulations/HP-GL menu. EMULATIONS HP-GL Select Access the HP-GL menu. HP-GL PLOTTER Next...
Page 46: Saving Configuration Changes
Canceling Configuration Changes If you change a configuration option and then decide to cancel that change, you can do so when exiting the configuration menu. 4-10 QMS 1725E Print System Reference...
Page 47: Setting The Message Window Language
Configuration Menu Example To cancel your configuration changes, press the control panel keys in the order shown in the following table. The printer responds by dis- playing a status message in the message window. Press this to... The message window reads... Online/ Exit from the menu (Online/Offline) or SAVE CHANGES?
Page 48: Restoring The Factory Default Configuration
Menu Operator Control/Copies Choices 001-999 Default Notes Sets the default number of copies for all subsequent print jobs. 4-12 QMS 1725E Print System Reference...
Page 49: Collation
Operator Control Menu Collation Use this option if you have 12 MB of memory or a hard disk installed to arrange multiple copies of a document in sequential order. This option helps to reduce network traffic. Menu Operator Control/Collation/ Choices On, Off Default Notes...
Page 50: Outputbin
Letter, Legal, A4, Executive, Com9, Com10, DL, Monarch, and Envelope (see notes) Default Letter Notes The Envelope setting should be used if your envelope size doesn’t match any of the other listed envelopes sizes. 4-14 QMS 1725E Print System Reference...
Page 51: Def. Duplex
Administration Menu Def. Duplex The Def[ault] Duplex option allows you to print on the front and back of each page. Menu Operator Control/Def. Duplex Choices On, Off Default Notes This is an optional feature and supported only if the duplexing unit and enough memory are installed.
Page 52: Communications
When a print job is sent from a Macintosh, the PS Wait timeout is automatically changed to 00300 (5 min.). Large print jobs, such as those generated by graphics or computer-aided design applications, require timeouts of 00300 (5 min.). 4-16 QMS 1725E Print System Reference...
Page 53: Setting Serial Interface Parameters
Communications Setting an Emulation Timeout The emulation timeout is the maximum number of seconds emula- tions other than PostScript (such as HP-GL, HP PCL5, and Line- printer) wait for incoming data. Menu Administration/Communications/Timeouts/Emul Timeout Choices 00000-99999 Default 00005 (5 sec.) Notes A value of 000 is the same as infinity (no timeout).
Page 54 Other optional emulations also appear, if installed. Default Minimum Number of Kilobytes for Spooling Sets the minimum number of kilobytes of system memory allocated to the serial interface. Menu Administration/Communications/Serial/Min K Spool Choices 00000-99999 Default 00015 4-18 QMS 1725E Print System Reference...
Page 55 QMS EOD—The printer recognizes only the QMS %%EndOfDocument command. HP EOD—The printer recognizes only the HP <ESC>%12345X command. Default None Notes See chapter 5, “Additional Technical Information,” for details on how to implement this feature on your QMS 1725E Print System. Printer Configuration 4-19...
Page 56 The printer’s parity setting must match that of the host or application. Use the Administration/Communications/Serial/Ignore Parity menu to specify how the printer handles parity errors. Ignore Parity Errors Specifies how the printer should handle parity errors. Menu Administration/Communications/Serial/Ignore Parity 4-20 QMS 1725E Print System Reference...
Page 57 Communications Choices Off—Ignore parity errors. The printer prints its best interpretation of the character(s) affected by the error. On—Don’t ignore parity errors. The printer replaces the character(s) affected by the error with a question mark. Default Notes Use the Administration/Communications/Serial/Parity menu to set parity.
Page 58 RTS and CTS must be set to On, and the cable pinouts must be connected as shown in appendix B, “Technical Specifications.” PS Protocol Sets the binary communications protocol (BCP) for communicating over a serial interface to a PostScript printer. Menu Administration/Communications/Serial/PS Protocol 4-22 QMS 1725E Print System Reference...
Page 59: Setting Parallel Interface Parameters
Communications Choices Normal—Enable standard, ASCII hex protocol. Data is sent and received in ASCII format. This mode is recommended if you do not print binary data. It was designed for data in the printable ASCII range. Print jobs can alter the PS protocol value through PostScript operators.
Page 60: Emulation
You can either let the printer restart automatically after you save the change and exit the configuration menu, or you can wait for the change to take effect the next time you manually turn on the printer. 4-24 QMS 1725E Print System Reference...
Page 61 QMS EOD—The printer recognizes only the QMS %%EndOfDocument command. HP EOD—The printer recognizes only the HP <ESC>%12345X command. Default None Notes See chapter 5, “Additional Technical Information,” for details on how to implement this feature on your QMS 1725E Print System. Printer Configuration 4-25...
Page 62 Binary Fixed—Enable binary communications protocol. Print jobs can not alter this value through PostScript operators. Data in the printable ASCII range also prints. Default Normal Notes See chapter 5, “Additional Technical Information,” for a full discussion of PS Protocol. 4-26 QMS 1725E Print System Reference...
Page 63: Setting Network 2 Options
Communications Setting Network 2 Options CrownNet For information on options and defaults found in this submenu, see chapter 2, “Printer Configuration,” in the QMS CrownNet Interface System Administrator’s Guide . PS Protocol Sets the binary communications protocol (BCP) for communicating over a parallel interface to a PostScript printer.
Page 64: Emulations
Administration/Communications menu. Setting an ESP Default Emulation The emulation sensing processor (ESP) feature of the QMS 1725E Print System analyzes incoming print jobs and identifies which emula- tion the printer will use. The ESP Default Emul sets the ESP default...
Page 65: Setting Postscript Parameters
HP PCL5 Emulation Technical Reference (available for purchase from your QMS vendor) contain more detailed informa- tion on this emulation. In addition, HP PCL5C Technical Support Notes , available free through the QMS Bulletin Board, Q-FAX, and Printer Configuration 4-29...
Page 66 Emulations CompuServe, has information on HP PCL5C. (See appendix A, “QMS Customer Support,” to find out how to access the bulletin board, Q-FAX, and CompuServe.) In addition, appendix C of this guide has information on the PCL5 Document Option Commands.
Page 67 Emulations Notes Not all symbol sets are available with certain resident fonts. The Desktop, PS Math, Math 8, Microsoft-Pub, Pi-Font, PS- Text, Ventura-Intl, Ventura-Math, Ventura-US, and Windows symbol sets cannot be used with the resident bitmap fonts Courier 10, Courier 10 Italic, Courier 10 Bold, Courier 12, Courier 12 Italic, Courier 12 Bold, and LinePrinter.
Page 68 If the font is not scalable or if a bitmap font is specified, this setting is ignored. Retain Temporary Fonts and Macros Allows you to choose whether to retain temporary HP PCL5 fonts and macros at the end of each print job. Menu Administration/Emulations/HP PCL 5/Retain Temporary 4-32 QMS 1725E Print System Reference...
Page 69 Emulations Choices Off—Reset PCL to its default state at the end of each PCL print job, execute an implicit <ESC>E at the start and end of the job, and delete any temporary fonts, macros, and patterns. On—Reset PCL to its default state at the end of each PCL print job.
Page 70 Choices Off—Emulate a color plotter (8 pens). Since a monochrome print system has only 2 pen colors (black and white), grayscale patterns are substituted for other colors. On—Emulate a monochrome plotter (2 pens). Default 4-34 QMS 1725E Print System Reference...
Page 71 Emulations Notes When set to off, this option maps pen colors as follows: Pen 0=White, Pen 1=Black, Pen 2=Red, Pen 3=Green, Pen 4=Yellow, Pen 5=Blue, Pen 6=Magenta, Pen 7=Cyan. When set to on, this option tells the printer to map each pen to its assigned color, then convert the color to a grayscale using the National Television System Committee (NTSC) color standard for luminosity coefficients (Additive System):...
Page 72: Setting Hp-Gl Parameters
Emulations Setting HP-GL Parameters Fifteen configuration choices are available. The QMS Crown Techni- cal Reference (shipped on disk with your printer) contains more detailed information on this emulation. Plotter Identifies the HP-GL plotter type. Menu Administration/Emulations/HPGL/Plotter Choices 7550A, 7475A, 7470A, Colorpro...
Page 73 Emulations Reverse Image Determines whether an image is printed in reverse. Menu Administration/Emulations/HPGL/Reverse Image Choices On—Print a white image on a black background. Off—Print a black image on a white background. Default Enhanced Mode Increases the resolution of a downloaded character. Menu Administration/Emulations/HPGL/Enhanced Mode Choices...
Page 74 The HP-GL emulation senses the media size when the Paper Type is set to Scale to Paper or when it is set to a particular media size through the control panel or through a QMS Document Option Command. Paper Type Identifies the original image’s paper size.
Page 75: Setting Lineprinter Parameters
HP-GL emulation color encoding equation. Setting Lineprinter Parameters Twelve configuration options are available. The QMS Crown Techni- cal Reference (shipped on disk with your printer) has more informa- tion on each of these options. Printer Configuration...
Page 76 Administration/Emulations/Lineprinter/Character Map Choices ASCII, EBCDIC Default ASCII Line Numbering Specifies if a five-digit number is to be prefixed to the beginning of each line. Menu Administration/Emulations/Lineprinter/Line Numbering Choices On—Number all lines. Off—Don’t number lines. Default 4-40 QMS 1725E Print System Reference...
Page 77 Emulations Tab Stops Specifies the number of spaces between tab stops. Menu Administration/Emulations/Lineprinter/Tab Stops Choices 0-256 Default Line Feed is Carriage Return-Line Feed Specifies whether each line feed (LF) in the print job is translated to a carriage return/line feed (CRLF) combination. Menu Administration/Emulations/Lineprinter/LF is CRLF Choices...
Page 78 Margins Defines the left, right, top, and bottom margins in 1/100" increments. Menu Administration/Emulations/Lineprinter/Margins Choices Bottom 0-1700 (0"-17.00") Left 0-1700 (0"-17.00") Right 0-1700 (0"-17.00") 0-1700 (0"-17.00") 4-42 QMS 1725E Print System Reference...
Page 79: Special Pages
Special Pages Use the Administration/Special Pages menu to print special pages, such as status pages, header pages, and trailer pages. See the QMS Crown Document Option Commands manual (available for purchase from your QMS vendor) for detailed information on the contents of these special pages.
Page 80 A header page is a separator page that prints before a print job to help users sort their jobs. The information on the header page can be customized. See the QMS Crown Document Option Commands man- ual (available for purchase from your QMS vendor) for more informa- tion. Enabling/Disabling Header Pages...
Page 81: Working With Trailer Pages
Default See the QMS Crown Document Option Commands manual Notes (available for purchase from your QMS vendor) for more information. Identifying a Trailer Page Input Source You can select the input bin (tray or cassette) from which the printer pulls media when printing the trailer page.
Page 82: Printer Start-Up Options
Notes This file does not print. Information on creating a SYS\START file is available in the QMS Crown Technical Reference Manual (shipped on disk with your printer) and also via Q-FAX (see appendix A, “QMS Customer Support,” for information on using Q-FAX).
Page 83: Loading The Postscript Error Handler
Memory Loading the PostScript Error Handler Error Handler is a diagnostic tool that identifies PostScript errors encountered during a print job. Menu Administration/Startup Options/Do Error Handler Choices Yes—Load the Error Handler. No—Don’t load the Error Handler. Default Notes Refer to the PostScript Language Reference Manual (Adobe Systems Incorporated, Reading, PA: Addison-Wesley, 1990, ISBN 0-201-18127-4) for more information on PostScript errors.
Page 84: Postscript Heap
PostScript Fonts The K Mem for PS Fonts, is the listed on the status page as Font Cache, number of kilobytes of RAM dedicated to caching previously scaled 4-48 QMS 1725E Print System Reference...
Page 85: Emulation
Memory bitmap representations of fonts for the PostScript emulation inter- preter. Menu Administration/Memory/K Mem for PS Fonts Choices 00088-08192 Default 00116 Notes This memory setting can reduce the number of times a PostScript font must be converted from outline form to bitmap form, thus reducing processing time.
Page 86: Display List
Menu Administration/Memory/K Mem Disk Cache Choices 00032-08192 Default 00036 4-50 QMS 1725E Print System Reference...
Page 87: Frame Buffer
Memory Notes If the Intellifont SIMM is installed and your printer has 12 MB of memory or less, the Disk Cache size must be set to 48 KB before the printer will recognize the Intellifont SIMM. If your printer has more than 12 MB of memory, the Disk Cache will automatically be set to the required amount.
Page 88: Printer Memory
When this client's memory is exhausted, the printer slows down, and the hosts are forced to wait. Menu Administration/Memory/MB Printer Mem Choices 00012-00064 Default Depends on the amount of memory installed. 4-52 QMS 1725E Print System Reference...
Page 89: Enable Disk Swap
Memory Notes This memory client is not user-configurable. If disk swapping is enabled (Administration/Memory/Enable Disk Swap menu), the amount of memory displayed is larger than the actual amount of memory installed in the printer. » Note: Memory that is added to the printer goes into a shared pool that is split between K Mem Display and K Mem Framebuff.
Page 90: Printer Engine Features
Administration/Engine/Image Alignment option to align the image horizontally and vertically in pixel incre- ments (1/300" or 0.08 mm). » Note: Engine constraints may limit the accuracy of pixel alignment. 4-54 QMS 1725E Print System Reference...
Page 91: Setting Default Paper
Printer Engine Features Horizontal Offset Menu Administration/Engine/Image Alignment/Horiz Offset Choices 000-300 (0.00"/0 mm-1.00"/25.4 mm) Default 100 (0.33"/.84 mm) Notes Values above 100 move the image to the right. Values below 100 move the image to the left. Vertical Offset Menu Administration/Engine/Image Alignment/Vertical Offset Choices 000-300 (0.00"-1.00")
Page 92: Setting Outputbin X Name
This option sets the print engine’s gamma correction. Menu Administration/Engine/Gamma Correction Choices On, off Default Notes Gamma correction “on” produces optimum print quality for halftones. For information on gamma correction, see chapter 5, “Additional Technical Information,” in this guide . 4-56 QMS 1725E Print System Reference...
Page 93: Enabling/Disabling The Warning Buzzer
Printer Engine Features Enabling/Disabling the Warning Buzzer You can enable or disable the warning buzzer the print engine sounds when it encounters an error (such as paper out). Menu Administration/Engine/Buzzer Choices On, Off Default Specifying Page Recovery Action When a media jam or other similar error occurs, the printer can reprint the job starting from the page on which the jam occurred.
Page 94: Setting Manual Feed Timeout
Letterhead paper must be loaded face down in the input bin with the bottom edge inserted first into the printer. You may notice a decrease in the printing speed depending on the mix of simplex and duplex pages. 4-58 QMS 1725E Print System Reference...
Page 95: Miscellaneous
Miscellaneous Miscellaneous The Miscellaneous submenu allows you to change printer configura- tions, such as defaults and message window language. Restoring the Factory Default Configuration If you need to cancel all of the configuration changes you have made, you can reset all of the configuration settings to their factory defaults. Menu Administration/Miscellaneous/Restore Defaults Choices...
Page 96: Setting The Message Window Language
: If you connect to this printer an external hard disk you previously Caution used with an earlier QMS Crown printer (QMS 860, QMS 860 Plus, QMS 1060, QMS 1060E, QMS 1660, QMS 1660E, QMS-PS 1700, QMS 1725, QMS-PS 2000, QMS 2025, QMS-PS 3200, or QMS 3225, QMS 4525,...
Page 97: Installing An Optional Font
Hard Disks Installing an Optional Font Use the Administration/Disk Operations/Install Options menu to add optional fonts to the hard disk from a font card. This selection copies data from the card to the hard disk. See chapter 6, “Printer Options,” for instructions.
Page 98: Installation
This represents the password used to enter the Administration menu when enabled. Menu Installation/Admin Password Choices Up to 16 alphanumeric characters Default Blank (no password) Notes Enable the password in the Installation/Use Admin Pwd menu. 4-62 QMS 1725E Print System Reference...
Page 99: Use Admin Password
Configuring Optional Features Use Admin Password Determines if a password is required to enter the Administration menu. Menu Installation/Use Admin Pwd Choices On—Require a password to enter the Administration menu. Off—Don’t require a password to enter the Administration menu. Default Notes Enter the password in the Installation/Admin Password menu.
Page 101: Additional Technical Information
Additional Technical Information In This Chapter . . . The Emulation Sensing Processor (ESP) Simultaneous Interface Operations (SIO) Communication modes Gamma correction Memory End job mode IEEE 1284 bidirectional parallel interface modes PS Protocol option...
Page 102: Introduction
(number of cop- ies, page margins, fonts). The QMS 1725E Print System prints almost any file sent in an emula- tion ESP technology understands, whether you have one, two, or more hosts, and whether you are communicating through a parallel, serial, Ethernet or optional LocalTalk interface.
Page 103: Simultaneous Interface Operations (Sio)
LocalTalk interface uses only PostScript.) Advanced users can also use PostScript operators to reconfigure printer ports. The QMS Crown Technical Reference contains informa- tion about PostScript operators. Generally, it is best to keep your printer in ESP mode. Since ESP mode is the factory default, all you have to do to use it initially is connect your host and printer and then send a file.
Page 104: Terms
A halftone is a printed copy of a scanned image as a set of tiny, evenly spaced spots of variable diameter that, when printed, visually blur together to appear as shades of gray. Your QMS 1725E Print System creates halftone cells by mapping each gray level onto a col- lection of dots.
Page 105: Gamma Correction Concept
53 lpi. This typically allows 33 different levels of gray. You can change screen frequency through your application or by using the PostScript setscreen operator. The QMS Crown Technical Reference Manual contains information on setscreen. The extra gray levels available through higher resolution provide a smoother shift from the darkest black to very light grays while higher resolution provides sharper image outlines.
Page 106 PostScript settransfer operator. (See your drawing application documentation, the QMS Crown Technical Reference Manual , and the PostScript Language Reference Manual for more information.)
Page 107: Qms Memory Management
(or “block”) of memory. Each memory client is dedicated to a specific printing and application purpose. Your QMS 1725E Print System allows you to distribute its memory among the various memory clients where it can best serve your specific printing needs.
Page 108: Memory Terms
Memory Terms Before you can configure your printer's memory efficiently, you must first understand the different types of memory and how they work together. Your QMS 1725E Print System documentation uses the fol- lowing memory terms: Memory Memory allows your printer to store and retrieve information. It’s the space within your printer where information is stored while being actively worked on.
Page 109 ROM (Read Only Memory) ROM contains data and/or machine-executable instructions that can be read but not modified. On your QMS 1725E Print System, the operating system code, resident fonts, and resident emulations are stored in ROM. This information is not lost when the printer’s power is turned off.
Page 110: Evaluation Of Your Printing Environment
Flash ROM Quick loading, reprogrammable memory that holds information even when the printer is turned off is known as flash ROM. Your QMS 1725E Print System has flash ROM available to hold system code and future system upgrades. The chief advantage of flash ROM is...
Page 111 Memory control the unused features and assign it to other clients that need additional memory. Evaluation Questions To get a better idea of what your printing requirements and your printer’s capabilities are, answer the following questions: How much RAM does your printer have (standard and additional memory)? Do you have the option of installing additional memory if it’s needed?
Page 112: Memory Clients
Menu options allow you to specify the largest media size you plan to use for each resolution. Memory is then automatically allocated to the clients that require it. 5-12 QMS 1725E Print System Reference...
Page 113 Memory » Note: The printer does not allow you to choose features that do not work with the amount of memory currently installed. Using this option does not change the media size. It just ensures that you have enough memory allocated to the appropriate clients to print on the requested media size.
Page 114 Memory The amount of memory required for each compressed block is printer specific. The QMS 1725E Print System takes approximately 32 KB of memory from the display list for each compressed block. However, if a page includes raster image data (for example, TIFF or bitmap data), each compressed block requires much more memory.
Page 115 Memory PS Heap Also known as K Mem PSHeap, Heap, PostScript VM, and Virtual Memory, this client holds downloaded fonts, PostScript operators, and forms. Inefficiently coded PostScript jobs can consume an extremely large amount of virtual memory or leave objects in the PostScript heap after the print jobs are completed, leading to virtual memory errors.
Page 116 Conversely, if no hard disk is used, the disk cache should be set to 36 KB until a hard disk is 5-16 QMS 1725E Print System Reference...
Page 117 Memory installed. However, when one or more hard disks are installed, they are not available until the disk cache client is increased. The amount of memory needed for the disk cache client is dependent on the size of the disk, the number of disks, the number of subdirecto- ries on each disk, and the amount of memory dedicated to caching.
Page 118: Hard Disk Management
Hard Disk Management You can add one internal hard disk and up to three external hard disks to your QMS 1725E Print System. These hard disks serve as secondary storage places for such items as downloaded fonts, emu- lations, and spooled data.
Page 119: End Job Mode
EOD command between each job, the serial and parallel protocols may be unable to detect an end of job automatically. So the End Job Mode feature on QMS Crown printers was designed to allow you to set the end of document for print jobs being sent through these proto- cols.
Page 120: Using The Eod Commands
EOD automatically, due to a lack of an EOD command in some printer languages, you can insert an EOD command at the end of your file to tell the printer where your print job ends. QMS Crown printers recog- nize two end-of-document commands: QMS EOD and HP EOD.
Page 121: Setting The End Job Mode For The Serial And Parallel Protocols
EOD command between each print job. See your QMS vendor for more information on this type of program. PC Print Server Set the end job mode from the printer’s control panel.
Page 122: Setting The End Job Mode Via The Control Panel
End Job Mode your print queuing system documentation, your network administra- tor, or your QMS vendor for more information. Setting the End Job Mode via the Control Panel Use the following procedure to set the end job mode from the printer’s...
Page 123: Adding An Eod Command To Your File
<CR><LF> HP EOD <ESC>%-12345X » Note: The <CR><LF> sequence following the %%EndOfDocument line for the QMS EOD is necessary to avoid an INPUT IDLE message remaining in the printer message window after the document finishes printing. Additional Technical Information 5-23...
Page 124: Creating A Network Job Separator
End Job Mode When the QMS EOD or the HP EOD is set, the printer does not rec- ognize the Ctrl-D EOD command. Add your organization's standard EOD command to the end of your print file, or add it to a separate file.
Page 125: Parallel Interface Modes
The network job separator is accessed with each print job, so this ensures that network job separation is enforced. See QMS Crown Network Notes for more information on how to create a network job separator for several commonly used networks.
Page 126: Compatibility Mode
PS Protocol Option Your QMS 1725E Print System supports PS Protocol, a new protocol for communication between the printer and a host computer over the serial, parallel, and optional interfaces. This binary communications...
Page 127 PS Protocol Option communications protocol to distinguish between the special control characters and print job binary data. To differentiate data from the special control characters, any data that is the same as one of the following special control characters must be quoted.
Page 128: Options
Quoted Binary. However, a data stream sent through an optional network interface using Quoted Binary is not treated the same as a data stream sent through the same interface using Binary. 5-28 QMS 1725E Print System Reference...
Page 129: Advantages
See your QMS vendor for any avail- able information on device drivers or binary filter programs.
Page 130 CMYK Value C (96) M (128) Y (224) K (0) [(96*0.3) + (128*0.59) + (224*0.11) + 0] ÷ 255 = [(28.80) + (75.52) + (24.64) + 0] ÷ 255 = 50% 5-30 QMS 1725E Print System Reference...
Page 131: Printer Options
Printer Options In This Chapter . . .
Page 132: Introduction
Introduction Introduction QMS 1725E Print System Reference...
Page 133: The Envelope Feeder
Additional Paper Cassettes Additional Paper Cassettes The Envelope Feeder Selecting Envelopes Installing the Envelope Feeder Printer Options...
Page 134 Turn the printer power switches off and remove the upper paper cassette. Remove the envelope feeder slot-cover located above the upper paper cassette slot by pushing it in and then down. Replace the cover of the upper cassette with the special paper cassette cover. QMS 1725E Print System Reference...
Page 135 The Envelope Feeder Reinstall the upper paper cassette in the printer. Take the envelope feeder in both hands, line up the position- ing arms with the openings in the printer and insert the enve- lope feeder as far as it goes. Positioning Arms Printer Options...
Page 136 Note: Arrange the envelopes so that they press lightly against the envelope feed guides. Do not adjust the guides too tightly; otherwise, a jam may occur. Close the envelope feeder cover. 10 Turn the printer power switches back on. QMS 1725E Print System Reference...
Page 137: Duplexer Assembly
Duplexer Assembly 11 Configure your printer for envelope printing through the control panel. Duplexer Assembly 300 dpi 600 dpi Paper Size Simplex Duplex Simplex Duplex Letter 12MB Legal 12MB 16MB 12MB Executive 12MB Installing the Duplexer Assembly Printer Options...
Page 138 Loosen the screw on the metal plate in the lower paper cas- sette slot with a Phillips screwdriver. Insert a finger or a screwdriver in the hole and slide the catch to the left as far as it goes while lifting the plate upward. QMS 1725E Print System Reference...
Page 139 Duplexer Assembly Pull the plate to the right and toward you to remove it from the slot. Remove the two screws on the duplexing unit slot-cover. Push in a little on the right edge of the duplexing unit slot- cover to unlock it. Then, slide the cover off to the right. Printer Options...
Page 140 Remove the four screws holding the inner cabinet in place, and pull out the inner cabinet. Insert the duplexing unit into the printer as shown. 10 Replace the four screws that were removed in step 8. 6-10 QMS 1725E Print System Reference...
Page 141: Font And Emulation Cards
IDLE Font and Emulation Cards : Your printer supports only QMS PCMCIA cards. These cards are not Caution backward compatible with previously released QMS printers, and cards for previous printers are not compatible with your printer.
Page 142 Put the printer back on line. » Note: If you are using an application, make sure the printer driver installed supports the fonts in the card. If not, contact your application manufacturer for support. 6-12 QMS 1725E Print System Reference...
Page 143: Security Card
Security Card QMS Crown Document Option Com- mands Security Card : The printer must be off line (the Online/Offline indicator should be Caution off) before you insert or remove cards. Press the Online/Offline key to turn the indicator off. If you forget to take the printer off line before inserting or removing a card, turn the printer power off and back on to regain access to the data stored in the printer's memory.
Page 144 Then press Select. Remove the secu- rity card from the card slot and put the printer back on line. ENTER PASSWORD INVALID PASS- WORD » Note: Password protection does not prevent software commands from changing functions. 6-14 QMS 1725E Print System Reference...
Page 145: Removing And Re-Installing The Tray Assembly
Removing and Re- installing the Tray Assembly Removing and Re-installing the Tray Assembly : It's very important to protect the printer tray assembly from Caution electrostatic damage while performing this task. in your printer option kit, attach If an anti-static wrist strap is provided one end of it to your wrist and the other end to any convenient electrical ground (for example, the bare metal chassis of equipment, as on the back of a computer, that is plugged in...
Page 146 Remove the two screws on each end of the side panel by turning the screws counterclockwise to remove the side panel. Remove the five screws on the metal tray assembly cover. Remove the metal cover revealing the tray assembly. 6-16 QMS 1725E Print System Reference...
Page 147 Removing and Re- installing the Tray Assembly Unplug the two connectors on the tray assembly. Connectors Remove the tray assembly screw located to the right of the fan to release the tray assembly. Printer Options 6-17...
Page 148 Caution: Do Not continue lifting the tray assembly of the printer. After the tray assembly has been lifted over the safety catches, allow the tray to return to a level, horizontal position. Then pull the tray assembly straight out. 6-18 QMS 1725E Print System Reference...
Page 149: Re-Installing The Tray Assembly
Removing and Re- installing the Tray Assembly Re-installing the Tray Assembly : It's very important to protect the printer tray assembly from CAUTION electrostatic damage while performing this task. in your printer option kit, attach If an anti-static wrist strap is provided one end of it to your wrist and the other end to any convenient electrical ground (for example, the bare metal chassis of equipment, as on the back of a computer, that is plugged in...
Page 150: Memory Modules (Simms)
Information,” for more information on memory distribution. Installing a SIMM » Note: The following instructions are written for the system administrator. Do not attempt this procedure if you have no experience working with circuit boards. 6-20 QMS 1725E Print System Reference...
Page 151 Memory Modules (SIMMs) : It's very important to protect the printer tray assembly from Caution electrostatic damage while performing this task. in your printer option kit, attach If an anti-static wrist strap is provided one end of it to your wrist and the other end to any convenient electrical ground (for example, the bare metal chassis of equipment, as on the back of a computer, that is plugged in ).
Page 152 Tilt the SIMM up to a 90° angle until you feel it snap into place. Repeat steps 2 through 4 for each additional SIMM you are installing. Return the tray assembly to the printer by following the instructions in “Re-installing the Tray Assembly,” earlier in this chapter. 6-22 QMS 1725E Print System Reference...
Page 153: Removing A Simm
Intellifont SIMM Removing a SIMM » Note: SIMM connector 0 (DRAM 0) must always have a SIMM installed. If you have not already done so, access the tray assembly by following the instructions in “Removing the Tray Assembly,” earlier in this chapter. Using the release latch located on each side of the SIMM connector, release the SIMM.
Page 154: Installing The Intellifont Simm
Redischarge your body each time after walking around and before touching the printer tray assembly again. Access the printer tray assembly. Position the tray assembly so the interface panel is on your right. Remove the SIMM from the anti-static bag. 6-24 QMS 1725E Print System Reference...
Page 155 Intellifont SIMM Insert the SIMM into the SIMM connector. Notch Snap the SIMM into place. Re-install the tray assembly and covers. Printer Options 6-25...
Page 156: Increasing The Disk Cache Size
If necessary, use the Administration/Special Pages/Status Page Type menu to change the default Standard setting to Advanced. Print an Advanced Status Page (Administration/Special Pages/Status Page Type selection, followed by Administra- tion/Special Pages/Print Status). Font List 6-26 QMS 1725E Print System Reference...
Page 157 Intellifont SIMM Serif Fonts Courier Medium Courier Italic Medium Courier Bold Courier Italic Bold Times Roman Medium Times Roman Italic Medium Sans Serif Fonts Printer Options 6-27...
Page 158: Accessing The Fonts
Access the Administation/PCL5/Default Font menu. Choose the Select by Index option. Access the Administration/PCL5/Default Font Idx menu. Identify the appropriate font selection index. Save your changes and put the printer back on line. 6-28 QMS 1725E Print System Reference...
Page 159: Installing Optional Interfaces
Installing Optional Interfaces Installing Optional Interfaces Installing an Optional Interface Card and Daughterboard » Note: The following instructions are written for the system administrator. Do not attempt this procedure if you have no experience working with circuit boards. Printer Options 6-29...
Page 160 Access the tray assembly by following the “Removing the Tray Assembly” procedure found earlier in this chapter. Remove the optional I/O metal plate located to the right of the standard interface ports by removing the screw on each end of the plate. 6-30 QMS 1725E Print System Reference...
Page 161 Installing Optional Interfaces Snap the two plastic feet to the bottom side of the interface board on the opposite end from the interface connection Note: Your optional interface card may look different than the one shown in the illustration. Peel the tape from the bottom of the plastic feet With the plastic feet facing down, insert the interface card through the connector opening in the metal plate from the outside of the tray assembly.
Page 162 Note: Your optional interface card may look different than the one shown in the illustration. Ejector latches Take the plastic ribbon cable and fold it over so that the notches (keys) face upward on both connectors. Slide the 6-32 QMS 1725E Print System Reference...
Page 163 Installing Optional Interfaces ribbon cable connectors onto the interface card connector and the controller board connector. 10 Install the two mini support posts in the two holes on the controller board. 11 Snap the daughterboard on the two mini support posts and the two 48-pin connectors.
Page 164: Using A Localtalk Interface
Using a Network Interface 12 Return the tray assembly to the printer by following the instructions in “Re-installing the Tray Assembly,” earlier in this chapter. Using a Network Interface Using a LocalTalk Interface 6-34 QMS 1725E Print System Reference...
Page 165 Using a LocalTalk Interface Hardware Macintosh Interface Cabling Making the Connection : Turn off both the printer and the Macintosh before making the Caution connection. Plug the connector from one transformer box into the printer’s LocalTalk port. Printer Options 6-35...
Page 166: Software
Put terminating resistors in all open sockets in the connec- tor boxes. Turn on the printer. Software Printing from the Macintosh However PS Executive Series printer utilitie LaserWriter 8. and the 1725 PPD file 6-36 QMS 1725E Print System Reference...
Page 167 Using a LocalTalk Interface Application-specific printer files Installing the Printer Utilities With the Macintosh on, insert the Macintosh Format PS Executive Series Utilities disk in the disk drive. Double-click the PSExec3. .sea file. In the window that appears, choose Continue. In the window that appears, specify a folder in which to install the utilities and choose Save.
Page 168 Open the PPDs folder inside the Drivers folder in the PSExec Folder. Open the Ver 4.1 folder inside the PPDs folder. Select the QMS 1725 printer description file in the Ver 4.1 folder and drag it to the Printer Descriptions folder you cre- ated in step 4.
Page 169 Using a LocalTalk Interface 13 Choose Select. Now you can access printer features by choosing Options in the Print dialog box. Choose Help in the Options dialog box for information on these options. Installing Printer Description Files » Note: The application (PageMaker, FreeHand, PrePrint, Separator, or QuarkXPress) should be installed before you install the printer description file(s).
Page 170: Testing Macintosh Communication
Using a LocalTalk Interface Testing Macintosh Communication Display a disk or folder window. Set up page information. Print a directory or a window. Operation Reference Setting LocalTalk Interface Parameters 6-40 QMS 1725E Print System Reference...
Page 171 Using a LocalTalk Interface Mode Administration/Communications/LocalTalk/Mode Menu Enabled—Establish one-way LocalTalk communication (from Choices the host to the printer). Disabled—Turn off the LocalTalk interface (the printer stops accepting LocalTalk interface print jobs). Enabled Default The printer must be restarted for changes to the Mode menu to Notes take effect.
Page 172 PostScript operators. Data in the printable ASCII range also prints. —Enables binary communications protocol. QBinary Fixed Print jobs cannot alter this value through PostScript operators. Data in the printable ASCII range also prints. 6-42 QMS 1725E Print System Reference...
Page 173 : If you connect to this printer an external hard disk you previously Caution used with an earlier QMS Crown printer (QMS 860, QMS 860 Plus, QMS 1060, QMS 1060E, QMS 1660, QMS 1660E, QMS-PS 1700, QMS 1725, QMS-PS 2000, QMS 2025, QMS-PS 3200, or QMS 3225, QMS 4525,...
Page 174 Redischarge your body each time after walking around and before touching the printer tray assembly again. Handle the tray assembly and disk drive carefully, and try to handle it by the edges only. 6-44 QMS 1725E Print System Reference...
Page 175 Hard Disks Access the tray assembly by following the instructions in “Removing the Tray Assembly,” earlier in this chapter. Connect the power cable and ribbon cable from the assem- bly kit to the hard disk connectors. » Note: The extra connector on the power cable is for future use and does not connect to anything at this time.
Page 176 Note: We recommend that when an internal hard drive is installed in the printer, it be given an address of DSK6. Refer to the “Identifying Hard Disks” section of this chapter for more information. External 6-46 QMS 1725E Print System Reference...
Page 177 : If you connect to this printer an external hard disk you previously Caution used with an earlier QMS Crown printer (QMS 860, QMS 860 Plus, QMS 1060, QMS 1060E, QMS 1660, QMS 1660E, QMS-PS 1700, QMS 1725, QMS-PS 2000, QMS 2025, QMS-PS 3200, or QMS 3225, QMS 4525,...
Page 178: Storage Options
WRITE ERROR encountered a write error, remove the message, and or there is no room for the restart the operation from the data on the hard disk or in beginning. RAM. Formatting a Hard Disk 6-48 QMS 1725E Print System Reference...
Page 179 Storage Options Using PS Executive Series Utilities Using the Printer Configuration Menu » Note: You may need to press the Next key one or more times to advance through the list of selections or options. Use this to... The message window reads...
Page 180: Fonts On The Hard Disk
DSK#: x Scrolls through the list of attached FORMAT DISK Next disks. DSK: x Selects the disk and accesses the card Select INSTALL SOURCE address from which the optional font is CAR#: x being installed. 6-50 QMS 1725E Print System Reference...
Page 181: Removing An Optional Font
Fonts on the Hard Disk Prompts you to insert the font card in Select INSTALL OPTION one of the card slots below the printer’s INSERT MEDIA media cassette. Begins reading data from the card and INSTALL OPTION installing the appropriate files on the READING DATA...
Page 182: Downloading An Emulation
Note: At least one hard disk (internal or external) must be installed on the printer before you can download an emulation. If more than one hard disk is available, the emulation automatically installs itself on the disk with the most free storage space. 6-52 QMS 1725E Print System Reference...
Page 183: Emulations On The Hard Disk
Emulations on the Hard Disk Procedure If necessary connect the PC to the printer’s parallel or serial port. Turn on the printer, and wait for to appear in the mes- IDLE sage window. Insert the emulation disk in your PC’s 3.5" disk drive, and change to that drive (for example, if you’re using the A drive, type a:↵...
Page 184: Removing A Printer Emulation
The hard disk then copies the contents of the card. When all of the contents are copied, press the Menu key to exit the menu. Press the Online/Offline key to allow the printer to receive data from the host. Removing a Printer Emulation 6-54 QMS 1725E Print System Reference...
Page 185: Kanji Fonts
Kanji Fonts Make sure the printer is on and idle. From the Administration menu, select the Disk Operations submenu. Press the Next key until displays. REMOVE OPTION Press the Select key. Press the Select key. Press the Select key. The hard disk then reads the contents of the card and the matching files are deleted from the hard disk.
Page 186: Hardware Requirements
The Japanese fonts are factory installed on a formatted hard Caution: disk drive. DO NOT reformat or initialize the QMS Kanji hard disk drive. Reformatting this drive erases all data, fonts, and files on the disk. The QMS Crown Kanji Option Kit warranty does not cover this error.
Page 187 Kanji Fonts the reserved settings of 7, 8, or 9. SCSI ID Connect the 25-pin end of the SCSI cable to the external SCSI port on the printer’s interface panel. 25-pin female Printer SCSI port Connect the 50-pin end of the SCSI cable to one of the Kanji SCSI interface ports.
Page 188: External Hard Disk Drive
Note: For the printer to recognize any attached hard disk(s), each hard disk must be turned on before you turn on the printer. DISK ONLINE appears on the start-up page if the printer recognizes the disk(s). 6-58 QMS 1725E Print System Reference...
Page 189: Configuring The Printer
This additional memory will also increase speed because additional memory is allocated to font caching. Procedure :If you have already reconfigured your QMS printer’s memory Caution: with settings specific to your print environment, do not use the Admin- istration/Memory/Frame Buffer simplified method. Instead print an advanced status page prior to changing them to the minimum Kanji settings, in case you need to return to your original memory settings.
Page 190 When you have changed all of the specified memory clients to their new settings, press the Menu key until the Online or Ready indicator lights. IDLE 6-60 QMS 1725E Print System Reference...
Page 191 Kanji Fonts Example » Note: This is an example of the control panel messages on a QMS 1725E Print System showing K Mem For PSHeap setting of 01328. Use this to... The message window reads... Advance to the Administration Memory...
Page 192: Updating System Software
Software Updating System Software QMS 1725E Print System » Note: The software loadable system mentioned in this section does not modify the code used by QMS Viking Interface cards. Administration/Miscellaneous/New Flash Image Menu Yes—Download new system code Choices No—Don’t download new system code...
Page 193 Fastest must be wired computer’s serial port to download 38400 baud (software as null modem method. or null modem available from QMS No additional adaptor Bulletin Board cables or attached. changes of port settings required. Procedure...
Page 194 Note: The new flash image will not erase the old image until the printer verifies that the new image is valid. Print another advanced status page, and verify that the con- figuration settings are the same. 6-64 QMS 1725E Print System Reference...
Page 195 Updating System Software Procedure PC Users Parallel and Serial Decompressing the System Software Create a new directory on your PC. Change to this directory. Insert the printer system software disk in your PC’s 3.5" disk drive. Type where is the name of the disk x :pkunzip x :system↵...
Page 196 Print another advanced status page, and verify that the con- figuration settings are the same. Downloading the System Software Serial Connect the serial cable to the printer. Download the DOS MODEX program available from the QMS Bulletin Board. Download a file hibaud.exe↵ Type to extract the MODEX files.
Page 197 Updating System Software Set the PC’s baud rate to 38400 by typing the following: modex.exe↵ modex # 38400 n 8 ↵ Access the Administration/Communication/Serial menu and set the Hardware Flow Control RTS and CTS values to On, press the Online/offline or Menu key and select yes to Save Changes.
Page 199: Qms Customer Support
QMS Customer Support In This Chapter . . . Sources of customer support QMS world-wide offices...
Page 200: Sources Of Support
In this case, the application manufacturer is the best source of help. Q-FAX Q-FAX, a QMS information retrieval service, provides application notes, technical support notes on common printing problems, and information about printer specifications, options, accessories, con- sumables, and prices.
Page 201: The Qms Corporate Bulletin Board System
QMS. You can access the QMS server via any one of the many web viewers available to Internet users. If you don’t have access to a web viewer, we recommend the NCSA Mosaic web viewer (Mosaic is at ftp.ncsa.uiuc.edu).
Page 202: Qms Customer Technical Assurance (Cta
Sources of Support QMS Customer Technical Assurance (CTA) QMS Customer Technical Assurance is available M-F, 7:00 am-6:00 pm, Central Standard Time, at (334) 633-4500 (US). You can also fax questions to CTA at (334) 633-3716 (US). Please indicate whether you would like a fax or a phone call.
Page 203: Qms National Service
Sources of Support QMS National Service The following numbers are valid in the US. To contact QMS in other countries, see the list of world-wide offices inthe following section. (800) 762-8894 Call for service information and maintenance pricing for repair of all QMS printers and printers of various other manufacturers.
Page 204: Qms World-Wide Offices
Offices in Ottawa, Québec City, Toronto, and Vancouver Europe, Middle Düsseldorf (49) 211/596 1333 East, Africa London (44) 1 784 442255 Maarssen (31) 3465 51 333 Paris (33) (1) 4107 9393 Stockholm (46) (8) 725 5680 QMS 1725E Print System Reference...
Page 205 Technical Specifications In This Chapter . . . Print engine specifications Controller characteristics Electrical and environmental requirements Physical characteristics Print media specifications Optional hardware Printer options and consumables Cable pinouts Warranty considerations...
Page 206: Print Engine Specifications
Microfine toner designed especially for high-resolution printers (EP-N cartridge); dry, single component in user- replaceable cartridge Toner Cartridge 8,000 pages at normal (5%) page coverage, letter or A4 Life paper Warm-Up Time Less than 5 minutes from cold start QMS 1725E Print System Reference...
Page 207: Controller Specifications
Controller Specifications Controller Specifications Emulations PostScript—Level 1 compatibility mode and Level 2 HP PCL 5 HP-GL 7475A/7550A Lineprinter CCITT Support for downloadable optional emulations Fonts 39 resident PostScript fonts that can be scaled from 4 points upward and rotated to any angle in 1° increments; all typefaces have multilingual character sets 7 resident bitmap HP PCL fonts in 25 symbol sets, 12 resident scalable HP PCL fonts in 35 symbol sets, and 1...
Page 208: Electrical Requirements
570-760 mm Hg Pressure Physical Characteristics Dimensions WxDxH 17.8" x 22.4" x 19.0" 454 mm x 570 mm x 483 mm Weight Approximately 97 lbs (44 kg) without cassettes and 106 lbs (48 kg) with cassettes installed QMS 1725E Print System Reference...
Page 209: Print Media Sizes
Print Media Print Media Delivery Face down; about 500 sheets of 20 lb (75 g/m ) paper Face up; about 100 sheets of 20 lb (75 g/m ) paper Feed Paper cassettes (2) About 500 sheets of 20 lb (75 g/m ) paper per cassette.
Page 210: Envelopes
Without an internal SCSI hard disk installed, up to 4 external SCSI hard disks may be added. Q-Fax, the QMS retrieval service, provides current information on hard disks available for this printer. See appendix A for information on using this service.
Page 211: Consumable Supplies
Consumable Supplies Consumable Supplies Cassettes Size Capacity 500 sheets Legal 500 sheets Letter 500 sheets Letter 1500 sheets Media—Sizes See “Print Media Sizes,” earlier in this chapter Media— Paper Plain—Xerox 4024 Recommended Laser—Hammermill Laser Print Brands Labels Avery 5260 Transparencies Canon brand type D 3-M type PP2500 Envelopes Com#10, Monarch...
Page 212 To prevent noise effectively, these cables should be shielded and connected to the chassis of the system unit and printer, respectively. QMS 1725E Print System Reference...
Page 213: Serial
Cable Pinouts All interface conditions are based on Transistor-Transistor Logic (TTL) level. Both the rise and fall times of each signal must be less than 0.2 microseconds. Data transfer must be carried out by recognizing the ACKNLG or BUSY signal. The cable must have an overall braided shield, Belden 8345 or equivalent.
Page 214: Ibm Pc/Xt, Pc/At, And Compatible Computers
RTS and CTS support. Make sure that pins 4 and 5 on the 25-pin serial cable and pins 7 and 8 on the 9-pin serial cable are criss-crossed as shown in this diagram. B-10 QMS 1725E Print System Reference...
Page 215: Ethernet
Cable Pinouts Ethernet 10BaseT These are the pinouts for the 10BaseT Ethernet cable: Pin Name (View from front of the connector) Transmit Data + Transmit Data - Receive Data + No Contact No Contact Receive Data - No Contact No Contact 10Base2 BNC These are the pinouts for the 10Base2 BNC Ethernet cable: Pin Name...
Page 216: Localtalk (Optional Interface
Note: To download printer system software from a Macintosh, you must have this type cable. Macintosh Printer DB-9 Female Din-8 Male HandshakeOut HandshakeIn TXD- RXD- GND,RXD+ 4,8* Not Used Not Used * Pins 4 and 8 must be connected together on the Din-8. B-12 QMS 1725E Print System Reference...
Page 217: Warranty Considerations
However, if QMS printer failure or damage is found to be directly attributable to the use of non-QMS consumables and/or accessories, QMS will not repair the printer free of charge. In this case, standard time and material charges will be applied to service your printer for that particular failure or damage.
Page 218 Handle the tray carefully, and try to handle it by the edges only. Incidental and consequential damages caused by not discharging electrostatic buildup can affect your printer warranty. B-14 QMS 1725E Print System Reference...
Page 219: Document Option Commands
Document Option Commands In This Chapter . . . Supported Document Option Commands (DOCs) Updated PLC 5 DOCs CCITT commands...
Page 220: Supported Docs
Introduction Introduction This appendix lists the supported Document Option Commands (DOCs) for your QMS 1725E Print System. The commands are grouped by feature type. Each command is preceded by either a DOC statement (%%) or an IncludeFeature statement (%%IncludeFeature). See the QMS Crown Document Option Commands manual for information on how to use each command.
Page 221: Hp Pcl 5 Emulation Commands
Supported DOCs Select pen width and color%%IncludeFeature:pen Select plotter%%IncludeFeature:plotter Shift the origin%%IncludeFeature:origin Reverse image%%IncludeFeature:reverse HP PCL 5 Emulation Commands Enable scalable fonts%%IncludeFeature:scalablefonts* Establish the current resource%%IncludeFeature:install* and default object ID value Remove an external object%%IncludeFeature:remove* %%IncludeFeature:removeresource* Reset to PCL defaults%%IncludeFeature:reset Retain temporary macros/fonts%%IncludeFeature:retaintemporary Select default font%%IncludeFeature:font* Select default font ID%%IncludeFeature:fontid*...
Page 222: Postscript Emulation Commands
This section provides updated information on HP PCL 4 and PCL 5 DOCs. This information will be merged into the appropriate manuals as they are revised. But until then, it supersedes the following: QMS Crown Document Option Commands manual (part number 1800216-001E) HP PCL 5 Emulation Technical Reference Manual (part number...
Page 223 (except Zapf-Dingbats which supports the Dingbats symbol set) support the group of normal symbol sets. In the QMS PCL 5 emulation, only fonts located in the current resource may be accessed by a PCL font ID using the normal <ESC>(#X sequence.
Page 224 IDs. Resource A resource is a location where downloaded objects such as fonts, macros, and patterns are stored. The printer has one default resource and one additional resource for each attached hard disk. All down- QMS 1725E Print System Reference...
Page 225 Updated DOCs loaded objects are stored in file systems which reside on these resources. The RAM1: resource may be used as the default, but sys- tems with at least one hard disk use the system disk instead. So, for any hard disk-equipped printer, all downloaded objects (except pal- ettes, which require special handling) are stored on disk.
Page 226: Updated Pcl 5 Docs
If no %%IncludeFeature:install DOC command is sent, the internal default location is used; otherwise, this parameter, which must be provided, specifies one of the alternate locations. For most QMS printers, resource 6 is the internal system disk. QMS 1725E Print System Reference...
Page 227 Updated DOCs object id Purpose Assigns an ID to an object, such as a font, macro, or pattern. Range 0-32767 Default Format Integer Notes The object ID can be used instead of the usual PCL command to assign an ID. This ID is overwritten by any ID assigned from the PCL print job, if present.
Page 228 *, font, macro, pattern, or other object type Default Format Character If object type is * or is not specified, then all objects Notes on the specified resource with the specified object id are removed. C-10 QMS 1725E Print System Reference...
Page 229 Updated DOCs object id Purpose Specifies the ID of the object that is to be removed from the printer system. Range *, -1 to 32767 Default -1 (wildcard) Format Integer If the object id is not specified, or if it is specified as * Notes or -1, all objects on the specified resource are removed.
Page 230 Default -1 (wildcard) Format Integer Notes If the object id is not specified, or it is specified as * or -1, all objects on the specified resource with the specified object type are removed. C-12 QMS 1725E Print System Reference...
Page 231 If no resource item is provided, the internal default location is used; otherwise, this parameter, which must be provided, specifies one of the alternate locations. For most QMS printers, resource 6 is the internal system disk. object code Purpose Assigns a code to an object such as a font, macro, or pattern.
Page 232 Purpose Specifies the default font name. Range courier12times*blditalic courier12bolduniv* courier12italicuniv*italic courier10univ*bold courier10bolduniv*blditalic courier10italicunivcond* lineprinterunivcond*italic times*univcond*bold times*italicunivcond*blditlc times*boldselectbyindex Default Depends on printer configuration Format Character Select Font Index Command %%IncludeFeature:fontid (index # Syntax Purpose Specifies the default font index number. C-14 QMS 1725E Print System Reference...
Page 233 PCL font selection mechanism is used to locate a font that matches the selected symbol set. With the standard set of fonts distributed by QMS, this matches the Times* font, but other user installed fonts could change this result. Variable...
Page 234 Range Off/false—Treat line feed as a line feed. On/true—Treat line feed as a carriage return-line feed combination. Default Printer configuration dependent Format Boolean C-16 QMS 1725E Print System Reference...
Page 235 Updated DOCs Notes The result of various settings for these parameters is shown in table below, in terms of the equivalent code passed to the PCL line termination command ( <ESC>&k#G ). The second setting (lfiscrlf on, criscrlf off) is correct for most ASCII listings printed from UNIX machines.
Page 236 The %%IncludeFeature:linesperinch DOC affects PCL’s default VMI (vertical motion index). Variable Purpose Specifies the default number of lines per inch. Range 100-4800 (1-48 lines per inch x 100) Default 600 (6 lines per inch x 100) Format Integer C-18 QMS 1725E Print System Reference...
Page 237 Updated DOCs Set Point Size Command Syntax %%IncludeFeature:pointsize (default font size) Purpose Specifies the point size for scalable default font. Notes If the selected font is not scalable or if a bitmap font size is specified, this setting is ignored. Variable default font size Purpose Specifies the floating point number for point size.
Page 238: Ccitt Commands
The remainder of this chapter provides the function, syntax, and default settings of all available CCITT commands. Accessing CCITT Emulation To access CCITT emulation, include the following QMS Document Option Commands (DOC) to the beginning of each data stream: %%IncludeFeature: emulation (ccitt)
Page 239: Imagesize
CCITT Commands ImageSize Function Sets the image size to be used for decompression of the image data that follows the %%ImageData command. %%ImageSize (width height) Syntax width The width of the image in pixels. height The height of the image in pixels. Default None.
Page 240: Rotation
Indicates that end-of-lines are required in the image data. Otherwise, an error results. false Indicates that end-of-lines are not required in the image data but, if present, are accepted with no error. Default false C-22 QMS 1725E Print System Reference...
Page 241: Blockend
CCITT Commands BlockEnd Function Indicates whether a CCITT End of Block is included in the image data. %%BlockEnd (true/false) Syntax true Indicates that a BlockEnd is required in the image data. Otherwise, an error results false Indicates that a BlockEnd is not required in the image data but, if present, it is accepted with no error.
Page 242: Invertimage
DPI resolutions above the original scanned resolution will reduce the image while DPI resolutions below the original scanned resolution will enlarge the image. %%DPI (horizontal vertical) Syntax horizontal vertical Default Currently selected engine resolution. C-24 QMS 1725E Print System Reference...
Page 243: Imagedata
CCITT Commands ImageData Function Instructs the emulation to begin decompression of the image data using the currently set image options. This command begins reading the image data after the end of the current line. After the image, the input stream is flushed until the next set of %% characters is encountered.
Page 244: Jobend
Ends the job and returns the printer to ESP mode. Syntax %%JobEnd Default None—no options. Notes If this command is omitted, the printer remains in CCITT emulation mode until the emulation wait timeout expires (Administration/x/Emul Timeout menu). C-26 QMS 1725E Print System Reference...
Page 245: Notices
Notices In This Chapter . . . Manual notices Laser safety FCC compliance International notices Colophon...
Page 246: Manual Notice
Manual Notice Manual Notice QMS, Inc. reserves the right to make changes to this manual and to the equipment described herein without notice. Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, QMS, Inc. makes no warranty of any kind...
Page 247: Fcc Compliance
QMS documentation. Um elektrische Kurtzschlüsse zu vermeiden, entfernen Sie keine A CHTUNG! Gehaüseteile von Ihrem Drucker, wenn Sie keine Erfahrungen im Umgang mit elektrischen Bauteilen haben. Befolgen Sie die in der QMS Dokumentation beschriebenen Hinweise. Notices...
Page 248: International Notices
Einhaltung der Bestimmungen eingeräumt. QMS Inc., Mobile, AL, USA Declaration of Manufacturer/Importer We hereby certify that the QMS 1725E Print System is in compliance with Vfg 1046/1984 and is RFI suppressed. The marketing and sale of this equipment was reported to the Ger- man Postal Service.
Page 249: Electronics Emissions
Transverter Pro; other illustrations were created directly in Frame- Maker. The menu configuration tree was produced using Banner Blue Software Inc. ORG PLUS for Windows. Typefaces chosen are Ben- guiat, Courier, Helvetica, MarkerFelt, and Tekton. The manual was printed in camera-ready form on a QMS printer. Notices...
Page 251: Configuration Menu
Configuration Menu In This Chapter . . . Configuration Menu Diagrams...
Page 252 Configuration Menu Configuration Menu » Note: The Installation menu appears only when an optional security card is installed. Press Press QMS 1725E Print System Reference...
Page 253 Press Configuration Menu Configuration Menu...
Page 254 Configuration Menu Press QMS 1725E Print System Reference...
Page 255 Glossary Glossary AppleTalk A local area network communication protocol developed by Apple Comput- er. AppleTalk operates on LocalTalk, Ethernet, or Token-Ring cabling and can be used by Macintosh systems, PCs, and printers. See also LocalTalk . Application Any computer program designed to help people perform a certain type of work (for example, word processing, page layout, programming, graphics, and spreadsheets).
Page 256 The control panel key that cancels a print job or sends an end-of-job indicator to a print job waiting for incoming data. It is not necessary to take the printer off line before using the Cancel key. Card See font card , and security card . Connector QMS 1725E Print System Reference...
Page 257 (until the printer is turned off) or on a hard disk. An acronym for dots per inch, a measurement unit used to indicate printer resolution. Your QMS 1725E Print System has 300x300 and 600x600 dpi resolution. Glossary...
Page 258 Developed by Xerox, Ethernet is a local area network that uses coaxial cable (thick or thin), or twisted pair wire to connect nodes transmitting variable-length frames of data at 10 Mbps (10-million bits per second). QMS 1725E Print System Reference...
Page 259 The memory remaining after providing all the other memory clients with their specified amounts of memory is automatically added to the excess memory client. All excess memory in your QMS 1725E Print System goes into a pool shared by the frame buffer and the display list clients.
Page 260 Header Page A separator page, printed before a print job, that identifies the print job and helps users sort out the print jobs in the printer's output tray. See the QMS Crown Document Option Commands manual information on customizing the header page information.
Page 261 An optional font SIMM containing 17 HP PCL 5 fonts that can be installed inside of the QMS 1725E Print System . Adding this option increases the number of available PCL 5 fonts for your printer from the 20 standard fonts to 37 (equivalent to the number of fonts available on a Hewlett-Packard LaserJet 4Si).
Page 262 Kanji A Japanese character set. The QMS Kanji Option Kit contains Kanji fonts licensed to QMS by Morisawa and Company, Ltd., and TypeBank. The Kanji Option Kit enables your printer to print Kanji fonts in a variety of point sizes and in different styles and resolutions.
Page 263 Network Interface Card (NIC) A printed circuit board, in the shape of a card, used to connect a printer physically to a network cable. See your QMS vendor for a complete list of available network interface cards. Next Key The control panel key that advances through a list of selections or options for a menu.
Page 264 Printing across the length of a page is called landscape orientation printing. The term “land- scape” is derived from pictures of the landscape, which are usually hori- zontal in format. G-10 QMS 1725E Print System Reference...
Page 265 Peripheral Device Page Description Language (PDL) A programming language, such as PostScript, that is used to describe output to a printer or a computer monitor. Page Memory A special buffer large enough to hold an entire page of data. Paper Path The path the paper follows in its journey through the printer;...
Page 266 A page description language trademarked by Adobe Systems Incorporat- ed. PostScript Level 2 capabilities, among others, are implemented in your printer through a QMS-developed PostScript emulation. PostScript Level 2 emulation is the native language of your printer’s controller. It describes text, graphics, and page images to the printer.
Page 267 Raster Graphics Print Quality A general measure of the appearance and readability of a printed page. Criteria of print quality include the darkness, clarity, and sharpness of the printed page. Printed Circuit Board A flat board made of plastic, fiberglass, or another nonconducting material on which chips and other electronic components are mounted.
Page 268 Remote Console A feature in QMS Crown printers allowing users to configure the printer and monitor printer conditions over the Ethernet network interface. Resident Permanently stored in the printer’s memory.
Page 269 SIMM (Single In-line Memory Module) Scalable Font A scalable font is one in which each character’s dot pattern (bitmap) is generated from a mathematical representation (or outline) of the character. Scalable fonts eliminate the need to store many different font sizes. Screen The pattern in which dots or lines are placed on a page to create colors or levels of gray.
Page 270 The expiration of a predefined interval, that triggers some action such as a disconnection that occurs following 30 seconds without any data activity (in a 30-second, no-activity timeout). Timeout also refers to the length or existence of such an interval. G-16 QMS 1725E Print System Reference...
Page 271 Trailer Page A separator page, printed after a print job, that identifies the print job and helps users sort out the print jobs in the printer's output tray. See the QMS Crown Document Option Commands manual information on customizing the trailer page.
Page 272 RAM to free temporarily the RAM for other tasks. Volatile Memory Memory that is cleared when the printer is turned off. Most RAM is volatile. XON/XOFF Control characters used for flow control in data transmission. G-18 QMS 1725E Print System Reference...
Page 273 Index See also LocalTalk Testing communication 6-40 Administration /Memory 5-12 Applications G-1 Administration menu 4-5, 4-15 Configuration, printer 4-2 Special Pages menu 4-43 Macintosh 6-39 Startup Options menu 4-46 ASCII G-1 Administration password 4-62 Autowrap menu (Lineprinter) 4-42 Adobe Avant Garde Gothic Illustrator 6-39 ITC Avant Garde Gothic 3-6 Separator 6-39...
Page 274 Methods 4-2 Statement D-4 PostScript operators, via 4-3 Cancel key G-2 PS Executive Series Utilities, via 4-3 Card Quick (see Frame Buffer ) Emulations 6-11 Remote Console, via 4-4 Installing 6-11, 6-13 Font 6-12 Security 6-13 QMS 1725E Print System Reference...
Page 275 Lineprinter emulation commands C-3 CR is CRLF menu (Lineprinter) 4-41 PCL 4 emulation commands C-4 Crown G-3 PostScript emulation commands C-4 Customer support, QMS A-2 Printer commands C-4 Trailer page commands C-2 Updated commands C-4 Document Option Commands Data Bits menu (parallel) 4-25...
Page 276 Enhanced Parallel Port mode, parallel 5-26 Emulation menu Envelope feeder 6-3 Menu 4-28 Installing 6-3 Parallel 4-24 Envelopes Serial 4-18 See also Media Emulation temporary 5-16 Selection 6-3 Enable Disk Swap menu 4-53 Environmental requirements B-4 QMS 1725E Print System Reference...
Page 277 EOD command 5-20 Samples 3-11 Network job separator 5-24 Scalable 3-4, G-15 Other print queuing systems 5-21 Subset 3-2 PC print server 5-21 Font cache 5-14 Stand-alone PC 5-21 Font card 6-12 EPP mode, parallel 5-26 Installing 6-11 Equation Font index number C-5 Bytes to kilobytes 5-12 Font menu (Lineprinter) 4-40 Error Handler, PostScript 4-47...
Page 278 Spanish/Latin 3-10 Helvetica Condensed 3-8, 3-11 Special Symbols 3-10 Helvetica Narrow 3-8, 3-11 HP-GL/2 Horiz. Offset menu 4-54 See PCL5 4-34 Host Input 4-47, 5-16 HP EOD 4-19, 5-20 HP PCL emulation HP PCL fonts 3-9 QMS 1725E Print System Reference...
Page 279 Line Printer 6-27 Marigold 6-28 IBM PC or Compatible Omega 6-27 AT cable pinouts B-10 Times Roman 6-27 XT cable pinouts B-10 Univers 6-27 IDE board B-6 Univers Condensed 6-28 Ignore Par. Err. menu (serial) 4-20 Verifying installation 6-26 Image alignment 2-3, 4-54 Interface Menu 4-54 LocalTalk parameters, setting 6-40...
Page 280 Tab Stops menu 4-41 Keypad language menu 4-11, 4-60 Lines per inch 5-4 Lines/ Inch x100 menu (PCL5) 4-31 Lines Per Page menu(Lineprinter) 4-42 Labels Printing 2-4 See also Media Stock 2-4 Storage 2-5 Type 2-4 QMS 1725E Print System Reference...
Page 281 LocalTalk Marigold 6-28 Cabling 6-35 MB printer mem 5-18 Connection menu 6-41 Menu 4-52 Menu 6-40 Media Def Job Prio menu 6-43 Imageable area 2-2, 2-3 Min K Spool menu 6-42 Margins 2-3 Mode menu 6-41 Storage 2-5 PS Protocol menu 6-42 Types 2-3 Parameters, setting 6-40 Weights 2-3...
Page 282 Monospacing 3-3 Origin menu (HP-GL) 4-36 Output bin name 4-56 Output bins 4-14 Network interface 6-29 Ozone density B-4 Installing 6-29 Network job separator 5-24 New Century Schoolbook 3-8, 3-12 New Flash Image menu 6-62 I-10 QMS 1725E Print System Reference...
Page 283 Parity Errors, ignore 4-20 Page design 3-13 Ignore errors 4-20 Bibliography 3-13 Serial 4-20 Design 3-13 Password Readability 3-13 Administration 4-62 Page margins 2-3 Invalid 4-63 Page Recovery menu 4-57 Using 4-63 Palatino 3-12 Paper System software, updating 6-62 Jams 2-2 Updating print system software 6-65 See also Media PC/AT...
Page 284 PS heap 5-15 Timeout 4-16 PS Protocol 4-22, 5-26 PostScript operators Advantages 5-29 scale 2-3 Implementation 5-29 setgray 5-6 Quoted character 5-27 translate 2-3 PS Protocol menu PostScript VM 5-15 LocalTalk 6-42 Parallel 4-26, 4-27 I-12 QMS 1725E Print System Reference...
Page 285 ROM 5-9 PS Wait Timeout menu 4-16 Flash 5-10 Roman Extensions symbol set (HP- GL) 3-10 Q-FAX A-2 QMS EOD 4-19, 5-20 QuarkXPress 6-39 Sans serif typefaces 3-6 Quick configuration Scalable font 3-4, G-15 See Frame buffer Scalable Fonts menu (PCL5) 4-33...
Page 286 Ozone density B-4 Stroke weight 3-4 Print engine B-2 Support Print Media B-5 CompuServe A-3 Print method B-2 Customer A-2 Print speed B-2 Internet A-3 Resolution B-2 QMS bulletin board A-3 Toner B-2 QMS, World-wide A-6 I-14 QMS 1725E Print System Reference...
Page 287 Technical A-4 Trailer pages 4-45 United States A-4 DOC C-2 Swap file 4-53 Menu 4-45 Symbol 3-8, 3-12 Source, specifying 4-45 Symbol set menu (PCL5) 4-30 translate (PostScript operator) 2-3 Symbol sets Transparencies See also Media HP-GL 3-9 See HP-GL symbol sets Storage 2-5 Symbol typeface 3-7 Type 2-5...
Page 288 Labels B-7 Paper B-7 Transparencies B-7 transparencies B-7 Vertical Offset menu 4-55 Virtual disk 5-9 Virtual memory 5-10, 5-15, 5-18 Volatile memory 5-9 Warning buzzer 4-57 Warranty B-13 Xmit Sw Flow Ctl menu (serial) I-16 QMS 1725E Print System Reference...

QMS 1725E Reference

Introduction

About this Manual

Introduction

Media Sizes and Imageable Areas

Media Types and Weights

Media Storage

Introduction

About Typefaces and Fonts

More Typography Terms

Typeface Classification

Resident Fonts

Optional Fonts

Postscript Typeface Sampler

Page Design

References

Introduction

Methods of Configuration

Configuration Menu

Operator Control Menu

Administration Menu

Communications

Emulations

Special Pages

Printer Start-Up Options

Memory

Printer Engine Features

Miscellaneous

Hard Disks

Installation

Configuring Optional Features

Introduction

The Emulation Sensing Processor (ESP)

Simultaneous Interface Operations (SIO)

Communication Modes

About Gamma Correction

Memory

End Job Mode

Parallel Interface Modes

PS Protocol Option

HP-GL Color Encoding

Introduction

Additional Paper Cassettes

The Envelope Feeder

Duplexer Assembly

Font and Emulation Cards

Security Card

Removing and Re-Installing the Tray Assembly

Memory Modules (Simms)

Intellifont SIMM

Installing Optional Interfaces

Using a Network Interface

Using a Localtalk Interface

Storage Options

Fonts on the Hard Disk

Emulations on the Hard Disk

Kanji Fonts

Internal Hard Disk

Updating System Software

Sources of Support

QMS World-Wide Offices

Print Engine Specifications

Controller Specifications

Electrical Requirements

Environmental Requirements

Physical Characteristics

Print Media

Optional Hardware

Consumable Supplies

Cable Pinouts

Warranty Considerations

Introduction

Supported Docs

Updated Docs

CCITT Commands

Manual Notice

Laser Safety

FCC Compliance

International Notices

Colophon
