2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN5/ATX1
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN20
CN21, CN23
CN22
VGA1
COM1, COM2
BAT1
SODIMM1
Board and Pin Assignments
Description
SMBus Connector
Digital I/O Connector
Front Panel Connector
DC +12V Power Input Connector
Fan Connector
DC +5V/15W Power Output Connector
M.2 2230 Key E Connector
SATA Power Connector
SIM Card Wafer Connector
SATA Connector
M.2 2242/3042 Key B Connector
USB 2.0 Port 1 and 2 Wafer Connector
Inverter Connector
Audio Line-in/Line-out/Mic-in Wafer Connector
Ethernet Port 3 Wafer Connector
LVDS Connector
USB 3.0/2.0 Port 0 Type A Connector
DisplayPort Connector
Ethernet Port 1 and 2
Audio Line-out Phone Jack
VGA Connector
COM1 and COM2 Wafer Connector
CMOS Battery Connector
DDR3L SO-DIMM Connector
CAPA84R Capa Board
