2.4.19
Ethernet Ports (CN21 and CN23)
The board has two RJ-45 Ethernet connectors, CN21 (for LAN2) and CN23 (for LAN1).
Connection can be established by plugging one end of the Ethernet cable into this
connector and the other end (phone jack) to a 1000/100/10-Base-T hub.
1000
Pin
Base-T
L1
BI_DA+
L2
BI_DA-
L3
BI_DB+
L4
BI_DC+
L5
BI_DC-
L6
BI_DB-
L7
BI_DD+
L8
BI_DD-
Active Link LED
A
Off: No link
Blinking: Data activity detected
Speed LED
B
1000: Orange
100/10: Green/OFF
2.4.20
Audio Line-out Phone Jack (CN22)
This is phone jack for audio out with HD audio support.
Install audio driver, and then attach audio device to
CN22.
2.4.21
VGA Connector (VGA1)
This is a standard 15-pin D-Sub connector commonly used for VGA display. This VGA
interface configuration can be configured via software utility.
Pin
Signal
1
Red
3
Blue
5
GND
7
GND
9
VCC
11
N.C.
13
Horizontal Sync
15
DDC CLK
Board and Pin Assignments
100/10
Description
Base-T
TX+
Bidirectional or Transmit Data+
TX-
Bidirectional or Transmit Data-
RX+
Bidirectional or Receive Data+
N.C.
Bidirectional or Not Connected
N.C.
Bidirectional or Not Connected
RX-
Bidirectional or Receive Data-
N.C.
Bidirectional or Not Connected
N.C.
Bidirectional or Not Connected
Pin
Signal
2
Green
4
N.C.
6
DETECT
8
GND
10
GND
12
DDC DATA
14
Vertical Sync
CAPA84R Capa Board
A
B
L8
L7
L6
L5
L4
L3
L2
L1
A
B
23
