AXIOMTEK CAPA84R User Manual page 27

24-bit single channel
Pin Signal
1 VCCM
3 VCCM
5 VCCM
N.C
7
9 GND
11 N.C
13 N.C
15 GND
17 N.C
19 N.C
21 GND
23 Channel A D0-
25 Channel A D0+
27 GND
29 Channel A D1-
31 Channel A D1+
33 GND
35 Channel A D2-
37 Channel A D2+
39 GND
24-bit dual channel
Pin Signal Pin Signal
1 VCCM
3 VCCM
5 VCCM
N.C
7
9 GND
11 Channel B D3-
13 Channel B D3+
15 GND
17 Channel B CLK-
19 Channel B CLK+ 20 Channel B D1+
21 GND
23 Channel A D0-
25 Channel A D0+
27 GND
29 Channel A D1-
31 Channel A D1+
33 GND
35 Channel A D2-
37 Channel A D2+
39 GND
Board and Pin Assignments
Pin Signal
2 VCCM
4 VCCM
6 VCCM
N.C
8
10 GND
12 N.C
14 N.C
16 GND
18 N.C
20 N.C
22 GND
24 N.C
26 N.C
28 GND
30 Channel A D3-
32 Channel A D3+
34 GND
36 Channel A CLK-
38 Channel A CLK+
40 GND
2 VCCM
4 VCCM
6 VCCM
8 N.C
10 GND
12 Channel B D0-
14 Channel B D0+
16 GND
18 Channel B D1-
22 GND
24 Channel B D2-
26 Channel B D2+
28 GND
30 Channel A D3-
32 Channel A D3+
34 GND
36 Channel A CLK-
38 Channel A CLK+
40 GND
18-bit dual channel
Pin Signal
1 VCCM
3 VCCM
5 VCCM
N.C
7
9 GND
11 N.C
13 N.C
15 GND
17 Channel B CLK-
19 Channel B CLK+
21 GND
23 Channel A D0-
25 Channel A D0+
27 GND
29 Channel A D1-
31 Channel A D1+
33 GND
35 Channel A D2-
37 Channel A D2+
39 GND
CAPA84R Capa Board
Pin Signal
2 VCCM
4 VCCM
6 VCCM
N.C
8
10 GND
12 Channel B D0-
14 Channel B D0+
16 GND
18 Channel B D1-
20 Channel B D1+
22 GND
24 Channel B D2-
26 Channel B D2+
28 GND
30 N.C
32 N.C
34 GND
36 Channel A CLK-
38 Channel A CLK+
40 GND
21
