Rear Speaker/Microphone Status
The Infinea X provides application developers with a programmable feature to Enable/Disable the
Infinea X rear speaker and microphone.
When the speaker is enabled, a single blue LED is lit on the right side of the unit, as shown in the figure
below.
Figure 12: Speaker/Microphone Status
Manually Enable/Disable Rear Speaker
To disable the rear speaker manually, press the lower right button to toggle the rear speaker mode.
Speaker/Mic Mode
Speaker/Mic LED
Enabled
On
Disabled
Off
Infinea X User Manual
Page 22 of 34
UM-00001 Version: C
