CHARGING YOUR INFINEA X

There are two options for charging the Infinea X:
• By wall outlet
• By replacing battery
The Infinea X supports pass through charging to the iOS device. An iPod or iPhone and Infinea X
combination may be charged by attaching the Charging Cup to the bottom of the Infinea X and USB
end into an AC wall adapter or by station charger. Due to charging requirements, the Infinea X and iPod
or iPhone combination cannot be charged with a USB cable to a PC.

Battery Specifications

The Infinea X standard battery has a capacity of 1,900 mAh. The extended battery pack
offers a capacity of 3,800 mAh.
The charge time for an empty battery to become 100% full is 3.5 hours for the standard battery and 7
hours for an extended battery pack.
75%-100%
50%-74%
25%-49%
1%-24%
1%-9%
When remaining battery capacity is below 30%, the automatic charge of the iOS device stops.
Infinea X User Manual
UM-00001 Version: C
Standard Battery
Battery Life Status
LEDs are solid green upon pressing the Battery Status button.
LEDs flash green upon pressing the Battery Status button.
LEDs flash orange upon pressing the Battery Status button.
LEDs flash red upon pressing the Battery Status button.
One LED automatically flashes red to indicate emergency low battery status.
Extended Battery
(sold separately)
