Barcode Scanner
Notification LEDs
Front/Rear
Speaker Toggle
Infinea X User Manual
UM-00001 Version: C
iOS On/Off Button
Figure 2a and 2b: Top and Bottom
Scan Button
Mini USB Connector
Figure 3a and 3b: Left and Right Sides
Pads for charging station and sync
Notification
LEDs
Battery
Status
Button
Volume
Buttons
Page 11 of 34
