Internal Duplexer Cable Connections
•
RX labelled cable is connected to RX port on Duplexer
•
TX labelled cable is connected to TX port on Duplexer
•
ANTENNA labelled cable is connected to ANTENNA port on Duplexer
Simplex Cable Connections
•
TX labelled cable is connected to ANTENNA labelled cable using the supplied Female-
Female adapter
Internal Duplexer and Booster Pack* Cable Connections
•
RX labelled cable is connected to RX port on Duplexer
•
RF IN labelled cable is connected to TX port on Duplexer
•
ANTENNA labelled cable is connected to ANTENNA port on Duplexer
•
TX labelled cable is connected to RF OUT labelled cable
External Duplexer Cable Connections
•
TX labelled cable is connected to RF OUT labelled cable
•
RX labelled cable is connected to RF IN labelled cable using the supplied Female-
Female adapter
External Duplexer and Booster Pack* Cable Connections
•
TX labelled cable is connected to RF OUT labelled cable
•
RX labelled cable is connected to RF IN labelled cable using the supplied Female-
Female adapter
Once connections are complete, replace the top cover and screw back in place.
* Booster Pack is not yet released by Futurecom
PDR8000 Portable Digital Repeater Deployment Guide
Document 8K088X03 R3.0
Page 8 of 24
