Internal Duplexer and Booster Pack*
•
AUX cable is connected from AUX connector of PDR8000 to AUX connector of Booster
Pack*
•
ANTENNA cable is connected to ANTENNA connector
•
RF cable is connected from RF OUT connector of PDR8000 to RF IN connector of
Booster Pack*
•
RF cable is connected from RF IN connector of PDR8000 to RF OUT connector of
Booster Pack*
External Duplexer
•
Duplexer cable (supplied by end user) is connected from RF OUT connector of
PDR8000 to TX port of External Duplexer
•
Duplexer cable (supplied by end user) is connected from RF IN connector of PDR8000
to RX port of External Duplexer
•
AUX and ANTENNA are not connected
External Duplexer and Booster Pack*
•
AUX cable is connected from AUX connector of PDR8000 to AUX connector of Booster
Pack*
•
RF cable is connected from RF OUT connector of PDR8000 to RF IN connector of
Booster Pack*
•
Duplexer cable (supplied by end user) is connected from RF IN connector of PDR8000
to RX port of External Duplexer
•
Duplexer cable (supplied by end user) is connected from TX port of External Duplexer to
RF OUT end connector of Booster Pack*.
•
The ANTENNA cable is connected to the ANTENNA port of the External Duplexer
•
The ANTENNA connector of PDR8000 is not connected
PDR8000 Portable Digital Repeater Deployment Guide
* Booster Pack is not yet released by Futurecom
** LAN / IP is not enabled in PDR8000 R3.0.
