Document 8K088X03 R3.0
PDR8000 Portable Digital Repeater Deployment Guide
STEP 7 - Open/Closed Case Operation
PDR8000 has been designed to support both open-case and closed-case operation. When
operating closed-case, the PDR8000 should be standing on its hinged side, allowing the case to
provide better cooling efficiency. When operating open-case (providing the best cooling
capability), the PDR8000 is to be placed flat on its large surface. Note that the PDR8000 is not
water resistant when operating open-case.
Figure 21 - Open case operation
Figure 22 - Closed case operation
Page 21 of 24
