6.10

Replacing the door seal

The new seal must be adjusted prior to installation.
Adjusting the seal
Prior to insertion, ensure that the seal lip is pointing
towards the middle of the rinsing tank, otherwise
there will be leaks in the area of the door
adjust the length of the seal to the circumference of the container.
cut the ends of the seal at an angle 45°.
place the seal on the base of the container. (Splash-proof
protection for the lower corners).
Press in the seal evenly and without any kinks
815_58300000120057_ara_en_d.doc – 25.05.11
Seite 42 von 60
