- Page 1 Translated from Dutch to English - www.onlinedoctranslator.com Dishwasher SRV2IKX10E [NL] User manual...
-
Page 2: Table Of Contents
Table of contents Safety..........4 Knife rack ........20 General instructions ....4 Cutlery basket heights ......20 Destination of the device....4 Before using for the first time ....21 Restriction of users .... 4 First time use..21 Secure installation......... - Page 3 Cancel program ....32 Switching off the device....32 Basic Settings ........ 33 Overview of the basic settings gen ..........33 Cleaning and maintenance....34 Cleaning the rinse aid dispenser ..34 Detergent ........34 Device maintenance tips..34 Machine cleaning ......35 Sieving System........
-
Page 4: Safety
NL Safety Safety Observe the following safety instructions. General instructions s Read this manual carefully. s Keep the operating instructions and product information for later use or for subsequent owners. s Do not connect the device in case of transport damage. Destination of the device Only use the device: s to wash dishes. - Page 5 Safety NL WARNING ‒ Risk of electric shock! s Improper installations are dangerous. ▶ Only connect and use the device in accordance with the information on the type plate. ▶ Always use the supplied power cord of the new appliance. ▶...
-
Page 6: Safe Use
NL Safety ▶ Only use adapters approved by the manufacturer. WARNING ‒ Risk of injury! The hinges move when opening and closing the appliance door and can cause injury. ▶ If underfloor or built-in appliances are not located in a niche and thus a side wall is accessible, the side hinge section must be covered. - Page 7 Safety NL s Highly corrosive alkaline or strongly acidic cleaning agents in combination with aluminum objects in the washing area of the appliance can lead to explosions. ▶ Never use highly corrosive alkaline or strongly acidic cleaning agents, in particular those for professional or industrial use, in combination with aluminum objects (e.g.
-
Page 8: Damaged Device
NL Safety ▶ Never bring the power cable into contact with sharp points or edges. ▶ Never kink, pinch or alter the power cord. Damaged device WARNING ‒ Risk of electric shock! s A damaged appliance or power cord is dangerous. ▶... - Page 9 Safety NL s Children can inhale or swallow small parts and choke. ▶ Keep small parts away from children. ▶ Do not allow children to play with small parts. s Children can lock themselves in the appliance and suffocate. ▶ If present, use the child lock. ▶...
-
Page 10: Avoiding Material Damage
NL Avoid material damage Material damage s Modified or damaged water hoses can lead to material damage avoid and damage to the device. Never kink water hoses, ▶ Safe installation pinch, modify or cut. Only supplied water hose ▶ or use original spare hoses. PAY ATTENTION! s An improper installation of the device can cause damage. -
Page 11: Environmental Protection And Saving
Environmental protection and saving NL Aquasensor Dishwasher detergent can damage the water softener. The aquasensor is an optical The reservoir of the softener ▶ measuring device (photocell) with Only fill the water supply with which the turbidity of the washing special salt for dishwashers. -
Page 12: Setting Up And Connecting
NL Set up and connect Waste water connection s Other documents containing information Connect the appliance to a drain water s Mounting material connection so that the contaminated s Steam protection plate washing water can be drained. s Salt filling aid funnel s Power cord Install waste water connection s Quick Guide... -
Page 13: Electrical Connection
Set up and connect NL Electrical connection Connect the device to the mains. Connecting the appliance electrically Notes s Observe the "Safety sing" → Page 4. s Only connect the device on an AC voltage of 220 - 240 V and 50 Hz or 60 Hz. -
Page 14: Getting To Know Your Device
NL Getting to know your device Getting to know your device Device Here you will find an overview of the components of your device. Nameplate Type plate with "E number and FD number" → Page 52. You need this information for the "service" →... -
Page 15: Controls
Getting to know your device NL Detergent dispenser Put the "dishwasher detergent" in the detergent dispenser → Page 25. "Lower crockery basket" → Page 19 Lower crockery basket "Sieve system" → Page 36 Sieving System Reservoir for softening salt Add softening salt to the water softening salt reservoir. - Page 16 NL Getting to know your device 12 11 "Turn on device" → Page 30 ON/OFF button and Reset button "Turn off device" → Page 32 "Abort program" → Page 32 "Programs" → Page 17 Program key "Programs" → Page 17 Programs Water supply indication Water supply indication...
-
Page 17: Programs
Programs NL Programs Here you will find an overview of the rinse system or lack of rinse aid adjustable programs. Depending on affects the run time. the configuration, different programs are offered on the control panel of The consumption values can be the device. -
Page 18: Notes For Test Institutes
NL Additional Features Program Usage Program sequence Additional Features Use only with the Machine cleaning 70 °C device removed. Machine cleaning Remark: The relatively longer run Usage Additional function time of the Eco 50° program is due to s The water and energy longer soaking and drying times. -
Page 19: Upper Basket
Equipment NL Place the basket on the upper Upper crockery basket rollers (position 3) or the lower Place cups, glasses and small rollers (position 1). → crockery in the upper basket. "Cutlery basket heights", Page 20 knife rack Make sure that the upper To create space for larger crockery, crockery basket is level on both you can adjust the height of the upper... -
Page 20: Cutlery Basket
NL Equipment Etagère Use the etagère and the space below it for storing small cups and glasses or for larger pieces of cutlery such as ladles or pre-cut cutlery. cutlery basket Always place the cutlery unsorted with the points downwards in the cutlery basket. -
Page 21: Before Using For The First Time
Before first use NL upper basket lower basket position 27 cm 25 cm 3 max. ø Start the program with the highest V for the first use cleaning temperature without dishes. set the options for the first use. We recommend that you use the appliance without any dishes before using it for the first time because of First time use... -
Page 22: Set Water Softening
NL Softening System Remark: Set the device to the The amount of softening salt determined water hardness. depends on the water hardness. The → "Setting water softening", higher the water hardness, the Page 22 greater the amount of softening salt required. -
Page 23: Switching Off Water Softening
Softening System NL 3. Note: Only use special salt for according to the manufacturer's dishwashers. instructions, only use up to a degree of hardness of 21 °dH Do not use salt tablets. Do not without adding softening salt. use table salt. s The water hardness is 0 - 6 Place the softening salt in the °dH. -
Page 24: Rinse System
NL Rinse System Press and lift the tab on the lid of Overview of the consumption values the rinse aid container . when regenerating the softening system Here you will find an overview of the maximum additional runtime and consumption values when regenerating the softening system. -
Page 25: Switch Off Rinse System
Dishwasher detergent NL To access the device settings, To access the device settings, press . for 3 seconds press . for 3 seconds to press. to press. a flashes in the display. a flashes in the display. Repeat until to press Press just as often blinks. - Page 26 NL Dishwasher detergent Non-combined detergent Description Dishwasher detergent Tabs Non-combined dishwashing detergents Tabs are suitable for all are products which contain no further dishwashing tasks and components in addition to the actual do not require dosing. dishwashing detergent. Examples of this With abbreviated "programs"...
-
Page 27: Unsuitable Dishwashing Detergent
Dishwasher detergent NL Unsuitable detergent dry detergent dispenser to prevent the packaging from sticking. Do not use detergents that could damage the appliance or harm your s Even when the gloss- health. top up rinse aid and the top up softener salt indicator lights up, the Description Dishwasher detergent... -
Page 28: Crockery
NL China Place detergent in the dry Close the lid of the detergent detergent dispenser. dispenser. 50ml 25 ml 15ml a The lid audibly clicks into place. If you use tabs, one tablet is a The detergent dispenser is enough. Place tabs across the tray. depending on the program opens When using powder or liquid automatically at the optimum time... -
Page 29: Damage To Glass And Crockery
China NL Damage to glass and crockery Cause Recommendation Highly corrosive alkali If you use highly corrosive al- chemical or strongly acidic or strongly acidic Prevent damage to glass and ser- dishwashing detergents containing dishwashing dirty stuff. detergents, in particular detergents used, Cause products for professionals, especially for Recommendation... -
Page 30: Unloading Crockery
NL The Ministry in essence s For better washing and drying sultaten, place crockery with curves or cavities at an angle so that water can run off. Clearing crockery WARNING Remove coarse food residues from Risk of injury! the dishes. Hot dishes can cause burns. -
Page 31: Set Program
The Ministry in essence NL The Eco 50° program is a very Make time setting environmentally friendly program You can delay the program start by and ideal for normally soiled 3, 6 or 9 hours. crockery. It is the most efficient program in terms of energy and press repeatedly until the water consumption for this type of... -
Page 32: Interrupt Program
NL The Ministry in essence s To save energy, it is Tip: If you press is pressed, the current program is appliance switches off automatically 1 interrupted. When you switch on the minute after the end of the programme. appliance, the program continues If you open the door immediately after automatically. -
Page 33: Basic Settings
Basic settings NL Basic settings You can set up your device according to your needs. Overview of the basic settings The basic settings depend on the equipment of your appliance. Basic setting Description Choise Set the water hardness. Scale with 4 positions Water hardness →... -
Page 34: Cleaning And Maintenance
NL Cleaning and maintenance If the "LED A" → Page 15 does cleaning and maintenance not light up, Extra Dry is switched off. If the "LED A" → Page 15 lights up, Carefully clean and maintain your appliance to ensure that it continues to Extra Dry is switched on. -
Page 35: Machine Cleaning
To avoid machine cleaners for dishwashers via malfunctions and to reduce the https://www.bosch-home.com/store formation of unpleasant odours, it is or our service department. recommended to clean the device at Machine cleaning is a program that regular intervals. -
Page 36: Sieving System
NL Cleaning and maintenance s Make sure that there are no aluminum Sieving System um objects, such as grease filters from The sieve system filters coarse extractor hoods or aluminum pans, are impurities from the rinsing circuit. in the washing compartment of the appliance. -
Page 37: Cleaning Spray Arms
Cleaning and maintenance NL Pull the micro sieve downwards. Cleaning spray arms Limescale and impurities in the wash water can block the nozzles and bearings of the spray arms. Clean the spray arms regularly. Unscrew the upper spray arms and unscrew them downwards. -
Page 38: Troubleshooting
NL Troubleshooting Troubleshooting You can remedy minor faults on the device yourself. Before contacting customer service, please refer to the troubleshooting information. This way you avoid unnecessary costs. WARNING Risk of electric shock! Improper repairs are dangerous. Only qualified personnel may carry out repairs on the device ▶... - Page 39 Troubleshooting NL Cause Troubleshooting Malfunction Water supply Put the plug back in the indicator lit socket. Switch on the device. Route the drain hose without Drain hose is clogged or kinks. kinked. Remove the remains. Check the connection to the ▶...
-
Page 40: Washing Result
NL Troubleshooting Washing result Cause Troubleshooting Malfunction Crockery is not dry. Fill the "rinse agent" No rinse aid has been → used or the dosage is Page 24 Bee. set too low. Set the amount of rinse aid. → "Amount of rinse aid set", page 24 Select a program with drying, "... - Page 41 Troubleshooting NL Cause Troubleshooting Malfunction No solution available. Plastic crockery is not No fault. Due to a bearing ▶ dry. heat storage capacity dries plastic worse. Drops may form at the touch Cutlery is not dry. Cutlery is not properly points of the cutlery.
- Page 42 NL Troubleshooting Cause Troubleshooting Malfunction Food remains on the ▶ Do not stack tall, narrow pieces High, narrow items of crockery. of crockery at an angle or in the crockery are insufficiently corners. spread out in the corners. flushed. The upper basket is not ▶...
- Page 43 Troubleshooting NL Cause Troubleshooting Malfunction There are wipeable or Components of the ▶ Change from "dishwasher detergent" → Page 25. water-soluble deposits detergent are in the interior or on the deposited. This deposit ▶ Clean the device mechanically. door of the appliance. usually cannot be removed chemically.
- Page 44 NL Troubleshooting Cause Troubleshooting Malfunction Tea or lipstick residue weak washing program. Stubborn dirt cannot on the dishes. be partially removed. Clean the device. There are colored (blue, Layering occurs due to the ▶ yellow, brown), difficult components of vegetables You can remove the deposits with a or non-removable "mechanical cleaning"...
- Page 45 Troubleshooting NL Cause Troubleshooting Malfunction The amount of rinse Set the rinse system to ▶ There are removable aid is set too high. smudges on glasses, a lower position. → " refill rinse aid", glassware with a metallic No rinse aid has been ▶...
-
Page 46: Indications On The Display
NL Troubleshooting Cause Troubleshooting Malfunction Use rust-resistant cutlery. Cutlery is not sufficiently ▶ Rust traces on the cutlery. rust resistant. Knife blades are often more affected by this. Cutlery also rusts Do not wash rusting objects ▶ off. when washed with rusty objects. -
Page 47: Malfunctions
Troubleshooting NL Cause Troubleshooting Malfunction Rinse aid refill Rinse aid is missing. Fill the "rinse agent" → indicator lights up. Page 24 Bee. Set the amount of rinse aid. → "Amount of rinse aid set", page 24 Amount of rinse aid in Rinse aid refill Water softening is ▶... -
Page 48: Mechanical Damage
NL Troubleshooting Cause Troubleshooting Malfunction Device hangs in a Check the power supply. Power and/or water supply program or cuts out. is interrupted. Check the water supply. Check that the rear wall of ▶ Upper basket presses against the device is being pressed the inner door and prevents by a socket or an proper closing of the... - Page 49 Troubleshooting NL Cause Troubleshooting Malfunction Load more dishes into the appliance Knocking or rattling sound. ▶ honeycomb. Light dishes move Spacious light pieces of crockery ▶ during rinsing. stable in.
-
Page 50: Cleaning The Drain Pump
NL Transport, storage and disposal Fit the pump cover and press Cleaning the drain pump down . Large food particles or objects can block the drain pump. As soon as the washing water is no longer draining properly, you must clean the drain pump. -
Page 51: Making The Appliance Frost-Proof
Transport, storage and disposal NL Frost-proof the appliance Disposal of your old appliance If the device is located in a room with Environmentally friendly disposal a risk of frost, eg in a holiday home, means that valuable raw materials empty the device completely. can be reused. -
Page 52: Service
NL customer service You can make a note of the data so service service that you can quickly find your device data and service phone numbers. If you have any questions, cannot rectify a fault with the device yourself or if the device needs to be repaired, AQUA-STOP guarantee please contact our customer service. -
Page 53: Technical Data
Technical data NL Information about free software gdata technical and open source software This product contains software Weight Max.: 45 kg components that are licensed by the Voltage 220 - 240V, 50Hz or intellectual property holders as free 60Hz software or open source software. 2000 - 2400 W Connection value The information about the respective... - Page 56 Contact data of all countries are listed in the attached service directory. Robert Bosch Hausgeräte GmbH Carl-Wery-Straße 34 81739 Munich GERMANY www.bosch-home.com * 9001679177* 9001679177 ( 010817) 442 E5 en...
