6.7.2
Installation
Insert spring clamp (D) into the hinge plate (A)
Insert hinge plate (A) into the base pan
Screw hinge plate (A) to the frame and base pan
Insert hinge lever (B) with the bearing bush (C) into the hinge plate
(A)
Screw inner door to hinge lever (B)
Attach tension cord (E) to the hinge lever (B)
Screw on side panels, angle strip, base panel and outside door.
815_58300000120057_ara_en_d.doc – 25.05.11
Seite 39 von 60
