6.2

Replacing the Aqua Stop valve

Open the housing
Disconnect the inlet hose
Cut through the electric connecting cables
Strip the insulation off the cable ends
Push the shrink-fit hose over the cable
Connect electric cables to the insulating sleeves (1.)
After fitting, warm the connectors until the shrinkage process occurs
and the hot-melt adhesive comes out of the ends of the connectors
(2).
Push the shrink-fit hose over the connectors and also warm until
the shrinkage process is complete (3)
815_58300000120057_ara_en_d.doc – 25.05.11
Seite 31 von 60
