This document supplements the following manuals:
- Instructions and warnings for GFW
80963B_MSW_GFW_11-2012_ENG
GFW adv
ADVANCED MODULAR POWER CONTROLLER
CONFIGURATION AND
PROGRAMMING MANUAL
Software version: 2.0x
code: 80963B - 11-2012 - ENG
ATTENTION!
This manual is an integral part of the product,
and must always be available to operators.
This manual must always accompany the pro-
duct, including if it is transferred to another user.
Installation and/or maintenance workers MUST
read this manual and scrupulously follow all of the in-
structions in it and in its attachments. GEFRAN will not
be liable for damage to persons and/or property, or to
the product itself, if the following terms and conditions
are disregarded.
The Customer is obligated to respect trade
secrets. Therefore, this manual and its attachments
may not be tampered with, changed, reproduced,
or transferred to third parties without GEFRAN's
authorization.
1
