Figure 7 List of Available Sensors
The sensor name and battery status:
Battery status.
The WiFi status:
Wifi transmission is available.
Wifi transmission is available but not good.
WiFi transmission is not available.
The Sensor availability:
Sensor is connected to your computer and ready for use. Click
Sensor is not connected to your computer. Click
Refresh button refreshes the list of sensors visible in the computer.
Figure 8 Dental Arch for Tooth Selection
To select the desired tooth or teeth for acquisition, click on the tooth. The tooth number for acquisition
is displayed as shown in the Figure 5.
12 Chapter 4 Imaging Software Overview
to disconnect.
to connect.
