  • Page 1 KODAK 9000 3D Extraoral Imaging System Installation Guide...
  • Page 2 Notice Congratulations on your purchase of the KODAK 9000 3D Extraoral Imaging System. Thank you for your confidence in our products and we will do all in our power to ensure your complete satisfaction. The Installation Guide for the KODAK 9000 3D Extraoral Imaging System includes information both on the Panoramic features as well as the 3D features.

  • Page 3: Table Of Contents

    Annual Maintenance ................7–1 KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01...
  • Page 4 Contents 8—TECHNICAL SPECIFICATIONS Compliance with International Standards ............8–1 Unit Technical Specifications .

  • Page 5: 1-About This Guide

    CAUTION Alerts you to a condition that might cause serious damage. IMPORTANT Alerts you to a condition that might cause problems. NOTE Emphasizes important information. Provides extra information and hints. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 1–1...

  • Page 6: Note To The User

    Warning and Safety Instructions When operating the Kodak 9000 unit, observe the following warning and safety instructions: DANGER OF ELECTRIC SHOCK This is an electrical Unit. DO NOT expose it to water spray. Such action may cause an electric shock or a malfunction of the Unit.
  • Page 7 Ask the patient to remain still until the Unit arm has stopped moving and the RESET movement has completed. • DO NOT use this Unit in conjunction with oxygen-rich environments. This Unit is not intended for use with flammable anesthetics or flammable agents. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 1–3...

  • Page 8: Marking And Labeling Symbols

    Marking and Labeling Symbols Marking and Labeling Symbols Type B device symbol complying with the IEC 60601-1 standard In the EEC, this symbol indicates: DO NOT discard this product in a trash receptacle; use an appropriate recovery and recycling facility. Contact your local sales representative for additional information on the collection and recovery programs available for this product...

  • Page 9: Responsibility And Warranty

    Our products are guaranteed in their original packaging. Carestream Health, Inc. cannot be held liable for damages resulting from transportation. Consumable spares, software and accessories are excluded from the warranty. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 1–5...
  • Page 10 Responsibility and Warranty 1–6 About This Guide...

  • Page 11: 2-Kodak 9000 3D Digital Imaging Unit Overview

    KODAK 9000 3D DIGITAL IMAGING UNIT OVERVIEW The KODAK 9000 3D digital imaging unit is compliant with the requirements of the EEC and international medical standards. The KODAK 9000 3D Unit has been designed to carry out the following radiological examinations: •...
  • Page 12 Column connecting terminals ON/OFF button X-Ray remote control Wall mounting brackets Door safety switch Wall mounting brackets cover PC hosting the imaging and acquisition software Column upper cover Ethernet outlet RJ45/1 2–2 KODAK 9000 3D D IGITAL IMAGING UNIT OVERVIEW...
  • Page 13 Figure 2–3 KODAK 9000 3D Unit Positioning Laser Beam components 3D central positioning laser beam Mid-sagittal positioning laser beam Horizontal positioning laser beam 3D Field of View (FoV) positioning laser beam KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 2–3...

  • Page 14: Control Panel Overview

    Display Screen: Displays the current acquisition parameters and the error messages. Ready Indicator LED: Green indicates the Unit is ready for acquisition. X-Ray Emission LED: Yellow indicates x-rays are being emitted. System Status LED: Red indicates error alerts. 2–4 KODAK 9000 3D D IGITAL IMAGING UNIT OVERVIEW...

  • Page 15: X-Ray Remote Control Overview

    You must press and hold the exposure button until the end of acquisition. Premature release of the exposure button interrupts the acquisition. Figure 2–5 X-Ray Remote Control Exposure button: launches image acquisition. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 2–5...
  • Page 16 X-Ray Remote Control Overview 2–6 KODAK 9000 3D D IGITAL IMAGING UNIT OVERVIEW...

  • Page 17: 3-Kodak 9000 3D Packaging

    • Wall mounting bracket • Column assembly 350mm (D) x 2300mm (L) x 460mm (H) 74 kg Wall bracket cover • 3 meter mains power cable • Upper column cover KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 3–1...

  • Page 18: Head Assembly

    Box (A) Components Table 3-3 lists the box A components. Table 3–3 Box (A) Components Product Description Quantity Unit fixed arm Under the head front cover Under the head back cover Column side cover Column inside cover 3–2 KODAK 9000 3D PACKAGING...

  • Page 19: Box (B) Components

    Mounting hook for the x-ray remote control A set of right and left temple supports Table 3–6 3D Positioning Accessories and Replacement Parts Accessory Description 3D bite block 3D chin rest KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 3–3...
  • Page 20 • Panoramic chin rest • TMJ x2 chin rest • Sinus chin rest TMJ x4 nose rest Panoramic standard bite block Bite block for edentulous patients Single use sheaths for bite blocks (500 pcs box) 3–4 KODAK 9000 3D PACKAGING...

  • Page 21: Column Assembly

    Table 3-8 lists the column assembly components. Table 3–8 Column Assembly Product Description Quantity Column assembly Wall mounting brackets Wall mounting brackets cover Column upper cover 3 meter mains power cable KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 3–5...
  • Page 22 Column Assembly 3–6 KODAK 9000 3D PACKAGING...

  • Page 23: 4-Site Preparation Before Installation

    Check the following ambient operating condition requirements of the x-ray room before installing the Unit: • Temperatures: 5 ~35 °C • Relative humidity: 30 ~ 85% • Atmospheric pressure: 700 ~ 1060 hpa KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 4–1...

  • Page 24: Unit Dimensions

    Unit Dimensions Unit Dimensions The Unit dimensions illustrated in the above figure are as follows: • Maximum height of the Unit (2378mm) • Minimum (1016mm) and maximum (1693mm) height of the chin rest • Width (1158mm) and depth (1595mm) of the Unit •...

  • Page 25: Electrical Requirements

    If other units are installed on the same line, interference and voltage fluctuations can cause the radiological Unit to operate abnormally. We strongly recommend that a separate electrical line be dedicated to supply power to the KODAK 9000 3D Unit. This line should be protected by a circuit breaker with a maximum current of: •...
  • Page 26 Electrical Requirements Figure 4–1 Electrical Diagram of the X-ray Room and KODAK 9000 3D Connections RJ45 K9000 7bis General mains 7bis X-ray warning lamp connecting terminal Differential circuit breaker Column connecting terminals Red color actuator emergency stop push-button X-ray remote control...
  • Page 27 Unit is active (1 lamp at each (5) and (7) access point). • Locate the green warning lamp (7) outside the x-ray room to indicate the x-ray emission. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 4–5...
  • Page 28 Electrical Requirements Table 4–2 Electrical Installation Specifications Contactor (13) 16A-250V 20A-250V UL listed UL listed Door Safety Switch 1A / 250V 1A / 130V Optionally, connect the door safety switch (9) that deactivates the x-ray remote control if the door remains open. Use the following switches: Emergency Stop Switch: Manufacturer:...

  • Page 29: X-Ray Room Requirement

    KODAK 9000 3D Unit IMPORTANT Install the Unit where a minimum amount of space is provided to allow easy access for the patient or the maintenance technician (see Figure 4-2). KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 4–7...
  • Page 30 X-Ray Room Requirement Figure 4–2 Minimum X-Ray Room Space Configuration RJ45/1 RJ45/2 7bis Red color actuator emergency stop push-button X-ray remote control Red color actuator emergency stop push-button Door safety switch Red warning lamp, power ON indicator Mains outlet (for electrical tools) Unit mains connecting terminal Ethernet outlet (RJ45/1) Green warning lamp, x-ray emission indicator...

  • Page 31: Pc System Requirements

    PC System Requirements PC System Requirements This section specifies the minimum PC system requirements for KODAK 9000 3D digital imaging software. IMPORTANT It is MANDATORY to check that the PC system configuration is compatible with the PC system requirements for the KODAK 9000 3D software.
  • Page 32 PC System Requirements 4–10 SITE PREPARATION BEFORE INSTALLATION...

  • Page 33: 5-Installing The Kodak Dental Imaging Software

    2. The Choose Setup Language dialog box is displayed. Select the installation language and click OK. 3. The Kodak Dental Imaging Software welcome page and the InstallShield wizard are displayed. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01...
  • Page 34 4. The Welcome to KODAK Dental Imaging Software Installation dialog box is displayed. Click Next to launch the installation. 5. The License Agreement dialog box is displayed. Accept and click Yes. 5–2 INSTALLING THE KODAK DENTAL IMAGING SOFTWARE...
  • Page 35 NOTE If you are upgrading the software, the default destination folder is the previously selected destination folder. 7. The KODAK Dental Imaging Software dialog box is displayed. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 5–3...
  • Page 36 No 3D Visualization and select 3D Visualization. Check that you have selected correctly. Click Next to begin the installation. 8. The InstallShield Wizard is displayed. Let the installation process run automatically. 5–4 INSTALLING THE KODAK DENTAL IMAGING SOFTWARE...
  • Page 37 The Kodak Patient file - InstallShield Wizard is displayed while the patient files are installed on the hard drive.. The KDIS Link - InstallShield Wizard is displayed while the KDIS link is installed on the hard drive. The Microsoft .NET Framework 2.0 is displayed while this software is being installed on your hard disk for 3D visualization.
  • Page 38 9. The KODAK Dental Software and 3D Volume Queu... icons are installed on your desktop after the reboot. 10. Double-click to open the Patient Window. 11. Create a patient record. From the toolbar, click and enter the required patient information. Click to access the Imaging Window.
  • Page 39 12. The Enter the licence number dialog box is displayed. Enter the licence number and click Validate if you have the licence number or click Cancel to continue. 13. The icon appears on the toolbar of the Imaging Window. The installation is finished. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 5–7...
  • Page 40 5–8 INSTALLING THE KODAK DENTAL IMAGING SOFTWARE...

  • Page 41: 6-Installing The Unit

    IMPORTANT The tool references mentioned in this manual are ISO tool references. Technical Staff Requirements The installation requires the following number of technicians: Unit Component Technicians Head Column Fixed arm KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–1...

  • Page 42: Opening The Boxes

    Opening the Boxes Opening the Boxes To unpack the boxes, follow the instructions for each box. Opening the Head Assembly Box Before opening the head assembly box make sure that you have the required tool. To open the head assembly box, follow these steps: 1.
  • Page 43 2. Remove with the help of 2 persons the column from its box, using one at each end of the column. 3. Place the column on the floor in a horizontal position. Unwrap the column. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–...

  • Page 44: Installing The Unit

    Installing the Unit Installing the Unit Before installing the Unit, check that you have: • All the necessary tools • All the cables • All the switches Installing the Column 9 10 RJ45 6 mm To install the column, follow these steps: 1.
  • Page 45 You can use the optional base plate if: • The floor is inappropriate for column fixation. • The client requests no floor fixation. The column is ready for the Unit head attachment. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–...

  • Page 46: Installing The Head

    Installing the Unit Installing the Head 5 mm 3 mm To install the head, follow these steps: 5. Remove the head cover by unscrewing the 4 screws that attaches the head cover to the head chassis. 6. Remove the restraining screws securing the Head to the transport trolley (A). 7.
  • Page 47 (E). Tighten the 2 upper (B) and the 2 lower (D) screws with washers of the head assembly. The column is ready for the fixed arm attachment. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–...

  • Page 48: Installing The Fixed Arm

    Installing the Unit Installing the Fixed Arm 6 mm To install the fixed arm, follow these steps: 10. With the help of 2 persons, lift the fixed arm and attach it to the column with 4 screws with washers (A), but do not tighten. Use the level adjustment screw (B) and the spirit level (C) to correctly position the fixed arm;...

  • Page 49: Connecting The General Wiring

    Connect the blue (A) and the brown (B) wires to the line filter input terminals. • Connect the yellow-green (C) wire (ground) to the ground post on the side of the KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–...
  • Page 50 Installing the Unit line filter. • Connect cable 23 to J9 (D) of the CJ653 board Connect the cables on the fixed arm to the head in the following order: • Connect cable 5 to J6 (E) of the CJ699 board. •...

  • Page 51: Fitting The Covers

    3. Fit the 2 covers (F) and (G) under the head and tighten the screws. 4. Fit the Head cover (H) of the Unit to the head chassis and tighten the 4 screws. You can switch on the Unit now. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 6–...
  • Page 52 Fitting the Covers 6–12 INSTALLING THE UNIT...

  • Page 53: Annual Maintenance

    If the results of any of these inspections are unsatisfactory, refer to the Service Manual in order to rectify any problems. If there is any doubt, do not operate the Unit. KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 7–1...
  • Page 54 Annual Maintenance 7–2 Maintenance...

  • Page 55: 8-Technical Specifications

    Chapter 8 TECHNICAL SPECIFICATIONS Compliance with International Standards The KODAK 9000 3D digital imaging Unit is compliant with the International and EEC standards. Manufacturer TROPHY A subsidiary of Carestream Health, Inc. 4, Rue F. Pelloutier, Croissy-Beaubourg 77435 Marne la Vallée Cedex 2, France Model KODAK 9000 3D Unit, KODAK 9000 Unit.

  • Page 56: Unit Technical Specifications

    Unit Technical Specifications Unit Technical Specifications Table 8-1 describes the technical specifications for the KODAK 9000 3D digital imaging unit and Kodak 9000 digital imaging unit. Table 8–1 Unit Technical Specification Kodak 9000 3D Kodak 9000 X-Ray Generator Tube voltage...
  • Page 57 1158mm (L) x 1595mm (D) x 2378mm (H)* * Unit with shorter column is available on special order Required space 1500 (L) x 2000 (D) x 2400 (H) mm Weight 160 kg (353 lb KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 8–3...

  • Page 58: Unit Electronic Specifications

    Unit Electronic Specifications Unit Electronic Specifications 230/240 V (± 10%) 50/60 Hz, 100/110/130V (± 10%) 50/60 Hz, Type of Electrical Power Supply Single-Phase Single-Phase Acceptable fluctuation ± 10% ± 10% Ω Ω Apparent resistance of the power (max.) 0.12 (max.) supply circuit Permanent absorbed current 0.45 A...

  • Page 59: X-Ray Generator Technical Specifications

    Radiation leakage after one hour's operation (maximum utilization rate of < 1 mGy 93W, i.e. 90 kV, 10 mA, 13.9 sec. every 2 minutes 15 sec.) Weight 8.2 kg Dimensions 235 x 245 x 120 mm KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 8–5...
  • Page 60 X-Ray Generator Technical Specifications Figure 8–1 Heating and Cooling Curves of the X-ray Generator. Heating and cooling curves 110, 0 100, 0 90, 0 80, 0 100 W 70, 0 66 W 60, 0 33 W 50, 0 15 W 40, 0 10 W 30, 0...
  • Page 61 X-Ray Generator Technical Specifications Figure 8–2 Heating and Cooling Curves of the X-ray Tube Figure 8–3 Single Load Chart of the X-ray Tube Figure 8–4 Filament Emissions of the X-ray Tube KODAK 9000 3D Extraoral Imaging System_Installation Guide (SM711)_Ed 01 8–7...
  • Page 62 X-Ray Generator Technical Specifications 8–8 TECHNICAL SPECIFICATIONS...
