Contents To Order Parts or for Technical Support ..........2 Dimensions .
Page 3
Water ..............10 Rinsing water does not flow, ventilation runs .
Page 4
The information contained herein is based on the experience and knowledge relating to the subject matter gained by Carestream Health, Inc. prior to publication. No patent license is granted by this information. Carestream Health, Inc. reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information.
To Order Parts or for Technical Support To Order Parts or for Technical Support Type Number Hours Phone +49 7062 9255 0 Normal Business Hours: Central European Time Direct Mail PROTEC® (Berlin, Paris, Rome) GmbH & Co. KG Monday - Thursday: 8 am to 5 pm Lichtenberger Strasse 35 D-71720 Oberstenfeld Friday: 8 to 12 am (noon)
Dimensions Dimensions Depending on the model type, the MXP-2000 has either an open stand or a closed cabinet. Transport To carry hold To carry hold here!
Installation Data Mains 220 - 240 V, 16 A; Cu wire-Kabel 3 x 1.5 mm ; Ground-Leakage-Switch 25 A / 30 mA; power consumption 2.2 kW. 2a Power switch 16 A; 140 cm above floor. 2b Machine connection: Socket incl. earth 60 cm above floor. 3a Water connection: Water consumption 1.9 L/min;...
Troubleshooting Troubleshooting Algae 1.1 Excessive algae growth in water tank Algae growth inside the water tank is not only annoying, it causes increased cleaning work and leaves residue on the films. When algae growth increases, countermeasures are necessary: • When work has been completed at the end of the day, drain the water out of the machine. •...
Troubleshooting 3.3 The drive motor does not run • The display shows “E1” or “E3”: See the Operator Manual for descriptions of the error messages. • If current can be registered on the motor, then the motor is defective. Replace it. •...
Troubleshooting Calibration process Switch the processor off. While pressing the developer temperature button, switch the processor on. The display will show the developer bath temperature as measured by the sensor. Measure the actual temperature inside the developer bath using a calibrated thermometer. At first, adjust the displayed value in 1 degree increments using the arrow buttons.
Troubleshooting 7.3 The dryer ventilation is too weak • If the ventilation is connected incorrectly, it runs very slowly (the heating element in the air channel starts to glow). Dryer ventilation connection: black brown blue yellow / green 7.4 The dryer temperature cannot be reached •...
Spare Parts Spare Parts Position Order No. Description 1190-0-0200 Machine cover 1190-0-3101 Light protection cover 1190-0-0105 Film infeed tray 1191-0-0105 *Film infeed tray, graphics art 2006-0-0005 Drain stopcock 10 mm 1101-0-2000 Replenisher tank dev. 25l 1101-0-2100 Replenisher tank fix. 25l 1101-0-1700 Suction pipe w.
Spare Parts Wires and cables Position Order No. Description 1190-0-0108 Transformer > power PCB 20V 1190-0-0112 Power PCB > transformer 230V UL 1190-0-0110 Power PCB > controller PCB 1190-0-0111 Motor > controller PCB 1190-0-0114 Fuse holder > controller PCB UL 2004-0-0010 Electrical power lead 2004-0-0016...
Page 16
Spare Parts Installation position see page 9 Position Order No. Description 2002-1-0011 Circulation pump MD-10 (circulation) 2036-1-0001 Safety-transformer UL 0002-1-0001 Bellows pump KB2X 230V, 50Hz 0002-2-0001 Bellows pump KB2X 230V, 60Hz 0002-1-0008 Valve insertion f. pos. 22 0190-0-0900 Power PCB 2008-5-0006 Axial fan 0190-0-1801...
Page 17
Spare Parts Position Order No. Description 2008-5-0007 Ventilation 230 V (dryer) 2008-7-0007 Ventilation 230 V (dryer) UL 1190-0-1301 Air channel 0190-0-1300 Heating element 2kW/230V (dryer) 0190-7-1300 Heating element 2kW/230V (dryer) UL 0190-0-2200 Temperature sensor (same for bath and dryer heating) 1190-0-1302 Plate for air channel 2003-5-0002...
Page 19
Spare Parts Position Order No. Description 1190-0-0300 Developer standard 1196-0-0400 Fixer 1190-0-0600 Water/dryer standard 1190-0-0610 Dryer C2 1190-0-0620 Water C2 1191-0-0300 Developer graphics art 1191-0-0400 Fixer graphics art 1191-0-0600 Water/dryer graphics art 1191-0-0610 Dryer graphics art C2 1191-0-0620 Water graphics art C2 1190-0-0301 Side plate dev.
Page 20
Spare Parts Position Order No. Description: 100-104 1281-0-0000 Mounting set “Through-the-wall-mounting set film output” 0281-0-0201 Wall plate 0281-0-0100 Sealing wedge 1253-0-0001 Catch basket 0281-0-0202 Mounting kit 0281-0-0204 Strap 0281-0-0203 Blind plate 2 Position Order No. Description: 110-115 1280-0-0000 Mounting set “Through-the-wall-mounting set film feed” 0280-0-0102 Light protection 0280-0-0103...
