VIBRATION SENSOR

Installation

To install the vibration sensor:
1. Loosen the screws on the TH-Module (see Figure 1).
2. Connect the vibration sensor wires to the TH-Module alarm 1 or
3. Connect the other end of the vibration sensor wires to the vibration
4 EATON Powerware
Figure 1. Adjusting TH-Module Screws
alarm 2 connectors, then tighten the TH-Module screws (see
Figure 2).
Red Vibration Sensor Wire
Figure 2. TH-Module with Vibration Sensor Wires
sensor (see Figure 3).
Red Vibration Sensor Wire
Black Vibration Sensor Wire
S
® Vibration Sensor User's Guide
Alarm 1 Alarm 2
Black Vibration Sensor Wire
Figure 3. Vibration Sensor
164201681 Rev 1
