VIBRATION SENSOR
6. Verify that the ERM is connected to the network. Open the ERM
7. Change the status of the TH-Module from "Disable" to "Auto" on
8. Select "Vibration" for alarm 1 or alarm 2.
9. Select
10. When the sensor detects vibration, the ERM Web page displays
6 EATON Powerware
Web page and select
Monitoring
. The setup screen displays (see Figure 6).
Setup
the Device Name line. Verify that the TH-Module LED
(Power/Status) is flashing.
to confirm the vibration sensor setup.
Set Value
Figure 6. Vibration Sensor Settings
the alarm. The Web page for the alarm table and sensor events also
records the alarm.
Figure 7. Comprehensive View Screen
S
® Vibration Sensor User's Guide
, then
TH-Module-1 Setup
Figure 8. Events Log Data
164201681 Rev 1
or
TH-Module-2
