Items
Grayscale range
Laser power range
Border
Set the laser-engraving parameters.
Click Setting on the LaserEngraving page.
Set the JunctionVel (junction velocity), PlanAcc (linear acceleration), and Acc
(acceleration), for example, set all to 5, as shown in Figure 5.96.
Issue V1.0 (2018-09-11)
Dobot Magician User Guide
Table 5.11 Laser engraving parameters
Figure 5.96 Set the parameters of laser engraving
User Guide
87
Description
Set the grayscale range
Range: 0 - 255
Default value: 20 - 240
Set the laser power range
Range: 2 - 100
Default value: 20 - 90
Set the border width.
Unit: pixel
Range: 0 - 50
Default value: 4
