CLI – This examples assigns an IP and MAC ingress ACL to port 1, and
an IP ingress ACL to port 2.
Console(config)#interface ethernet 1/13-1
Console(config-if)#ip access-group david in3-127
Console(config-if)#mac access-group jerry in3-142
Console(config-if)#exit
Console(config)#interface ethernet 1/2
Console(config-if)#ip access-group david in
Console(config-if)#

Port Configuration

Displaying Connection Status

You can use the Port Information or Trunk Information pages to display
the current connection status, including link state, speed/duplex mode,
flow control, and auto-negotiation.
Field Attributes (Web)
• Name – Interface label.
• Type – Indicates the port type. (1000BASE-T, 1000BASE-SX,
1000BASE-LX)
• Admin Status – Shows if the interface is enabled or disabled.
• Oper Status – Indicates if the link is Up or Down.
• Speed Duplex Status – Shows the current speed and duplex mode.
(Auto, or fixed choice)
• Flow Control Status – Indicates the type of flow control currently in
use.
(IEEE 802.3x, Back-Pressure or None)
• Autonegotiation – Shows if auto-negotiation is enabled or disabled.
• Forced Mode
combination ports 9-12. (Copper-Forced, Copper-Preferred-Auto,
SFP-Forced, SFP-Preferred-Auto)
1
– Shows the forced/preferred port type to use for
P C
ORT ONFIGURATION
3-89
