SMC Networks SMC8606T Specifications

Switches/Hubs
The TigerSwitch 1000 makes gigabit affordable by pro-
viding 6 Auto-MDIX10/100/1000 BASE-T ports, and 2
h o t - s wappable GBIC slots for fiber co n n e ct i v i ty.
Without rewiring your existing network, SMC8606T
b rings gigabit co n n e ctions for bandwidth starve d
workstations, workgroups, and servers. It is a worthy
investment for the long run.
Overview
Advanced Features
• Easy migration- 6 10/100/1000 ports
Convenient Expansion – Each unit comes
with 2 slots for GBICs for fiber or copper
connections and network expansion
• QoS expedites critical data via prioritizing
and filtering
• MultiLink Trunking creates high-speed data
paths to servers or other switches
• VLAN Support provides port VLANs and GVRP
for auto-registration
• IGMP Snooping reduces multicast traffic for
maximum performance
• Broadcast storm control allows a user-defined
threshold to limit broadcast traffic
6 H u g h e s
Irv i n e, CA 92618
1-800-SMC-4YOU
w w w. s m c. co m
TigerSwitch
6-Port Gigabit 10/100/1000 Managed Standalone L2 Switch
Benefits
• EliteView, SMC's full-features, Windows-based SNMP
management software, included free
• Manage and configure the TigerSwitch 1000
from any Web-browser
• 4 group RMON support for detailed monitoring of
network performance
• RS-232 port available for out-of-band direct or
remote management
• Mirror port traffic from any port for easy
troubleshooting
• Spanning Tree protocol creates resilient links for
increased stability
• Optional redundant power unit provides
maximum uptime
1000
TM
Model Number::
SMC8606T delivers non-blocking switching perform-
ance, with advance features like Quality of Service,
VLAN support, MultiLink Trunking to provide maximum
performance benefits while maintaining security and
reducing network problems. Spanning Tree support,
redundant power lower the total cost of ownership.
S N M P, RMON and a full-fe at u red Web based the
TigerSwitch 1000 is further backed by a comprehen-
sive limited lifetime warranty and SMC's award winning
free technical support.
Compatibility
• IEEE 802.3 Ethernet
• IEEE 803.3u Fast Ethernet
• IEEE 803.3z Gigabit Ethernet
• IEEE 802.1d Spanning Tree Protocol and
• IEEE 802.1P Priority Tags
• IEEE 802.1Q VLAN
• IEEE 802.3ab Gigabit
• IEEE 802.3ac VLAN Tagging
• IEEE 802.3x Full-duplex flow control
• IEC 8802-3
• SNMP (RFC 1157), RMON (RFC 1757), ARP
• IGMP (RFC 1112),MIB II (RFC 1213),
• (RFC 1643), Bridge MIB (RFC 1493)
SMC8606T
traffic priorities
(RFC 826),
Ethernet-like MIB
