Configuring Port Authorization Mode - SMC Networks SMC8612XL3 F 1.0.1.3 Management Manual

Web – Select Security, 802.1x, Configuration. Enable dot1x globally for the
switch, modify any of the parameters required, and then click Apply.
CLI – This enables re-authentication and sets all of the global parameters
for dot1x.
Console(config)#dot1x re-authentication3-108
Console(config)#dot1x max-req 53-105
Console(config)#dot1x timeout quiet-period 403-108
Console(config)#dot1x timeout re-auth 53-109
Console(config)#dot1x timeout tx-period 403-109
Console(config)#authentication dot1x default radius3-105
Console(config)#

Configuring Port Authorization Mode

When dot1x is enabled, you need to specify the dot1x authentication mode
configured for each port.
Command Attributes
• Status – Indicates if authentication is enabled or disabled on the port.
• Operation Mode – Allows single or multiple hosts (clients) to connect
to an 802.1X-authorized port. (Range: Single-Host, Multi-Host;
Default: Single-Host)
• Max Count – The maximum number of hosts that can connect to a
port when the Multi-Host operation mode is selected. (Range: 1-20;
U A
SER UTHENTICATION
3-65
