SMC Networks SMC8606SX Specification Sheet

Managed &
Unmanaged
Switches
The TigerSwitch 1000 makes gigabit affordable by pro-
viding 6 1000BASE-SX ports, and 2 hot-swappable
GBIC slots for fiber connectivity. Without rewiring your
existing network, SMC8606SX brings gigabit connec-
tions for bandwidth starved workstations, workgroups,
and servers. It is the ideal solution for networks looking
for distance connection between workgroups or serv-
er farms.
Overview
Features
• Easy migration- 6 1000BASE-SX
SC ports
• Convenient Expansion – Each unit
comes with 2 slots for GBICs for fiber
connections and network expansion
• QoS expedites critical data via
prioritizing and filtering
• MultiLink Trunking creates high-speed
data paths to servers or other switches
• VLAN Support provides port VLANs
and GVRP for auto-registration
• IGMP Snooping reduces multicast
traffic for maximum performance
6 H u g h e s
• Broadcast storm control allows a user-
Irv i n e, CA 92618
defined threshold to limit broadcast
1-800-SMC-4YOU
traffic
w w w. s m c. co m
TigerSwitch
6-Port Gigabit 1000BASE-SX Managed Switch
with 2 GBIC ports
Benefits
• EliteView, SMC's full-features, Windows-based
SNMP management software, included free
• Manage and configure the TigerSwitch 1000 from
any Web-browser
• 4 group RMON support for detailed monitoring
of network performance
• RS-232 port available for out-of-band direct or
remote management
• Mirror port traffic from any port for easy
troubleshooting
• Spanning Tree protocol creates resilient links for
increased stability
• Optional redundant power unit provides
maximum uptime
1000
TM
Model Number::
SMC8606SX delivers non-blocking switching per form-
ance, with advance features like Quality of Service,
VLAN support, MultiLink Trunking to provide maxi-
mum per formance benefits while maintaining securi-
ty and reducing network problems. Spanning Tree
support, redundant power lower the total cost of own-
ership. SNMP, RMON and a full-featured Web based the
TigerSwitch 1000 is further backed by a comprehen-
sive limited lifetime warranty and SMC' s award win-
ning free technical support.
SMC8606SX
Compatibility
• IEEE802.3 Ethernet
• IEEE802.3u Fast Ethernet
• IEEE802.1D Spanning Tree
Protocol and traffic priorities
• IEEE802.1Q VLAN
• IEEE802.1P priority tags
• IEEE802.3x full-duplex flow
control
• IEEE802.3z Gigabit Ethernet
