Programming
7-38 Process Feed Forward Factor
Range: Function:
0% [0– The FF factor sends a part of the reference
*
400%] signal around the PI controller which then only
affects part of the control signal.
Activate the FF factor to obtain less overshoot
and high dynamics when changing the setpoint.
This parameter is always active when parameter
1-00 Configuration Mode is set to [3] Process.

7.5 Main Menu

[Main Menu] is used for programming all parameters. The
Main Menu parameters can be accessed immediately
unless a password has been created via
parameter 0-60 Main Menu Password. For most VLT
Drive applications it is not necessary to access the Main
Menu parameters, but instead the Quick Menu provides
the simplest and quickest access to the typical required
parameters.
The Main Menu accesses all parameters.
1. Press [Menu] key until indicator light in the
display is located above Main Menu.
▲ ▼
2.
Use [ ] [ ] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in
the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6. Use [ ] [ ] to set/change the parameter value.
Press [Back] to go back 1 level.
7.6 Quick Transfer of Parameter Settings
between Multiple Frequency Converters
When the set-up of a frequency converter is completed, it
is recommended to store the data in the LCP or on a PC
via MCT 10 Set-up Software.
Data transfer from the frequency converter to the LCP
1. Go to parameter 0-50 LCP Copy.
2. Press [OK].
3. Select [1] All to LCP.
4. Press [OK].
Connect the LCP to another frequency converter and copy
the parameter settings to this frequency converter as well.
MG02K402
Design Guide
Data transfer from the LCP to the frequency converter
1.
2.
3.
4.
7.7 Readout and Programming of Indexed
Parameters
Use chapter 7.4.2 Quick Menu Parameters - PI Basic Settings
QM2 as an example.
•
®
•
Micro
•
•
•
•
7.8 Initialize the Frequency Converter to
Default Settings in two Ways
Recommended initialization (via parameter 14-22 Operation
Mode)
1.
2.
3.
4.
5.
Danfoss A/S © 01/2016 All rights reserved.
Go to parameter 0-50 LCP Copy.
Press [OK].
Select [2] All from LCP.
Press [OK].
Press [OK] to select a parameter and use [
for selecting the indexed values.
To change a parameter value, select the value
and press [OK].
▲ ▼
Change the value using [ ]/[
Press [OK] to accept the new setting.
Pressing [OK] for more than 1 s activates the
adjust mode. In the adjust mode, it is possible to
make fast adjustment by pressing [
together with [OK].
▲ ▼
Press [ ]/[ ] to change the value. Press [OK] to
shift between digits. To exit the adjust mode,
press [OK] for more than 1 s again to exit and
save changes, or press [Back] to exit without
saving changes.
Select parameter 14-22 Operation Mode.
Press [OK].
Select initialization and Press [OK].
Cut off the mains supply and wait until the
display turns off.
Reconnect the mains supply, the frequency
converter is now reset.
▲ ▼
]/[ ]
