SMC Networks ADSL Barricade SMC7204BRA User Manual page 67

Figure 21. NAT TRANSLATION – Details Page
In addition to the information displayed in the [NAT TRANSLATION
- Details] table, this table displays the following for the selected
current translation sessions:
Field Description
Translated In This field indicates the public IP address to which the private
Address: IP address was translated.
In Address: This field indicates the private IP address that was translated.
Out Address: This field indicates the IP address of the outside destination
(web, ftp site, etc.)
In Packets: These fields indicate the number of incoming and outgoing
IP packets that have been translated in this translation session.
Out Packets:
In Ports: This is the actual port number corresponding to the LAN computer.
Out Ports: This is the port number associated with the destination address.
Translated In This is the port number to which the LAN computer's actual port
Ports: number was translated.
Viewing Current NAT Translations
65
