Technical Specifications - SMC Networks ADSL Barricade SMC7204BRA User Manual

Interface Ports:
- Internet (WAN): ADSL RJ11 (pin 3 and 4)
- Network (LAN): 4-Port 10/100 Mbps Ethernet switch
(Auto MDI/MDI-X)
ADSL Features:
- Embedded full-rate ADSL Modem Compliant with ANSI
T1.413 Issue 2 , ITU G.992.1 (G.DMT) and ITU G.992.2
(G.Lite).
- G.DMT full-rate connectivity at up to 12 Mbps downstream,
1024 Kbps upstream
Software:
- ATM Subsystem:
Supports up to 64 Virtual Channel Connections (VCCs)
•
Supports UBR, GFR, CBR, and VBR service classes
•
Provides adaptation layer (AAL5) functionality
•
Performs the traffic shaping and scheduling per ATM port
•
Supports PPP encapsulation over ATM (PPPoA) and
•
PPP over Ethernet (PPPoE)
Supports IP over ATM (IPoA)
•
Support for F5 AIS, RDI, and loopback cells
•
- Data Subsystem:
User Datagram Protocol (UDP)
•
Transmission Control Protocol (TCP)
•
Address Resolution Protocol (ARP)
•
T
S
PECIFICATIONS
ECHNICAL
181
