P
ERFORMANCE
The interface on the ADSL Barricade that communicates with other
network and Internet devices are identified by unique Internet
protocol (IP) addresses. You can use the Configuration Manager
to view the list of IP addresses that your device uses, and to view
other system and network performance data. See IP Addresses,
Network Masks, and Subnets for a description of IP addresses
and masks.

Viewing the ADSL Barricade's IP Addresses

To view the ADSL Barricade's IP addresses, click the [Routing] tab,
and then click [IP Address] in the task bar. The [IP Address Table]
page appears:
The table lists the [IP address], the network masks ([Netmask]),
and the interface names ([IF Name]) for each of its IP-enabled
interfaces.
V
IEWING
A
DDRESSES AND
Figure 8. IP Address Table Page
S
YSTEM
S
TATISTICS
IP
IP
39
