Quick Start
Figure 2. Quick Configuration Page in Configuration
The fields are described in the following table. Work with your
ISP to determine which settings you need to change.
Field
ATM Interface:
Operation Mode:
Encapsulation:
VPI:
VCI:
18
Description
General Settings
This setting allows you to select the ATM interface you want to
use (usually [atm-0]). Your system may be configured with more
than one ATM interface if you are using different types of services
with your ISP.
This setting enables or disables the ADSL Barricade.
When set to [No], the device cannot be used to provide Internet
connectivity for your network. Set it to [Enabled ], if necessary.
This setting determines the type of data link your ISP uses
to communicate with your ADSL Barricade. Contact them
to determine the appropriate setting.
These values are provided by your ISP and determine the unique
path that your connection uses to communicate with your ISP.
Manager
