SMC Networks ADSL Barricade SMC7204BRA User Manual page 34

1. At the bottom of the [Home] page, click [Modify].
The [System – Modify] page appears in a separate
browser window.
2. Modify the fields on this page as required.
The following table describes each field:
Option
Date: These fields initially appear dimmed. To modify the date and time,
Time: click the respective check boxes and select the appropriate values
from the drop-down lists. The time appears in military format.
Time Zone: You can select your time zone from the drop-down list, and then
click the appropriate radio button to indicate whether Daylight
DST: Savings Time is currently in effect. After you initially set the time,
(Daylight turning DST On or Off will adjust the current displayed time by one
Savings hour in the appropriate direction. You must remember to change
Time) the DST option each spring and fall as it will not change
automatically.
Modifying Basic System Information
Figure 5. System - Modify Page
Description
29
