Bridge:
IGMP:
IP Address:
Subnet Mask:
Primary DNS
Server:
Secondary DNS
Server:
Username:
Password:
3. When you have finished customizing these settings, click
[Submit]. The settings are now effective. However, if you
reboot or if the power is disconnected, your settings will
be lost. In Step 4, you save the changes to the permanent
memory.
4. Click the [Admin] tab that appears in the upper right corner
of the page, and then click [Commit & Reboot] in the task bar.
5. Click [Commit]. A page will appear briefly to confirm your
changes, and then you will be returned to the [Commit &
Reboot] page.
You can click [Delete] to remove all existing [Quick Configuration]
settings and return to the default values.
Configuring the ADSL Barricade
You may select [Enabled] or [Disabled] to set the bridging between
the ADSL Barricade and your ISP. Your ISP may also refer to this
as RFC 1483 or Ethernet over ATM.
You may select [Enabled] or [Disabled] to set the Internet Group
Management Protocol, which some ISPs use to perform remote
configuration of your device.
If your ISP has assigned a public IP address to your LAN, enter the
address and the associated subnet mask in the provided boxes.
(Note: In some configurations, the public IP address should be
entered on your PC rather than on the ADSL Barricade; please
check with your ISP.)
Enter the Primary and Secondary DNS server addresses
provided by your ISP.
Enter the Username and the Password you use to log in to your
ISP. (Note: This is not the same as the user name and password
you have used to log in to Configuration Manager.)
DNS
PPP
