Summary of Contents for SMC Networks 7904BRA3 - annexe 1
Page 1
ADSL2 BARRICADE ™ EZ Connect N 4-Port Annex A ADSL2/ADSL2+ Modem Router Draft 11n Wireless USB2.0 Adapter SMC7904BRA3...
Page 2
Fast Ethernet Router with built-in ADSL2/2+ Modem From SMC’s line of award-winning connectivity solutions February 2009 R.01 f/w 1.0...
Page 3
SMC Networks, Inc. 38 Tesla Irvine, CA 92618 All rights reserved. Trademarks: SMC is a registered trademark; and Barricade is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
Page 4
30 days of purchase from SMC or its Authorized Reseller. Registration can be accomplished via the enclosed product registration card or online via the SMC web site. Failure to register will not affect the standard limited warranty. The Limited Lifetime warranty covers a product during the Life of that Product, which is defined as the period of time during which the product is an “Active”...
MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
SMC7904BRA3 User Manual OMPLIANCES Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 7
In order to program this information into your facsimile, refer to your communications software user manual. EC Conformance Declaration SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2o, 4a, 08970 - Sant Joan Despí,...
Page 8
SMC7904BRA3 User Manual OMPLIANCES Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following conformance standards: •EN 55022 •EN 55024•EN 61000-3-2 •EN 61000-3-3 •EN 60950-1 CSA Statement This unit is to be used with an external power adaptor of a Class 2 or level 3 type and Approved type suitable for use in the North America of equipment installation, having an...
SMC7904BRA3 User Manual OMPLIANCES Safety Compliance Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger.
SMC7904BRA3 User Manual Contents Introduction..................................1 Package List ................................1 Safety Precautions ..............................1 Description of LEDs and Interfaces ........................2 System Requirements ............................3 Features .................................3 Hardware Installation ...............................5 Introducing the Web Configurator ...........................7 How to Access the Router .............................7 Status ..................................8 3.2.1 System..............................8 3.2.2 LAN ................................8 3.2.3...
Page 11
SMC7904BRA3 User Manual 3.7.2 Commit/Reboot.............................41 3.7.3 Password ...............................42 3.7.4 Backup/Restore .............................42 3.7.5 Upgrade Firmware ..........................43 3.7.6 Time Zone .............................44 3.7.7 System Log ............................45 3.7.8 SNMP..............................46 3.7.9 ACL...............................47 Diagnostic................................48 3.8.1 Ping ...............................48 3.8.2 ATM Loopback.............................49 3.8.3 ADSL ..............................50 3.8.4 Diagnostic .............................50 Appendix A Questions &...
SMC7904BRA3 User Manual 1 Introduction The ADSL access device supports multiple line modes. It provides four 10/100Base-T Ethernet interface at the user end. Utilizing the high-speed ADSL connection, the device provide users with broadband connectivity to the Internet or the Intranet for high-end users as net bars, office users, etc. can provide a downlink speed up to 24 Mbps and uplink speed up to 1 Mbps.
SMC7904BRA3 User Manual 1.3 Description of LEDs and Interfaces Front panel Fig 1.3-1 Front panel Color Status Description No power GREEN Device init OK Power Green/Red Device init RED BLINK Firmware upgrade No WAN link BLINK WAN data transiting Data Green WAN link established and active Initial self-test failed...
SMC7904BRA3 User Manual Item Usage Power On/Off. Power Power connector. DC 12 Voltage/1000mA, female pole is positive. 1.4 System Requirements Make sure first that you have prepared these following items to guarantee the ROUTER can work normally. Services subscriptions An 10BaseT/100BaseT Ethernet card installed on your PC HUB or Switch.
Page 15
SMC7904BRA3 User Manual Supports WEB interface Supports telnet CLI Supports System status display Supports PPP session PAP/CHAP Supports IP filter function Supports IP QoS function Supports remote access control Supports line connection status test Supports remote management (Telnet; HTTP) Supports configuration file backup and restoration function Ethernet supported such as Crossover Detection &...
SMC7904BRA3 User Manual 2 Hardware Installation 1. Refer to the figure below: Connect the DSL port of the device and the ROUTER port of the splitter with a telephone cable; connect the phone to the Phone port of the splitter through a cable; connect the incoming line to the Line port of the splitter.
Page 17
SMC7904BRA3 User Manual Fig 2-2 Connection Diagram (Connecting a telephone set before the splitter) It is recommended to follow the Connection 1 in an actual connection! Note: When Connection 2 is used, the filter must be installed close to the telephone lines. (See Fig. 2-2. Do not use the splitter instead of the filter).
SMC7904BRA3 User Manual 3 Introducing the Web Configurator 3.1 How to Access the Router The following is a detail “How-To” user guide for the first time users. 1. Open IE browser and enter http://192.168.2.1 in address bar. 2. You are required to enter user name and password. See the Fig 3.1-1. The super user name and password is admin/smcadmin The common user name and password is user/user Fig 3.1-1...
SMC7904BRA3 User Manual 3.2 Status Click Status in the menu to open the sub-menu which contains 6 items: System, LAN, WAN, Port Mapping, Statistic and ARP Table. 3.2.1 System Click System in the sub-menu to open the screen of Fig 3.2.1. In this page, you can view the current status and some basic settings of this router, for example, Software Version, DSL mode, Upstream Speed, Downstream Speed, Uptime and so on.
SMC7904BRA3 User Manual Fig 3.2.2 3.2.3 WAN Click WAN in the sub-menu to open the screen of Fig 3.2.3. In this page, you can view basic status of WAN, Default Gateway, and DNS Server. If you want to configure the WAN network, refer to section 3.5.1 “WAN Interface”.
SMC7904BRA3 User Manual 3.2.4 Port Mapping Click Port Mapping in the sub-menu to open the screen of Fig 3.2.4. In this page, you can view the mapping relation and the status of port mapping. Fig 3.2.4 3.2.5 Statistic Click Statistic in the sub-menu to open the menu in the left bar, which contains two items: Traffic Statistic and DSL Statistic.
Page 22
SMC7904BRA3 User Manual Fig 3.2.5.1 3.2.5.2. DSL Statistic Click DSL Statistic in the left bar to open the screen of Fig 3.2.5.2. In this page, you can view the ADSL line statistics, downstream rate, and upstream rate.
SMC7904BRA3 User Manual Fig 3.2.5.2 3.2.6 ARP Table Click ARP Table in the sub-menu to open the screen of Fig 3.2.6. In this page, you can view the table that shows a list of learned MAC addresses.
SMC7904BRA3 User Manual Fig 3.2.6 3.3 Wizard Click Wizard in the menu to open the sub-menu which contains one item: Wizard. Wizard enables speedy and accurate configuration of your Internet connection and other important parameters. The following sections describe these various configuration parameters. Whether you configure these parameters or use the default ones, click 'Next' to enable your Internet connection.
Page 25
SMC7904BRA3 User Manual Fig 3.3.1-1 Be sure to use the correct Virtual Path Identifier (VPI) and Virtual Channel Identifier (VCI) numbers assigned to you. The valid range for VPI is 0 to 255 and for VCI is 32 to 65535(0 to 31 is reserved for local management of ATM traffic).
Page 26
SMC7904BRA3 User Manual Label Description WAN Connection Type If you select the WAN Connection Type, you can select PPPoA, PPPoE, 1483 MER, 1483 Routed or 1483 Bridged. Encapsulation Mode Select the method of encapsulation used by your ISP from the drop-down list box.
Page 27
SMC7904BRA3 User Manual Fig 3.3.1 -4 The following table describes the fields of this screen. Label Description PPP Username The username and password apply to PPPoE and PPPoA encapsulation only. Make sure that you have entered the correct username and password. PPP Password PPP Connection Type Choices are Continuous, Connect on Demand and Manual.
Page 28
SMC7904BRA3 User Manual Fig 3.3.1 -5 The following table describes the fields of this screen. Label Description LAN IP Enter the IP address of your ROUTER in dotted decimal notation, for example, 192.168.2.1 (factory default) LAN Netmask Enter the subnet mask of LAN IP. Enable Secondary IP Select this check box to enable the secondary LAN IP Secondary LAN IP...
Page 29
SMC7904BRA3 User Manual Fig 3.3.1 -7 If you select 1483 MER in Fig 3.3.1-2, the screen appears as shown next. Fig 3.3.1 -8 The following table describes the fields of this screen. Label Description Obtain an IP address The MODEM obtains a WAN IP address automatically and at this time it automatically enables DHCP Client functions.
Page 30
SMC7904BRA3 User Manual Label Description Use the following IP If you want to input the WAN ip address by yourself. Check this entry and address then input related data in the field. WAN IP Address Input the IP address of the WAN interface provided by your ISP WAN Subnet Mask Input the subnet mask concerned to the IP address of the WAN interface provided by your ISP.
SMC7904BRA3 User Manual Label Description Use the following IP A static IP is a fixed IP that your ISP gives you. address WAN IP Address Input the IP address of the WAN interface provided by your ISP WAN Subnet Mask Input the subnet mask concerned to the IP address of the WAN interface provided by your ISP.
SMC7904BRA3 User Manual Fig 3.4.1 The following table describes the fields of this screen. Label Description IP Address Input the IP of Local area network interface here. Subnet Mask We recommend that you use an address from a block that is reserved for private use.
Page 33
SMC7904BRA3 User Manual Fig 3.4.2-1 If you set to DHCP Proxy, the screen of Fig 3.4.2-2 appears. Fig 3.4.2-2 The following table describes the fields of this screen. Label Description DHCP Proxy If set to DHCP Proxy, your ROUTER acts a surrogate DHCP Server and relays the DHCP requests and responses between the remote server and the client.
Page 34
SMC7904BRA3 User Manual Fig 3.4.2-3 The following table describes the fields in this screen. Label Description DHCP Server If set to DHCP Server, your ROUTER can assign IP addresses, an IP default gateway and DNS Servers to Windows95, Windows NT and other systems that support the DHCP client.
Page 35
SMC7904BRA3 User Manual Fig 3.4.2-4 The following table describes the fields in this screen. Label Description IP Address This field displays the IP address relative to the MAC address. MAC Address This field displays the MAC (Media Access Control) address of the computer.
SMC7904BRA3 User Manual Label Description Assign IP Click this button after entered Host MAC Address and Assigned IP Address, a row is added in MAC-Base Assignment Table. Modify Assigned IP Select a row in MAC-Base Assignment Table, the MAC address and IP address display Host MAC Address and Assigned IP Address.
Page 37
SMC7904BRA3 User Manual Fig 3.5.1-1 Label Description Current ATM VC Table This table shows the PVCs already existed. It shows the Interface name, Channel Mode, VPI/VCI, Encapsulation mode, local IP Address, Remote IP address, etc. The maximum item of this table is eight. (Virtual Path Identifier) The virtual path between two points in an ATM network, and its valid value is from 0 to 255 The virtual channel between two points in an ATM network, ranging from...
Page 38
SMC7904BRA3 User Manual Label Description WAN IP Settings Type The choices are Fixed IP and Use DHCP. If set Fixed IP, you should enter the Local IP Address, Remote IP Address and Subnet Mask. If set Use DHCP, your Modem is a DHCP client, the WAN IP is assigned by the remote DHCP server.
SMC7904BRA3 User Manual ATM Setting: Click ATM Setting button in Fig3.5.1-1, the screen of Fig 3.5.1-3 appears. In this page, you can configure the parameters of the ATM for your ADSL router, including QoS type, PCR, CDVT, SCR and MBS. Fig 3.5.1-3 3.5.2 ADSL Settings Click ADSL Interface in the sub-menu to open the screen of Fig 3.5.2.
SMC7904BRA3 User Manual 3.6 Advance Click Advance in the menu to open the sub-menu which contains 8 items: DNS, Firewall, Virtual Server, Routing, IP QOS, Anti-dos, Port Mapping and Others. 3.6.1 DNS Short for Domain Name System (or Service or Server), an Internet service that translates domain names into IP addresses.
SMC7904BRA3 User Manual 3.6.2 Firewall Click Firewall in the sub-menu to open the menu in the left bar, which contains three items: IP/Port Filter, MAC Filter and URL Blocking. 3.6.2.1. IP/Port Filter Click IP/Port Filter in the left bar to open the screen of Fig 3.6.2.1. Entries in this table are used to restrict certain types of data packets through the Gateway.
SMC7904BRA3 User Manual Fig 3.6.2.2 3.6.2.3. URL Blocking Click URL Blocking in the left bar to open the screen of Fig 3.6.2.3. This page is used to configure the Blocked FQDN (Such as tw.yahoo.com) and filtered keyword. Here you can add/delete FQDN and filtered keyword.
SMC7904BRA3 User Manual Fig 3.6.2.3 3.6.3 Virtual Server Click Virtual Server in the sub-menu to open the menu in the left bar, which contains two items: Services and DMZ Settings. 3.6.3.1. Services Click Services in the left bar to open the screen of Fig 3.6.3.1. This page is used to enable the servers in the local network.
SMC7904BRA3 User Manual Fig 3.6.3.2 Select the checkbox Enable DMZ to enable this function. Then input a IP Address of the DMZ host. Click the button Apply Changes to save the settings of this page. 3.6.4 Routing Click Routing in the sub-menu to open the menu in the left bar, which contains two items: RIP and Static Route.
SMC7904BRA3 User Manual Fig 3.6.4.1 3.6.4.2. Static Route Click Static Route in the left bar to open the screen of Fig 3.6.4.2-1. This page is used to configure the routing information. Here you can add/delete IP routes. Fig 3.6.4.2-1 Click Show Routes, the below window appears. The table shows a list of destination routes commonly accessed by your network.
SMC7904BRA3 User Manual Fig 3.6.4.2-2 3.6.5 IP QoS Click IP QoS in the sub-menu to open the screen of Fig 3.6.5. Entries in this table are used to assign the precedence for each incoming packet based on physical LAN port, TCP/UDP port number, and source/destination IP address/subnet masks.
SMC7904BRA3 User Manual Fig 3.6.6 Click the button Apply Changes to save the settings of this page. 3.6.7 Port Mapping Click Port Mapping in the sub-menu to open the screen of Fig 3.6.7. In this page, you can bind the WAN interface and the LAN interface to the same group.
SMC7904BRA3 User Manual Fig 3.6.7 3.6.8 Other Click Others in the sub-menu to open the menu in the left bar, which contains four items: IGMP Proxy, UPNP, Bridge and IP PassThrough. 3.6.8.1. IGMP Proxy Click IGMP Proxy in the left bar to open the screen of Fig 3.6.8.1. IGMP proxy enables the system to issue IGMP host messages on behalf of hosts that the system discovered through standard IGMP interfaces.
Page 49
SMC7904BRA3 User Manual Fig 3.6.8.1 3.6.8.2. UPNP Click UPNP in the left bar to open the screen of Fig 3.6.8.2. This page is used to configure UPnP. The system acts as a daemon after you enable it. Click Apply Changes to save the settings of this page. Fig 3.6.8.2 3.6.8.3.
Page 50
SMC7904BRA3 User Manual Fig 3.6.8.3-1 Click Show MACs button in Fig 3.6.8.3-1, the below window appears. This table shows a list of learned MAC addresses for this bridge. Fig 3.6.8.3-2 3.6.8.4. IP PassThrough Click IP PassThrough in the left bar to open the screen of Fig 3.6.8.4. The IP PassThrough has the other name ZIPB or IP Extension.
SMC7904BRA3 User Manual Fig 3.6.8.4 3.7 Admin Click Admin in the menu to open the sub-menu which contains 11 items: Remote Access, Commit/Reboot, Password, Backup/Restore, Upgrade Firmware, Time Zone, System Log, SNMP, TR069, ACL and Logout. 3.7.1 Remote Access Click Remote Access in the sub-menu to open the screen of Fig 3.7.1. In this page, you can enable or disable the services which are used by the remote host.
SMC7904BRA3 User Manual Fig 3.7.1 3.7.2 Commit/Reboot Click Commit/Reboot in the sub-menu to open the screen of Fig 3.7.2. In this page, you can set the router reboot to default settings or set the router save the current settings then reboot. Fig 3.7.2 Label Description...
SMC7904BRA3 User Manual 3.7.3 Password Click Login Password in the sub-menu to open the screen of Fig 3.7.3. In this page, you can change the password of the user, include admin and user. The super user name and password are admin/admin as default, and the common user name and password are user/user.
SMC7904BRA3 User Manual Fig 3.7.4 Label Description Save Settings to File Click the Save button, then select the path and save the configuration file of your router. Load Settings from File Click the Browse button to select the configuration file. Upload Selected the configuration file of router, click Upload button to begin restore the router configuration.
SMC7904BRA3 User Manual Fig 3.7.5 Label Description Select File Click the Browse button to select the Firmware file. Upload Selected the Firmware file, click Upload button to begin upgrading the Firmware. Reset Click this button to begin selecting the Firmware file afresh. 3.7.6 Time Zone Click Time Zone in the sub-menu to open the screen of Fig 3.7.6.
SMC7904BRA3 User Manual Fig 3.7.6 Label Description Refresh Click this button to refresh the system shown in the page. Time Mode If select Time Server, the router obtains the system time from the time server. If select Manual, you should configure the system time manually. Enable SNTP Client If select this checkbox, you can choose the correct SNTP Server which you Update...
SMC7904BRA3 User Manual Fig 3.7.7 Label Description System Log You can enable or disable the System Log function. Apply Changes Click this button to save the settings of this page. Refresh Click this button to refresh the system log shown in the text field. 3.7.8 SNMP Click SNMP in the sub-menu to open the screen of Fig 3.7.8.
SMC7904BRA3 User Manual Fig 3.7.8 Label Description Trap IP Address Enter the IP address of the trap host. The trap information is sent to this host. Community name (read-only) The network administrators must use this password to read the information of this router. Community name The network administrators must use this password to configure the (write-only)
SMC7904BRA3 User Manual Fig 3.7.10 Step 1: If you want to enable ACL, select "Enable" and click "Apply Changes". Step 2: Configure Access Control List. Step 3: Click "Apply Changes” to effect the configuration. Note: If you check "Enable" in ACL Capability, please make sure that your host IP is in ACL List before it takes effect 3.8 Diagnostic Click Diagnostic in the menu to open the sub-menu which contains 4 items: Ping, ATM Loopback, ADSL...
SMC7904BRA3 User Manual Fig 3.8.1 Label Description Host Address Enter the IP Address here. Send Click this button to begin to Ping the Host Address. 3.8.2 ATM Loopback Click ATM Loopback in the sub-menu to open the screen of Fig 3.8.2. In this page, you can use VCC loopback function to check the connectivity of the VCC.
SMC7904BRA3 User Manual 3.8.3 ADSL Click ADSL in the sub-menu to open the screen of Fig 3.8.3. This page is used for ADSL Tone Diagnostics. Fig 3.8.3 Go!: Click this button to begin ADSL Tone Diagnostics. 3.8.4 Diagnostic Click Diagnostic in the sub-menu to open the screen of Fig 3.8.4. This page is used for testing your DSL connection.
SMC7904BRA3 User Manual Appendix A Questions & Answers This section describes common problems you may encounter and possible solutions to them. The Barricade can be easily monitored through panel indicators to identify problems. Question: Why all LED indicators are off? Answer: Check the connection between the power adaptor and the power socket Check the power switch is on or not...
Page 63
SMC7904BRA3 User Manual 5. Question: Why cannot open the Modem configuring web page? Answer: Follow below steps to check the communication between the computer and Modem: Click start -> run (input ping demands)-> Ping 192.168.2.1 (MODEM IP address). If cannot reach the modem, please check following configuration: The type of the network cable The connection between the modem and computer You computer’s TCP/IP configuration...
SMC7904BRA3 User Manual Appendix B Technical Specifications External Connectors 1 push power switch 1 DC power jack 1 factory reset button 4 LAN 10/100M Auto MDI/MDIX RJ45 ports 1 WAN RJ11 DSL port Protocol Feature Bridging/Routing RFC 1483 Bridge IEEE 802.1D transparent bridging Bridge Filtering RFC 1483 Router RIP 1 &...
Page 65
SMC7904BRA3 User Manual Ethernet Feature Fully compliant with IEEE802.3/802.3u auto-negotiation function Support 10base-T, 100base-TX Support half duplex, full duplex Support back pressure flow control for half duplex, IEEE802.3x flow control for full duplex Support MDI/MDIX auto cross Management Support Support WEB/TFTP mode which use as native and long-distance edition upgrade Support test estate of circuitry connect(Diagnostics)...
