Data Sheet
ADSL Barricade
SMC7204BRB
4-Port ADSL Router with Built-in Annex B
ADSL Modem
The ADSL BarricadeTM (SMC7204BRB) is an external Ethernet standards
based ADSL modem and Router that provides high-speed Internet access
to both the residential and the small and home office (SoHo) user. This new
Modem/Router provides unrivaled asymmetric high-speed data transport
over a single copper pair linking branch offices, home offices and individual
subscribers to their network service providers, including Internet service
providers.
With the ADSL BarricadeTM, investments are protected through the support
of popular DSL connection models such as PPP over Ethernet (PPPoE), PPP
over ATM (PPPoA), bridging and routing. The Barricade ADSL supports two
modes of operation. This modem can be configured to function as bridge to
support a single computer, then as the network grows, it can be reconfigured
as full featured Router to provide Internet access to multiple computers.
Another benefit of using the SMC7204 BRB in router mode is that you are also
protected by the built-in SPI/NAT firewall. Other features that are available in
Router mode include VPN pass-through, remote access communications, and
DHCP Server easy network setup.
This new high-performance ADSL Gateway has an easy-to-use web-based
management user interface that can be used to configure and manage your
network via a local or remote computer. For added control, this modem can
also be managed via the Command Line Interface (CLI), which can be initialized
through a Telnet session, or through a Windows-based configuration tool.
Features and Benefi ts
High Speed Internet Access
•
Full-rate ADSL Modem - Supports speeds up to 8 Mbps downstream, 1024 Kbps upstream
•
Compliant with ANSI T1.413 Issue 2, ITU G.992.1 (G.DMT), ITU 992.2 (G.Lite) and ITU 994.1
(G.hs) standards
•
Exceeds DSL forum performance specifi cation
•
Offers both a 4-Port 10/100 Mbps Ethernet Switch for computer connectivity
•
Simple installation with Web-based Management
•
Support for IP Filtering and Website Blocking using Keywords
•
Built-in DHCP Server and DNS Proxy for easy network setup
•
Supports both Bridge or Routing Modes
•
Management access via SNMP, HTTP, and CLI
•
Fast Internet/Intranet access
•
Easy installation with auto-run CD program
•
Remote Access
•
SOHO/Home solutions
•
Brings instant data, voice & video access to your PC up to 150 times faster than a 56K
modem
•
Provides greater fl exibility for simultaneous sharing of local resources & the ADSL line
•
Supports for MDI/MDI-X auto crossover on each port (LAN & WAN)
Compatibility
•
ANSI T1.413 Issue 2
•
G.DMT (ITU G.992.1)
•
G.Lite (ITU G.992.2)
•
G.hs (ITU 994.1 )
•
IEEE 802.3 10 Base-T Ethernet
•
IEEE 802.3u 100 Base-Tx Fast Ethernet
Product Model No
ADSL Barricade g SMC7204BRB
TM
g
Description
4Port ADSL Router with Built-in Annex B ADSL Modem
