JUMPER SETTINGS

Table 4. Link Option Functions
Link Number Default Position
LK1 Short
LK2 Open
LK3 Open
LK4 Short
LK6 Open
LK7 Open
LK8 Short
LK9 Open
LK10 Short
LK11 Open
LK12 Short
LK13 Short
LK14 Open
LK24 Open
M1 B
M2 B
M3 Open
M5 A
Function
AN_A to AFE daughter board.
LED GPIO functionality of P2.1.
AN_B to AFE daughter board.
Connect the supercapacitor to the VBACK pin.
Thermistor voltage output measurement (AN_A).
VCCM_DIG to VCCM_ANA external connection (connected internally on chip).
LED GPIO functionality of P0.11.
AN_C to AFE daughter board.
AGND To DGND connector.
AN_D to AFE daughter board.
LED GPIO functionality of P4.2.
VBUS link.
Supply for VLCDVDD.
VUSB to VCCM_ANA connector. The battery must be removed when this link is inserted.
P0.6 selected for UART Tx.
P0.7 selected For UART Rx.
AN_EXCITE used for thermistor operation.
VDD_IO connection. When this link is in Position A, the VDD_IO supply is from
VCCM_ANA.
